Intec CVM Series Replacement Instructions page 3

Dimensional Charts and Reccomendations.
Your Monitor – Dimensions do not include the mounting bracket.
Monitor
CVM450LPP Series
CVM500
CVM550LPP
CVM600 Series
CVM700LPP Series
Your Camera - Flush Mount Dimensions
Camera
CVC110FM Series
CVC111FM Series
CVC112FM Series
CVC210FM Series
CVC120FM Series
You may also call us toll free at 800‐468‐3254 (West) or 800‐522‐5989 (East) or e‐mail support@intecvideo.com with any questions.
Dimensions
5" wide X 4 5/8" high
5" wide X 4 3/4" high
5 3/8" wide X 5 1/8" high
6 1/4" wide X 5 3/8" high
7 1/8" wide X 6 5/8" high
Cutout Dimensions
2" wide X 2" high
2" wide X 2 5/8" high
2" wide X 2 5/8" high
2 1/2" wide X 2 1/2" high
4" wide X 3 3/4" high
For additional information, please visit www.intecvideo.com/support.html
Recommended Display – Dimensions do not include the mounting bracket.
Display Dimensions
Outside 6 1/2" wide X 4 7/8" high
CVD500LCD
(Back bump out 5 3/4" wide X 4 1/8" high)
Outside 7 5/8" wide X 5 1/2" high
CVD650LCD
(Back bump out 6 3/8" wide X 4 1/4" high)
Recommended Camera - Flush Mount Dimensions
CVC400FM 2 1/2" wide x 2 3/4" high
CVC500AHFM *** 3 3/4" wide X 2 7/8" high
*** Requires the 313-02-02-002 adapter to connect this
camera to the main cable
