- Page 1 JPD-HA200 Electronic Blood Pressure Monitor User Manual Version: V1. 0 Date of revision: January 2019...
- Page 2 Foreword Dear user: Thank you for purchasing our Electronic Blood Pressure Monitor. Please read this manual carefully and use correctly. Please keep the user manual properly for checking and reference at any time .The Electronic Blood Pressure Monitor is suitable for adults. Product Profile The full name of the product is electronic blood pressure...
-
Page 3: Table Of Contents
Contents 1、Unpacking Inspection............- 1 - 2、Packing List................- 1 - 3、After-sales Service............... - 1 - 4、Safety Precautions..............- 2 - 5、Product Composition............- 3 - 6、Intended for Use..............- 3 - 7、Product Parts.................- 3 - 8、Installation Before Use............- 4 - 9、Function Setting Mode............- 6 - 10、Method for Correct Use............- 9 - 11、General Knowledge of Blood Pressure...... -
Page 4: 1、Unpacking Inspection
Quantity Electronic blood pressure monitor Cuff User manual 3、After-sales Service After-sales service unit: Shenzhen Jumper Medical Equipment Co., Ltd. Address: D Building, No. 71, Xintian Road, Fuyong Street, Baoan, Shenzhen ,Guangdong,China Tel: +86-755-26692192, 26696279 Fax: +86-755-26852025 Website:www.jumper-medical.com Postal Code: 518103... -
Page 5: 4、Safety Precautions
Authorized European Representative: Wellkang Ltd Suite B, 29 Harley Street , London W1G 9QR,UK 4、Safety Precautions The warnings and illustrations shown in the manual are intended to enable you to use the product safely and correctly, thus preventing harm to you and others, specific meanings of which are shown as follows: Legend, mark and meaning Warning information... -
Page 6: 5、Product Composition
5、Product Composition This product is composed of host machine and cuff of an electronic blood pressure monitor. 6、Intended for Use The electronic blood pressure monitor is intended to measure the systolic pressure and diastolic pressure, as well as the pulse rate of adult person via non-invasive oscillometric technique at medical facilities or at home. -
Page 7: 8、Installation Before Use
(2) Display screen User icon Low battery icon Date / time display Unit Systolic pressure Blood Pressure Diastolic pressure Level Indicator Heartbeat icon Memory icon Memory Number Pulse Arrhythmia Average value Symbol 8、Installation Before Use (1) Install the battery Open the battery cover and install the batteries in the battery compartment. - Page 8 a) Open the battery cover according to the method shown in the figure (as shown in the above figure) b) Place 4 AAA dry batteries in the battery compartment, and pay attention to the electrode indication of the batteries. Install the battery as indicated in the picture right under this sentence.
-
Page 9: 9、Function Setting Mode
external power supply through a USB interface. (4) Cuff The applicable arm circumference rang of the cuff is 22-36cm or 22-42cm. Connection: Insert the air plug on the cuff into the air jack on the left side of the electronic blood pressure monitor. As shown in the following figure : -The cuff is the application part. - Page 10 (Note: In the shutdown state, press "User " key to view the current time and the current user) (2) Year & month / Date setting In the shutdown state, press the "User " key for 3 seconds to enter the setting mode. Press the "User "...
- Page 11 (3) Talking function setting (voice version only) After entering talking function setting mode, " " will show up at the SYS area, with the current voice status " " / " " and voice icon (not displayed, when talking function mode is off) at the DIA area. Press the "Memory "...
-
Page 12: 10、Method For Correct Use
(4) Unit display setting After entering the unit setting mode, the SYS area will display " " and unit area will display mmHg, it means the unit mmHg is selected (system default unit: mmHg), At this time, press of the "Memory "... - Page 13 --Comparative blood pressure measurement must be carried out under the same conditions! Generally, the measurement should be carried out in a quiet environment! --Exert strengths on the arm may increase your blood pressure, so make sure you're in a comfortable and relaxed state before measurement, and do not exercise the muscles of the arm during the measurement.
- Page 14 make the cuff air plug point to the lower arm. 3. Apply the cuff to upper arm to ensure that the lower edge of the cuff is 2-3 cm from the elbow and the air tube is located at the inner side of the arm. 4.
- Page 15 (5) Starting measurement Start measurement after wearing the cuff: 1. Press the "On / Off " key, the machine will automatically return to zero. The air pump starts to inflate the cuff, and the change of air pressure in the cuff will be displayed on the screen.
- Page 16 inflation/automatic deflation, press the "User " key and the "Memory " key, there will be no response. ※In the measurement process, press the "On / Off " key to turn off the machine. ※ The automatic shutdown time starts after the value of the measurement is displayed.
-
Page 17: 11、General Knowledge Of Blood Pressure
of the current user are deleted. 11、General Knowledge of Blood Pressure (1) General knowledge of blood pressure-definition of blood pressure Blood pressure is the pressure that the blood is transmitted to the artery through the heart beat (systole and diastole). When systole, the pressure at which the blood is transmitted to the artery is called systolic pressure, i.e. - Page 18 WHO standard blood pressure values are shown below. Hypotension has not been defined. It is generally considered that high pressure lower than l00mmHg (13. 3kPa) is defined as hypotension. 12、Contraindications, Precautions, Warnings and Prompt Instructions (1) Warnings: Do not let a child below 12 years old and the people who can’t express one’s intention .When it used by the people of 12~18 years old ,it should accompanied by the - 15 -...
