- Page 1 ArcPod 15Q Compact 15x10W RGBW/Fc outdoor IP66 LED wash light for exterior installations USER MANUAL English version REV.01-07/20...
- Page 2 ARCHWORK product are trademarks OWNED or licensed by Music & Lights S.r.l., its affiliates, and subsidiaries. ARCHWORK is a registered trademark by Music & Lights S.r.l. All right reserved. Music & Lights – Via Appia km 136,200; Itri 04020, Italy.
- Page 3 LENS (CODE S27QLENS10-15-25-45) BARNDOOR (CODE A15QBD) BARNDOOR (CODE A15QBD) 11 - MAINTENANCE 11 - MAINTENANCE MAINTENANCE AND CLEANING THE PRODUCT MAINTENANCE AND CLEANING THE PRODUCT VISUAL CHECK OF PRODUCT HOUSING VISUAL CHECK OF PRODUCT HOUSING TROUBLESHOOTING TROUBLESHOOTING ARCHWORK - ArcPod 15Q...
-
Page 4: Safety Information
• Before using the fixture, check that all power distribution equipment and cables are in perfect condition and rated for the current requirements of all connected devices. • Isolate the fixture from power immediately if the power plug or any seal, cover, cable, ARCHWORK - ArcPod 15Q... - Page 5 The products to which this manual refers comply with the European Directives pursuant • 2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD). • 2014/30/EU - Electromagnetic Compatibility (EMC). • 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS). ARCHWORK - ArcPod 15Q...
-
Page 6: Package Content
• DATAMASTER: RDM/DMX tool,cable tester, 5p XLR connectors,pouch, charging cable, XLR adapt- ers; • AWEXAC1L03: IP67 power extension cable for ARCHWORK projectors, L.03 m; • AWEXAC1L05: IP67 power extension cable for ARCHWORK projectors, L.05 m; • AWEXAC1L10: IP67 power extension cable for ARCHWORK projectors, L.10 m;... -
Page 7: Installation
Do not use any type of clamp that does not completely encircle the structure when fastened. TILT movement: 130°. Screws for unlock and lock the TILT (on both sides). Slots for fixing. 307 [12.1] 289 [11.4] R4 [R0.2] 8 [0.3] Fig.2 ARCHWORK - ArcPod 15Q... -
Page 8: Product Overview
2. DMX IN (3-pole): 1 = GND, 2 = sign-, 3 = sign+. 3. DMX OUT (3-pole): 1 = GND, 2 = sign-, 3 = sign+. power output for connection of multiple units in series. 4. POWER OUT: Fig.3 ARCHWORK - ArcPod 15Q... -
Page 9: Connection To The Mains Supply
POWER POWER POWER POWER POWER POWER POWER POWER MAINS 230V NOTE: when not using the Power output connectors, you must seal the cable ends with the supplied caps. Fig.5 - Example configuration (Output at 230 V) ARCHWORK - ArcPod 15Q... -
Page 10: Dmx Connection
... . DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX OUT DMX512 Controller Fig.7 - Example 10 DMX channels configuration ARCHWORK - ArcPod 15Q... -
Page 11: Dmx Addressing
The PIDs in the following tables are supported in the product. Parameter DMX_PERSONALITY 0x00e0 DMX_PERSONALITY_DESCRIPTION 0x00e1 CURVE 0x0343 MODULATION_FREQUENCY 0x0347 IDENTIFY_DEVICE 0x1000 FACTORY_DEFAULTS 0x0090 WBANLANCE_R 0x8200 WBANLANCE_G 0x8201 WBANLANCE_B 0x8202 WBANLANCE_W 0x8203 FULL ON_Mode(Full On 0:HB, 1:Studio) 0x8217 ARCHWORK - ArcPod 15Q... - Page 12 8200 White Balance-Red ÷ 8201 White Balance-Green ÷ 8202 White Balance- Blue ÷ 8203 White Balance- White ÷ 0: No 8206 Clean Device Hours 1: Yes 8217 Full On mode 0: HB Mode 1: Studio Mode ARCHWORK - ArcPod 15Q...
-
Page 13: Stand Alone Function
DMX line. On others units that will be connected to the same DMX line must NOT be setted the STAND ALONE, they will be "SLAVE" and they will follow the DMX of the MASTER. ARCHWORK - ArcPod 15Q... -
Page 14: Dmx Charts
9 - DMX CHARTS Channel 5 Ch 7 Ch 10 Ch DIMMER DIMMER GREEN BLUE GREEN GREEN WHITE BLUE BLUE DIMMER SPEED MODE WHITE WHITE STROBE STROBE DIMMER SPEED MODE COLOR MACRO EFFECTS EFFECTS SPEED DIMMER SPEED MODE ARCHWORK - ArcPod 15Q... - Page 15 000 - 051 Dimmer speed mode off 052 - 101 Dimmer speed mode 1 (fast speed) 102 - 152 Dimmer speed mode 2 (middle speed) 153 - 203 Dimmer speed mode 3 (slow speed) 204 - 255 ARCHWORK - ArcPod 15Q...
-
Page 16: Accessories Installation
2. Replace the lenses by inserting the two pins on the back of the lens with the holes provided on the PCB LED. NOTE: to reassemble the lenses, the reverse procedure. NOTE: it is recommended to tighten the front cover screws carefully so as to guarantee the correct IP degree. Fig.9 ARCHWORK - ArcPod 15Q... - Page 17 The Black barn door with 4 directional leafs to adjust the light beam is available as optional accessory. Insert the three to positioning and the spring pin on the hardware into the holes provided on the top and down side edge of the product. NOTE: To remove the accessory, reverse the procedure. Fig.10 ARCHWORK - ArcPod 15Q...
-
Page 18: Maintenance
• This checking is necessary for both fixed installations and preparing product for renting. Any free moving parts inside of the product, cracked cover/housing or any part of front glass not sitting properly in place need to be immediately replaced. ARCHWORK - ArcPod 15Q... -
Page 19: Troubleshooting
• Dirty or damaged filters • Install lens assembly properly Contact an authorized service center in case of technical problems or not reported in the table can not be resolved by the procedure given in the table. ARCHWORK - ArcPod 15Q... - Page 20 MUSIC & LIGHTS S.r.l. - Phone +39 0771 72190 - www.musiclights.it...
