Comet CHA-250BX Instruction And Assembly Manual

CHA-250BX Broadband GP antenna
Instruction and assembly manual
Thank you for purchasing the Comet CHA-250B Broadband GP antenna. For your
safety and to get the best possible results, we recommend that you read this manual to
fully familiarize yourself with the CHA-250B. Also, please keep this manual in safety
place for your future reference.

Features

• Ultra wide-band coverage.
• Thick base element (2mm) for heavy duty operation.
• Utilizing stainless bolts and nuts for longer life.

Before assembly

Please make sure all parts are enclosed in carton box as listed below.
No. Description
1 Matching section assembly
2 Worm cramp for Aluminum element (1)
3 Aluminum element (2)
4 Aluminum element (3)
5 Aluminum element (4)
6 Aluminum element (5)
7 U bolt (w/ lock washier, nut)
8
Hexagon head screw (M5 X 35/Wing nut)
9 Hexagon head screw (M4 X 30/Wing nut)
10 Hex wrench
11 Self adhesive tape (20cm)
Qty.
1
l
1
1
1
1
2
2
2
1
1
