Comet VA-250 Instruction And Assembly Manual

VA~250
Instruction and assembly manual
Thank you for purchasing the Comet VA-250 Broadband antenna. For your safety and to
get the best possible results, we recommend that you read this manual to fully
familiarize yourself with the VA-250. Also, please keep this manual in safety place for
your future reference.
No. Description
1 Matching section assembly
2 Worm cramp for Aluminum element (1)
3 Aluminum element (2) with the element attachment lug
4 Top element
5 Top element with the reduction coil
6 U bolt (w/ lock washier, nut)
7 Antenna wire : 3.5 sq.mm (10m)
8 Insulator
9 Nylon rope (5m)
10 Self adhesive tape (20cm)
Broadband antenna install a veranda

Features;

• It was compared with a usual antenna, and
the ultra wide-band property which
became stable was realized.
@ Thick base element(2mm) for heavy
duty operation.
©Utilizing stainless bolts and nuts for longer
life.
®An antenna wire kind can be used even if
Zeppelin form wire antenna is taken
because it is attached.

Before assembly;

Please make sure all parts are enclosed in
carton box as listed below.
Qty.
1
1
1
1
2
1
1
1
1
