Intec CVM Series Replacement Instructions page 2

Single camera system

Advertisement

Item
Quantity
Part Number
1
1
CVDxxxLCD
2
1
CVDR5MA
3
1
CVR100
4
1
CVDC6MA
5
1
CVS100M
6
1
CVS100MP3M
7
1
CVU18M
8
1
CVC400(FM)
For CVC400 Series Option
10
For CVC500AH Series Option
Item
Quantity
Part Number
9
1
313-02-02-002
10
1
CVC500AH(FM)
Display Connection Detail
DISPLAY
CVD640LCD
Controller
Remote
Description
Car Vision Display
Optional Remote Extension Cable
Remote Control
Six Meter Display to Controller Cable
Controller – Molex Version
Power Harness for Molex Controller
Existing Coach Cable
M Series (Flush Mount) Camera
8
9
Description
Adapter – Cable to CVC500AH
H Series (Flush Mount) Camera
DISPLAY
VIDEO OUT/IN
2
3
7
See The Power Connection Table
Below For Wire Connection Details
Power Connection Table – CVS100
Color
Red
Black
Blue
Green
Controller Connection Detail
CAMERA
Upgraded System
4
6
Function
Power (+11 to +32 VDC)
Ground
Reverse Trigger (+11 to +32 VDC)
Source Alarm Out (Functional Only
with Optional Radar Component)
POWER
1
5
2
