USER'S MANUAL
Thank you for purchasing this PIVOT product. Please read this manual carefully
before installation and use. Please keep this manual for future reference.
If this product is given to another user,
make sure to include this User's Manual.
Contents
Contents / WARNING / CAUTION ............... 1
Features................................................... 1
Part Names and Functions ........................ 1
Connecting The Wires................................. 2
Connection for Cylinder Number Setting ...... 3
Fastening The Product .............................. 4
Basic Operation ....................................... 4
Troubleshooting ....................................... 4
• Do not work in areas where there
is excessive exhaust.
Due to vehicle exhaust emission
WARNING
p oisoning or fire may result in a
damage to humans.
Improper use or disre-
• Do not operate while driving.
gard of these warnings
Operating or checking the display
may result in the injury
during driving may cause an acci-
or death of people.
dent; please use with the utmost
consideration for safety.
• Do not use electrotap.
Wiring should be carried out using the
attached "Cut Connector" or by solder-
CAUTION
ing, make sure to securely insulate all
wiring parts with insulation tape, and
confirm that no wires are sticking out.
Improper use or disre-
gard of these warnings
•This product is for DC12V cars.
may cause injury to per-
Installation cannot be carried out on
sons, damage the prod-
cars with other voltage batteries.
uct and / or other things.
• Do not , in any manner, process,
take apart, or make changes to this
product.
Features
The PT5-X displays RPM immediately without Opening
Demo upon engine start after Stop-Start function.
Compatible with Stop-Start system model cars
Display RPM without Opening Demo upon engine star t after
Stop-Start function.
Note: It's also compatible with non Stop-Start system
models.
From Eco to Sports
From eco to sports; getting accurate RPM readings is a must.
Compatible with wide range
Compatible with 1-, 3- and 4-cylinder cars including Stop-Start
model cars. [12V]
Easy Installation
Fastening with double-sided tape in various places by the Band
Holder.
Translucent Illumination
The translucent LED system provides a clear display.
(
Product Number :
)
PT5-X
Product
Please check the contents of the package
Meter
Adjustable Stand
Cushion
Allen Wrench
Tape
• During installation be sure to remove
the minus cable from the battery.
So as to prevent fire and damage resulting
from shorting of circuits, etc...
• Do not crush the cable.
Please be careful that the cable dose not
get crushed by the seat rail or car door
steel plate, nor cut by any sharp steel plate
as this may cause a poor connection or an
electric short leading to fire or other danger.
• Just after installation do not exert any
strong force on the product.
When double-sided tape is used for an
installation be warned that when hot the
tape temporarily losses adhesiveness.
• Do Not Use Chemical Cleansers.
If the unit gets dirty please wipe with a
soft cloth to remove any dirt. Do not use
chemical cleansers such as thinner, ben-
zene, or alcohol.
• Make sure to replace all screws and
parts to their original place.
Part Names and Functions
2
Opening Demo
During the opening demo, the needle will move slightly to minus several
times. Then it will move to the maximum value and finally to reading for
current values.
Tachometer for Stop-
Start System Models
PROGAUGE
STEPPING DRIVE
TACHO METER
5-pin Power Cable
White Extension
with fuse 3A
Cut Connectors
Zip tie
×3
• Please securely fasten the product to
a stable place and be sure to store
bundle away all wires with tape, etc...
It is very dangerous to pull tangled wires
by force or allow tangled wires to inter-
fere with driving.
• Do not install the product in any place
subject to high temperature or any
place where water may be splashed.
• If you are not confident about doing
the wiring yourself, please consult
your local pro shop or garage.
When installing this product, we recom-
mend that if technical knowledge be-
comes necessary please consult a quali-
fied mechanic.
• Do not install the product in a place
where it will cause distraction.
6
7
8
9
5
4
X1000rpm
PROGAUGE
3
0
1
2
1
( PT5-X As of October 2016 No.1)
ø52
Double-sided
Wire
Tapes
Wiring Chart of
User's Manual
Rotation Signal
(This Book)
(in Japanese)
1
Needle
Show the RPM values.
2
Wide Scale Display
T h e d i s p l ay h a s b e e n
made easier to read by
enlarging the 500 to 7000
rpm area.
3
Illumination
(night illumination)
N o r m a l l y i l l u m i n a t e d
when on display.
