- Page 1 Precision Fluid Dispenser TS9150 USER GUIDE Sales and service www.adhesivedispensers.co.uk info@adhesivedispensers.co.uk Tel. +44 (0) 1908 686660 Fax. +44 (0) 1908 686836...
- Page 2 The TS9150 fluid dispenser provides many years of trouble-free, productive service. This Operating Guide will help you maximize the usefulness of your new dispenser. Please spend a few minutes to become familiar with the controls and features of your new dis- penser.
-
Page 3: Table Of Contents
Contents Initial Steps One: Unpack and use the checklist enclosed with the Dispenser Kit to identify all items. If there is any discrepancy, please call us immediately. Two: Power and compressed air should be available where the dispenser is to be set up. Air pressure should be between 80 and 100 psi (5.5 and 6.9 bar). - Page 4 Foot pedal assembly Air input hose Power cord Mains air, 100 psi max Check voltage label on dispenser Adapter assembly Male quick-connect, insert and twist to lock Sales and service www.adhesive-dispensing.co.uk info@adhesivedispensers.co.uk...
-
Page 5: Connection
Connection ❶ Connect the air input hose to a plant air source. Set mains air supply within 80 to 100 psi (5.5 to 6.9 bar). Where required, use an ADL five-micron filter regulator #TSD800-6. ❷ Push the air input hose in to the dispenser. Standard 6mm OD hose push fit. ❸... - Page 6 Controls and Connections Sales and service www.adhesive-dispensing.co.uk info@adhesivedispensers.co.uk...
-
Page 7: Setup For Testing
Setup for Testing Power switch ❶ should be off. The amount of material dispensed each cycle depends on the combination of air pressure, time of air pulse, viscosity of material and dispensing tip size. Note: For watery liquids and Cyanoacrylates, refer to “Making Timed Deposits of Watery-thin Flu- ids”... -
Page 8: Making Timed Deposits Of Medium To Thick Fluids
Making Timed Deposits of Medium to Thick Fluids You are now ready to test the dispenser with a thick, non-levelling fluid such as a sealant, paste or grease. Check your initial settings: A) Air gauge reads 30 psi. B) Timer is set at number 7. C) Green tapered tip is on the test barrel. -
Page 9: Programmable Timer
Programmable Timer Each TS9150 dispenser has a rotary timer with adjustable time ranges. The DIP switch that controls the timer has been set at the factory for a time range of 0.01 to 1.0 second, with the initiation set to MOMENTARY contact. -
Page 10: How To Use The Vacuum Control
How to Use the Vacuum Control Making Timed Deposits of Watery-thin Fluids The vacuum control allows low viscosity fluids, even water, to be consistently dispensed without drip- ping between cycles. The vacuum places a negative pressure on the fluid in the barrel and prevents dripping. - Page 11 If you choose not to use the piston, please follow these in- Some things to remember structions carefully: If you do not use the piston when dispensing thin fluids: 1. While holding the barrel upright in one hand, twist on an or- ange, black or white tip cap.
- Page 12 For Thick Fluids If you dispense thick fluids, several problems may occur. First, the repetitive air cycles can bore tunnels through non-levelling fluids, causing spitting and inconsistent deposits. Second, thick fluids contain trapped air that leads to drooling and oozing. These problems are eliminated by using the PE piston.
- Page 13 For Thinner Fluids If you use low to medium viscosity fluids, the white PE piston has several advantages. First, vacuum adjustment is much less sensitive. Second, the piston prevents fumes from the fluid being exhausted into the work environment. Third, the piston prevents fluid backflow into the dispenser if the barrel is inadvertently turned upside down.
- Page 14 For Cyanoacrylates and Solvents Caution: Do not completely fill barrels. The optimum fill is a maximum 2/3 of the barrel capacity If the fluid you are dispensing is pourable, take the barrel, twist on a tip cap and pour your fluid in. If appropriate, insert the PE piston (see page 13).
- Page 15 We offer productive alternatives to traditional barrel loading methods. Here are a few sug- gestions that can help keep your work area clean, save time and reduce the chance of en- trapped air in the fluid. 1. You could use the ADL #TS900-12- barrel loader.
-
Page 16: Troubleshooting
Troubleshooting 1. Check voltage at wall outlet. NO POWER 2. Check fuse. Replace fuse. 3. Unplug from wall, remove top cover, visually inspect for any loose or shorted connections. Module must be replaced. POWER, BUT NO LIGHT 1. Unplug power input cord. POWER, LIGHT, BUT 2. -
Page 17: Suggestions & Reminders
Suggestions & Reminders 1. Always use an ADL piston to make your barrel loading, dispensing and handling cleaner, safer and more accurate. Caution: If you dispense watery-thin fluids and choose not to use white PE pistons – do not increase vacuum pressure rapidly and do not tip the barrel. Vacuum may pull liquid into the air hose;... - Page 18 ADL Components Tapered tips gauge standard colour opaque rigid colour TTN14 Olive TTN14E Salmon TTN16 Grey TTN16E Grey TTN18 Green TTN18E Green TTN20 Pink TTN20E Pink TTN22 Blue TTN22E Blue TTN25 TTN25E TTN27E Clear TTN27E Orange Precision stainless steel tips gauge 0.5”...
-
Page 19: Two Year Limited Warranty
Warranty ADL Two Year Limited Warranty All specified components of Adhesive Dispensing Ltd (ADL) dispensers are warranted to the original end user for two years from date of purchase. Within the period of this warranty, ADL will repair or replace free of charge any defective component on return of the part, or the complete dispenser, prepaid to the Warehouse. - Page 20 Adhesive Dispensing Ltd Unit 501 Milton Keynes Business Centre Foxhunter Drive, Milton Keynes, MK14 6GD, UK Tel. +44 (0) 1908 686660 Fax. +44 (0) 1908 686836 Main Switchboard. +44 (0) 1908 686661 www.adhesive-dispensing.co.uk email: info@adhesivedispensers.co.uk...
