Panasonic NV-MD9000EN Service Manual page 57

Ref. Part No. Part Name &
No. Description
VZ4501 VRT0158 TRANSIENT/SURGE
ABSORBER
VZ4502 VRT0158 TRANSIENT/SURGE
ABSORBER
VEP03G26A DV TERMINAL C.B.A. (RTL)
JK4591 VJJ0673 DV TERMINAL
P4591 K1KA05A00259 CONNECTOR 5P
VEP06F11A SIDE (R) C.B.A.
FP6701 K1MN50B00014 CONNECTOR 50P
FP6702 K1MN26A00043 CONNECTOR 26P
FP6703 K1MN21B00033 CONNECTOR 21P
P6701 K1KA02B00051 CONNECTOR 2P
P6702 K1KA02B00051 CONNECTOR 2P
R6701 ERJ6GEY0R00V M.RESISTOR CH
1/10W 0
R6702 ERJ6GEY0R00V M.RESISTOR CH
1/10W 0
R6705 ERJ6GEY0R00V M.RESISTOR CH
1/10W 0
R6906 ERJ6GEYG102 M.RESISTOR CH
1/10W 1K
R6907 ERJ6GEYG102 M.RESISTOR CH
1/10W 1K
R6908 ERJ6GEYG102 M.RESISTOR CH
1/10W 1K
S6701 VSP1102 SWITCH
VZ6707 VRT0158 TRANSIENT/SURGE
ABSORBER
VZ6708 D4ED1270A008 TRANSIENT/SURGE
ABSORBER
VZ6709 D4ED1270A008 TRANSIENT/SURGE
ABSORBER
VEP26254D MONITOR C.B.A.
C903 ECST0JY106R T.CAPACITOR CH
6.3V 10U
C906 ECUX1E471KBQ C.CAPACITOR CH 25V
470P
C907 ECJ2YB1A105K C.CAPACITOR CH 10V
1U
C908 ECJ2YB1A105K C.CAPACITOR CH 10V
1U
C909 ECJ2YB1A105K C.CAPACITOR CH 10V
1U
C910 ECJ0EB1A104K C.CAPACITOR CH 10V
0.1U
C911 ECUX1E471KBQ C.CAPACITOR CH 25V
470P
C913 ECUX1E471KBQ C.CAPACITOR CH 25V
470P
C916 ECJ2YB1A105K C.CAPACITOR CH 10V
1U
C917 ECJ2YB1A105K C.CAPACITOR CH 10V
1U
C918 ECJ2YB1A105K C.CAPACITOR CH 10V
1U
C921 ECJ2YB1A105K C.CAPACITOR CH 10V
1U
C923 ECUM1C106VB C.CAPACITOR CH 16V
10U
C927 ECJ2VB1E104K C.CAPACITOR CH 25V
0.1U
C929 ECUX1E152KBQ C.CAPACITOR CH 25V
1500P
C931 ECJ2YB1A105K C.CAPACITOR CH 10V
1U
Remarks Ref.
No.
C932
D4ED12710002
C934
D4ED12710002 C935
C937
C938
K1FA104A0011
C939
C940
(RTL)
C941
C942
C943
C944
C945
D0GBR00JA017
C946
D0GBR00JA017
C947
D0GBR00JA017
C948
C950
C952
C953
D903
K0H1BA000260
D904
D905
D4ED12710002
D906
D908
FP901
FP903
(RTL)
IC901
IC902
IC908
IC991
L901
L905
Q901
Q902
Q903
Q905
Q906
QR901
QR902
QR903
QR904
QR905
R901
R903
R904
R907
57
Part No. Part Name &
Description
ECJ3YB1E105K C.CAPACITOR CH 25V
1U
F1J1C105A091 C.CAPACITOR 16V 1U
ECUM1C106VB C.CAPACITOR CH 16V
10U
ECJ0EB1A104K C.CAPACITOR CH 10V
0.1U
ECJ0EC1H101J C.CAPACITOR CH 50V
100P
ECUX1H331GCV C.CAPACITOR CH 50V
330P
ECJ0EC1H560J C.CAPACITOR CH 50V
56P
F1G1H100A448 C.CAPACITOR 50V
10P
ECJ2YB1C474K C.CAPACITOR CH 16V
0.47U
ECJ1VB1A224K C.CAPACITOR CH 10V
0.22U
ECJ1VB1A224K C.CAPACITOR CH 10V
0.22U
ECUX1E332KBQ C.CAPACITOR CH 25V
3300P
ECUM1C106VB C.CAPACITOR CH 16V
10U
ECJ1ZB1C104K C.CAPACITOR CH 16V
0.1U
ECJ1ZB1C104K C.CAPACITOR CH 16V
0.1U
F1J1C105A091 C.CAPACITOR 16V 1U
ECJ2VB1E104K C.CAPACITOR CH 25V
0.1U
ECUX1C103KBQ C.CAPACITOR CH 16V
0.01U
MA132WA DIODE
MA4X159A0L DIODE
MA6S121 DIODE
MA2J11100L DIODE
02DZ6.2YTPH3 DIODE
VJS3320B024 CONNECTOR (FEMALE)
24P
K1MN25B00033 CONNECTOR 25P
AN2540FHQ-V IC
TC4W53FU IC
SN74LV04APW IC
DN8797MS HOLE IC
VLQ0807K100 COIL 10UH
VLQ0807K100 COIL 10UH
HN1C01FUYR TRANSISTOR
B1DFCG000004 TRANSISTOR
B1HFCFA00010 TRANSISTOR ARRAY
B1HFCFA00010 TRANSISTOR ARRAY
2SB1462 TRANSISTOR
UNR9210J0L TRANSISTOR-
RESISTOR
UN9214J TRANSISTOR-
RESISTOR
UN9214J TRANSISTOR-
RESISTOR
UNR9210J0L TRANSISTOR-
RESISTOR
UN9212 TRANSISTOR-
RESISTOR
ERJ3GEY0R00A M.RESISTOR CH
1/16W 0
ERJ3GEYJ153 M.RESISTOR CH
1/16W 15K
ERJ3RBD622 M.RESISTOR CH
1/16W 6.2K
ERJ3GEY0R00A M.RESISTOR CH
1/16W 0
NV-MD9000EN
Remarks
MA3S132D
MA6Z121
B0BC6R100014
K1MN24B00036
K1MN25B00034
C0JBAR000226
C0JBAB000247
G1C100K00024
G1C100K00024
B1HBCFA00001
2SB14620R
UNR9212
