- Page 1 Car Vision® System Utilizing the CVD650LCD So ware Version 1.0.5 ESG CVD650LCD-A So ware Version 1.0.5A ESG System User’s Guide © INTEC Video Systems, Inc. Revision F - August 2022...
-
Page 2: Table Of Contents
Table of Contents General Information Introduction What This Manual Covers Important Information Certifi cates of Compliance Warnings and Cautions Getting Started Turning On Your Car Vision® System Verifying Proper Image Orientation How to Change Your Image Orientation Adjusting the Screen Brightness Single or Dual Camera System Applications Using a CVS100 or CVS102 Series Controller Becoming Familiar with your CVR100 Remote Button Label and Function... - Page 3 Table of Contents Additional Features (CVS500) Trigger Sequencing Turn Signal Triggering Momentary Rear Camera Override Maintenance and Troubleshooting Preventative Maintenance Status LED’s and Fuses (CVS100 or CVS102) Status LED’s and Fuses (CVS500) Troubleshooting Service and Warranty How to get Service Warranty Policy Locations Page 3...
-
Page 4: General Information
Use only INTEC specifi ed and provided brackets and cables to connect the components of the system. Use of other than INTEC specifi ed and supplied brackets and cabling could be dangerous and result in damage to the system components and void the warranty. -
Page 5: Warnings And Cautions
fi re or electrical shock. When installing the system be sure to use only INTEC supplied brackets. The Car Vision® camera must be insulated from the vehicle body. The supplied camera bracket provides the required insulation. Failure to do so could result in a fi re and lead to property damage or personal injury. -
Page 6: Getting Started
How to Change Your Displayed Image Orientation INTEC’s CVC Series cameras are set as default at the factory to display a Mirror image when used with our CVD Series displays. Should you need to change the default image, you can do so through the displays on screen Installers Menu. -
Page 7: Single Or Dual Camera System Applications Using A Cvs100 Or Cvs102 Series Controller
Single or Dual Camera System Applications using a CVS100 or CVS102 Series Controller Becoming Familiar with your CVR100 Remote All adjustments to your Car Vision® system are made via the CVR100 remote control. For your convenience the buttons on the remote are backlit to aid in use under low light conditions. The CVR100 remote also includes a speaker for audio equipped systems and serves to provide an audible alert when the system is used in conjunction with our active radar component. -
Page 8: Navigating The On Screen Display Menu (Cvs100 Or Cvs102)
Navigating the On Screen Display Menu (CVS100 or CVS102) There are three menus available when using a CVS100 or CVS102 controller, the Help Menu, the User Menu and the Installer Menu. The Help Menu explains the buttons used to navigate the menu. The User Menu allows you to adjust menu items associated with the image such as brightness, contrast, etc... -
Page 9: Installer Menu
Set to STD for standard radar, set to CAN for all others. RADAR 1 Note: Radar 1 connects to the camera input via an INTEC cable and is only active when triggered. Turns the Radar Alarm Output function off and on. See the... -
Page 10: Advanced Features (Cvs100 Or Cvs102)
TRUE. Note: Not available in EXT. Not all cameras are fi eld reversible and may need to be returned to INTEC to have the image reversed. Please contact INTEC for additional information. -
Page 11: One To Five Camera System Applications Using A Cvs500 Series Controller
One to Five Camera System Applications using a CVS500 Series Controller Becoming Familiar with your CVR500 Remote All adjustments to your Car Vision® system are made via the CVR500 remote control. For your convenience the buttons on the remote are backlit to aid in use under low light conditions. The CVR500 remote also includes a speaker for audio equipped systems and serves to provide an audible alert when the system is used in conjunction with our active radar component. -
Page 12: Navigating The On Screen Display Menu (Cvs500)
Navigating the On Screen Display Menu (CVS500) There are three menus available when using the CVS500 controller, the Help Menu, the User Menu and the Installer Menu. The Help Menu explains the buttons used to navigate the menu. The User Menu allows you to adjust menu items associated with the image such as brightness, contrast, etc... -
Page 13: Installer Menu
Mirror image. Thru CAMERA 5 “TRUE” Displays the image from an INTEC camera on the screen as a True image. Note: CAMERA 1 thru CAMERA 5 are the default names assigned to each of the fi ve camera inputs. You have the option of changing those input names on Page 3 of the Installer Menu. - Page 14 Installer Menu Continued Page 3 - Input Name Sets the displayed name for the selected position. 0 thru 9, A thru Z and a number of special characters, INPUT 1 including a Space, are available. Names can be up to 8 Thru characters in length.
