audiovias.com
instruction
manual
st
1
edition, november 2000
www.audiovias.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Panorama Cyc Power and is the answer not in the manual?

Questions and answers

Related Manuals for Coemar Panorama Cyc Power

Summary of Contents for Coemar Panorama Cyc Power

  • Page 1 audiovias.com instruction manual edition, november 2000 www.audiovias.com...
  • Page 2 Please note in the space provided above the relative service information of the model and the retailer from whom you purchased your Panorama Cyc Power : This information will assist us in providing spare parts, repairs or in answering any technical enquiries with the utmost speed and accuracy.
  • Page 3 English Index 1. Packaging 2. Transportation 3. Important safety information 4. Lamp: installation and replacement 5. Operating frequency and voltage 5.1 Slecting the operating voltage and frequency of the lamp 5.2 Selecting the operating voltage of the transformer 6. Installing the unit 6.1 Installing the unit in weather-protected areas 6.2 Installing the unit in exposed areas 7.
  • Page 4 English Congratulations on having purchased a coemar product. You have assured yourself of a fixture of the highest quality, both in componentry and in the technology used. We renew our invitation to you to complete the service information on the previous page, to expedite any request for service information or spares (in case of problems encountered either during, or subsequent to, installation).
  • Page 5 3. The level of technology inherent in the Panorama Cyc requires the use of specialised personnel for all service applications; refer all work to your authorised coemar service centre. 4. A good earth connection is essential for proper functioning of the projector.
  • Page 6 English 4. Lamp: Installation and replacement Panorama Cyc Power utilses two Philips 575/2 MSR or MSD 575 da 575W with GX 9,5 lamp bases. The lamps are available from your authorised coemar sales agent. coemar cod. 105245/2 coemar cod. 105215...
  • Page 7 English 4) Remove the lamp assembly (D). 5) Locate the lampholders (E) 6) The lamps used are manufactured from quartz glass and should be handled with care; always adhere to the instruc- tions supplied in the packaging. Never touch the glass direc- tly, use the tissue provided in the lamp’s packaging.The GX 9,5 lampbase is symmetrical in construction so the lamp may be positioned easily.
  • Page 8 5.1 Selecting an operating voltage and frequency for the lamp to other than that preset by coemar (this procedure is reserved for technical personnel) This procedure will determine the operating current drawn by the lamps after they have been ignited; the correct value is 6,95 Amps.
  • Page 9 English 3) Locate the terminal strip marked with a sticker showing 208/230/240 V and 50 or 60Hz; the cables attached here at those which you will need to move. 4) Cables 33 and 18 determine operating voltage, move these to either the 208, 230 or 240V terminals of the ballast. 5) Cables 31 and 29 determine operating frequency, move these to either the 50 or 60Hz terninals of the ballast..

  • Page 10: Installing The Unit

    As indicated in the diagram, the base of the unit must always be facing the ground. The lamp head of the Panorama Cyc Power may be adjusted from -35° to +75° without having to move any other component except the head of the fixture.

  • Page 11: Mains Connection

    ø external 10 mm, rated 300/500V, tested to 2KV, operating temperature -40° +180°, coemar cod. CV5309). mains connection Panorama Cyc Power can operate at voltages from 208V-230V-240V at 50 or 60Hz (operating voltage and frequency can be selected as described in section 5 of this manual).

  • Page 12: Signal Connection

    We recommend that the last link in the DMX chain be isolated by using suitably sheathed weather-proof dummy plugs. This ensures that the weather rating of the Panorama Cyc Power is maintained. coemar supplies two XLR 3, IP 67 rated plugs for this purpose.
  • Page 13 We recommend that these links in the DMX chain be isolated by using suitably sheathed weather-proof dummy plugs. This ensures that the weather rating of the Panorama Cyc Power is maintained; coemar supplies two XLR 3, IP 67 rated plugs for this purpose.
  • Page 14 English 9. Powering up Panorama Cyc Power is supplied with 4 barndoors which are supplied fitted to the unit in the closed postion to reduce packaging dimensions. Attention! The barndoors should always be opened out prior to turning on the lamp. Failure to do so may result in dangerous overheating of the projector and possible damage to its compnents.

