MaxLite ML2LA A Series Operating Instructions Manual

4.02"
Operating Instructions
15.04"
MaxLite LED ARCHITECTURAL CCT SELECTABLE
®
General Safety Information
• To reduce the risk of death, personal injury or property damage from fire, electric
shock, falling parts, cuts/abrasions, and other hazards read all warnings and
instructions included with and on the fixture box and all fixture labels.
• Before installing, servicing, or performing routine maintenance upon this equipment,
follow these general precautions.
• Commercial installation, service and maintenance of luminaires should be performed
by a qualified licensed electrician.
• For Residential installation: If you are unsure about the installation or maintenance
of the luminaires, consult a qualified licensed electrician and check your local
electrical code.
• DO NOT INSTALL DAMAGED PRODUCT!
• This fixture is intended to be connected to a properly installed and grounded UL listed junction box.
WARNING:
• Risk of Fire - Supply conductors (power wires) connecting the fixture must be rated minimum 90℃.
If uncertain consult an electrician.
• Risk of Fire/Electric Shock - If not qualified, do not attempt installation. Contact a qualified electrician.
CAUTION:
• For your safety read and understand instructions completely before starting installation.
• To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or other sharp objects.
• Before attempting installation, check your local electrical code, as it sets the wiring standards for your
locality.
NOTES:
• If luminaire (fixture) is to be switched from a wall switch, make sure black power supply wire is connected to
the switch. DO NOT connect the white supply wire to the switch.
• Make certain no bare wires are exposed outside the wire nut connectors.
• Do not make or alter any open holes in an enclosure of wiring or electrical components during kit
5.12"
installation.
• Warranty is not applicable to lamps not installed in compliance with:
- National Electrical Code (NEC)
- The Standard for Safety of Underwriters Laboratories Inc. (UL)
SERIES: ML2LAxA CCT SELECTABLE
Operating Temperature: -20°C to 40°C Damp Location Rated
PRODUCT DIMENSIONS:
4.76"
3.43"
120V
15.87"
120-
4.29"
277V