- Page 15 Installer Menu Continued Page 6 - Output Cycle (Active only when CYCLE is selected as one of the Video Outputs) INPUT 1 Adjusts the time (0 to 20 Seconds) the camera input will Thru be displayed. INPUT 5 Note: If all positions are set to “0” the output cycle EXT IN function will be disabled.
-
Page 16: Advanced Features (Cvs500)
TRUE. Note: Not available in EXT. Not all cameras are fi eld reversible and may need to be returned to INTEC to have the image reversed. Please contact INTEC for additional information. -
Page 17: Multi Display Camera View
Multi Display Camera View There are 4 multi display camera views available. They are; Quad, Tri Up, Tri Low, and Dual. The multi display camera views are fully programmable through the on-screen menu and allow you to select which camera position(s), 1 – 5, are displayed in each view. Setting a camera positions to “E” will eff ectively turn that position off . Setting all camera positions to “E”... -
Page 18: Programmable Auto Camera Cycle
Programmable Auto Camera Cycle The Auto Cycle allows the user to select dwell time intervals from 0 to 20 seconds for each camera position, including external video in. They will be displayed on the screen for the preset period of time before cycling to the next camera position. -
Page 19: Integrated Active Object Detection (Radar)
fl ash according to the detected object’s distance from the sensor as shown below. The integrated radar is available for camera positions 1 and 2, and will operate only when connected via an INTEC cable to either of those positions on the controller. Radar 1 is activated via a +11 to +32 VDC source applied to the blue trig- ger wire of the controller’s power harness. -
Page 20: Additional Features (Cvs500)
Additional Features when used with a CVS500 Controller Trigger Sequencing Camera 1 through 5, Multi Display and Cycle triggers follow a priority sequence with camera 1 having the highest priority followed by camera 2 and so on until the Cycle trigger, with the Cycle trigger having the lowest priority. The following chart shows the priority sequencing. -
Page 21: Maintenance And Troubleshooting
Repairing the source of where the moisture is coming into the camera is the only way to prevent it from happening again. The camera should be returned to INTEC for service. 5. Damage to the cable and the connector seal. This includes the main cable as well as the camera and monitor pigtails. -
Page 22: Status Led's And Fuses (Cvs100 Or Cvs102)
There is also a spare 2 Amp fuse. INTEC strongly recommends using only properly rated fuses at all times. In addition the CVS100 is equipped with internal auto reset fuses for camera and display power. These fuses are designed to open in the event of a short in the camera, display, remote or associated cabling if the external fuse fails to blow. -
Page 23: Status Led's And Fuses (Cvs500)
There is also a spare 5 amp and a spare 2 Amp fuse. INTEC strongly recommends using only properly rated fuses at all times. In addition the CVS500 is equipped with internal auto reset fuses for camera and display power. These fuses are designed to open in the event of a short in the camera, display, remote or associated cabling if the external fuse fails to blow. -
Page 24: Service And Warranty
INTEC. A Return Materials Authorization (RMA) number will be issued. Refer to this number during any future contact with INTEC concerning this service. -
Page 25: Warranty Policy
Cables CVU/UP/H/XL/XLP/TT This limited warranty is void and does not cover product that has been lost or at the sole determination of INTEC has been damaged in shipment, subjected to misuse, abuse, tampering, neglect, accident, improper installation, use on improper voltage or current, use contrary to operating instructions, or disassembly, repair, or alteration by anyone other than INTEC or an INTEC authorized service agent.