  • Page 15: Dmx Addressing

    English 10. DMX addressing Each Panorama Cyc Power utilises 6 channels of DMX 512 signal for complete control. To ensure that each unit accesses the correct signal, it is necessary to correctly address each fixture. Any number between 1 and 506 can be generated via the multifunction panel of the Panorama Cyc Power.
  • Page 16 English 11. DMX 512 signal Panorama Cyc Power may be operated using DMX 512 signal, connection is described in section ”8.1 Using DMX512 signal”. If you have followed all instructions correctly to this point, the 6 channels of your DMX 512 controller will have control of...

  • Page 17: Automated Functions

    P R O 2 (2 selections available) enter +o– program n° 2 3- Adjust the hold time for each colour in the sequence, if you wish to alter from the 0 set as the coemar default. -–000 AOO1 A U S P from menu + o –...
  • Page 18 P R O 2 (2 selections available) enter +o– program n° 2 4- Adjust the hold time for each colour in the sequence, if you wish to alter from the 0 set as the coemar default. -–000 AOO1 A U S P from menu + o –...
  • Page 19 English 13.2 Setting up “slave” units All units being operated from the “Master” unit must be set to “Slave” mode. They must be connected correctly in the dmx daisy chain, see section 8.3 Synchronising Panorams without DMX 512 signal Projectors set up as ““Slave”” are recognisable as they are the only ones with both dmx in and out sockets connected (with the exception of the last in the series which has only its “DMX IN”...

  • Page 20: Display Panel Functions

    English 14. Display panel functions On display panel of Panorama Cyc Power are shown all the functions available; it is possible to change some of those parameters and to add some functions. Changing the setting made by coemar can vary the functions of the device that will not respond to the DMX 512 mixer used to control it.
  • Page 21 English Functions described on paragraph 12 and 13. AOO1 A U T O O F F menu + o – +o– automatic movement enter enter to disable the function to activate colour changing effects without using an external control signal +o–...

  • Page 22: Mechanical Adjustments

    English 15. Mechanical adjustments After having powered up the projector and set up either DMX 512 or automated control of the functions of the Panorama Cyc Power, you may wish to perform the following mechanical adjustments to optimise the output of the unit in your installation.
  • Page 23 Further adjustments to the output of the fixture may be made by adjusting the barndoor, as described below. 15.4 Barndoor adjustments The Panorama Cyc Power features a 4 leaf barndoor which is set in the full closed position for transportation. It can be used to alter the beamspread to suit your particular application.

  • Page 24: Thermal Protection

    The thermal sensor may be manually reset. This procedure should be undertaken by qualified technicians only. 17. Maintenance Whilst every possible precaution has been taken to ensure the trouble-free operation of your Panorama Cyc Power, the following periodic maintenance is highly recommended. Make sure that mains power is disconnected prior to performing any maintenance.
  • Page 25 English Mechanicals Periodically check all mechanical devices for wear and tear; gears, guides, belts, etc., replacing them if necessary. Ensure the screws affixing the barndoors are firmly tightened. Electrical components Check all electrical components for correct earthing and proper attachment of all connectors, refastening if necessary. Dichroic filters To correctly clean and maintain the dichroic filters, it is necessary to gain access to the internals of the projector.

  • Page 26: Electronic Motor Alignment

    RESERVED FOR INSTALLERS ONLY The display panel on the Panorama Cyc Power allows for the electronic calibration of the unit’s motors; this procedure is undertaken by coemar at predelivery; it may be useful to perform this procedure in the case of internal components being replaced.
  • Page 27 Inghilterra 46042 Castelgoffredo (Mantova) Italy Tel. 0376/77521 Fax 0376/780657 coemar reserves the right to effect modifications without notification instruction manual Panorama Cyc Power edition november 2000 audiovias.com www.audiovias.com...