- Page 19 adult .This device has not been tested for use by pregnant women . Make sure there is no connection tubing kinking before start measuring to avoid can not be measured or other injury. For any patient, do not measure more than 3 times continuously, it should be at least above 5 minutes of interval rest between any two measurements,otherwise will cause extravasated blood.
- Page 20 For those with peripheral circulation disorder caused by certain diseases, there might be significant difference in the blood pressure value measured on the wrist and upper arm; Do not make measurements in 1h after meals or immediately after strenuous exercise, shower, smoking, alcohol drinking, coffee drinking or black tea drinking;...
- Page 21 Please do not use mobile phone, computer,electric kettle and the other can cause interference device around the device.Please do not use the device around the magnetic field. Please keep to maintain the device ,during use it. (2) Precautions: Do not repair, disassemble or modify the electronic blood pressure monitor without permission;...
- Page 22 Do not touch the host when measurement; Remove the battery when the product is left unused for a long time; Do not store the electronic blood pressure monitor in a place with high temperature, moisture or direct sunlight; Calibrate the electronic blood pressure monitor periodically.
-
Page 23: 13、Common Q & A On Blood Pressure
In case of rescue of seriously ill patients, diagnosis of hypertension and direction of hypertensive medication, use the electronic blood pressure monitor with caution. Keep the power supply enough. After product packaging, it is allowed to use common vehicle transportation, but rain, moisture, squeezing or mechanical collision should be avoided. - Page 24 3. The cuff is rolled too loose. If the cuff is rolled too loose, If the cuff is rolled too loose, the compression force might fail to be transmitted to the artery, resulting that the measured blood pressure value is higher than the actual value.
-
Page 25: 14、Abnormal Phenomena And Handling
to obtain the correct blood pressure value by measurement only once. Please make measurement for 2~3 times. The first measurement will generally be higher due to nervousness or inadequate preparation, and then when the second measurement, the nervous emotion will be slightly alleviated, so generally, the second measurement will be 5mmHg-10mmHg (0.7kPa-1.3kPa) lower than the first time. - Page 26 SYS area, signal is too weak. Please check the cuff, tie it up and try again 1 is displayed in the DIA area Err is displayed in the high The blood pressure signal cannot SYS area, be detected due to too much noises. Please remove the noise sources 2 is displayed in the and measure again...
-
Page 27: 15、Cleaning And Disinfection
Install in Are the positive and accordance with negative poles of the the positive and batteries reversed? negative poles of the batteries Insert the tracheal Is the tracheal plug plug into the bore tight? tightly No pressure Is the trachea broken Buy a new cuff or leaking? Keep your arms... - Page 28 clean soft cloth. 3) The body can be wiped using a soft and clean cloth with a small amount of neutral cleaner or water. Do not use corrosive detergents. During the cleaning, be careful not to immerse any part of the blood pressure monitor in the liquid to prevent liquid from flowing into the machine.
-
Page 29: 17、Precautions For Keeping
50 -104 ), relative humidity: 15%~80%RH, non-condensing, atmospheric pressure: 70kPa~106 kPa. 16、Upkeep and Maintenance - Always keep the surface of Blood Pressure Monitor clean and tidy, helpful to prolong the service life of Blood Pressure Monitor. - If the host is dirty, please wipe with a dry soft cloth. -
Page 30: 18、Product Specification
If you fail to observe the above precautions and other proper usage methods to cause machine failure, the company will not be responsible for the quality issues. 18、Product Specification Product name Electronic Blood Pressure Monitor Model JPD-HA200 Display mode Digital display Measuring Oscillographic method method Measuring... - Page 31 Pulse Pulse rate per minute, showing three digits Memory 99 groups of measurement data for each of two capacity users 4 AAA dry batteries or DC 5V USB external Power supply power supply Power Manual shutdown / 30s delayed automatic mode shutdown Body weight...
-
Page 32: 19、Statement Of Electromagnetic Compatibility
The Model JPD-HA200 Electronic Blood Pressure Monitor is intended for use in the electromagnetic environment specified below.The customer or the user of the Model JPD-HA200 Electronic Blood Pressure Monitor should assure that it is used in such an environment. Emissions... - Page 33 The Model JPD-HA200 Electronic Blood Pressure Monitor is intended for use in the electromagnetic environment specified below.The customer or the user of The Model JPD-HA200 Electronic Blood Pressure Monitor should assure that it is used in such an environment. Immunity...
- Page 34 AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy.To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the Model JPD-HA200 - 31 -...
- Page 35 Model JPD-HA200 Electronic Blood Pressure Monitor The Model JPD-HA200 Series Electronic Blood Pressure Monitor is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the Model JPD-HA200 Series Electronic Blood Pressure Monitor...
- Page 36 Shenzhen Jumper Medical Equipment Co., Ltd. Address: D Building, No. 71, Xintian Road, Fuyong Street, Baoan, Shenzhen ,Guangdong, China Tel: +86-755-26692192, 26696279 Fax: +86-755-26852025 Website:www.jumper-medical.com Postal Code: 518103...
