- Page 1 10ml Size Manual Syringe Gun USER GUIDE...
- Page 2 Our dispensing gun systems are built and pre-assembled using high quality parts to ensure that your time is spent where it belongs, on productivity. The TS710SG is built to accept most 10ml size syringe barrels. You can use pre-filled 10ml barrels containing fluids such as solder paste, flux, silicone, RTV, grease and PVA or use empty barrels from us and fill yourself.
-
Page 3: Table Of Contents
We strive to develop strong partnerships by delivering cost effective solutions that provide savings in assembly time and raw materials. So your confidence and trust in Adhesive Dispensing Ltd is of the utmost importance to us. S.L Kerr Technical Manager of Adhesive Dispensing Ltd Meets applicable CE requirements. -
Page 4: Specifications
Specifications Capacity: 10ml (10cc) Initiation: Manual Trigger Dispenser Gun Materials: Polypropylene, nylon, EPR O-ring Colour: Red body, white trigger and flange Length: Polypropylene, nylon Height: 135 mm Weight: 110 gram (without filled syringe) -
Page 5: First Steps
First Steps Step 1: Unpack the shipping box and use the supplied delivery note to make sure all items are present. If any items are missing or damaged, please contact us immediately. Step 2: Ensure the area where you are setting up the equipment is clean and follow safety procedures of your adhesive Material Safety Data Sheet for safe handling. -
Page 6: Reservoir Filling
Setup Continued Assemble Syringe: If your adhesive is supplied in a pre-filled 10ml syringe, please skip this step. When using our industrial syringe barrels, take an empty 10ml size and attach a luer lock tip cap seal. Fill the syringe with your adhesive or paste. Take care not to overfill because material will ooze from the tip when the tip cap is removed. -
Page 7: Component Selection Guide
Disposable Reservoir System Five sizes, three colours and two types of syringe barrels/pistons make up the 700 series reservoir system for quality dispensing of all kinds of assembly fluids. For samples, recommendations and immediate customer service: 0845 652 0058 www.adhesivedispensers.co.uk Syringe barrel &... -
Page 8: Component Selection Guide
Precision Dispense Tips All tips supplied in packs of 50 unless specified. Tapered tips gauge standard colour opaque rigid colour TTN14 Olive TTN14E Salmon TTN16 Grey TTN16E Grey TTN18 Green TTN18E Green TTN20 Pink TTN20E Pink TTN22 Blue TTN22E Blue TTN25 TTN25E TTN27... -
Page 9: Troubleshooting
Check the rod for damage and/ or residue adhesive cured. Clean and replace. If damaged, replace rod. Contact Adhesive Dispensing Ltd if faulty gun. Syringe Barrel Does Not Fit Use only syringes 7100LL1NPK, 7100LL1BPK, 7100LL1DPK, 910-N, 910-B and 910-D. -
Page 10: Warranty
Warranty One Year Limited Warranty Adhesive Dispensing Ltd (ADL) warrants its product to be free from defects in materials and workmanship for a period of one year from the date of purchase. Under this warranty, ADL will repair or replace any defective part or, at its own option, the complete value regardless of fault.
