PMV Mounts PMVMOUNTCORNSH Mounting Instructions

pmvmounts

Mounting instructions for corner bracket shelf kit.

Shelf kit - Up to 5Kgs max per shelf
Model No.
PMVMOUNTCORNSH

Parts Inventory

A B
C
A
- Shelf hanger bracket x2
B
- Shelf hanger x2
C
- Metal shelf x2
Shelf Fixing Kit
D - M6 x 12mm
E - M5 x 12mm
.co.uk
Factory No.
Z0883SK
1

Attach shelf hanger brackets

Dx4
X8
X8
PLEASE READ THESE NOTES FIRST:
READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLING YOUR EQUIPMENT.
INSTALL THE WALL BRACKET IN A SUITABLE LOCATION USING FIXINGS WHICH ARE APPROPRIATE
FOR THE WALL MATERIAL AND STRUCTURE. CONSULT A QUALIFIED BUILDER IF YOU ARE IN ANY
DOUBT AS TO THE STRUCTURAL INTEGRITY OF THE WALL. WALL FIXINGS NOT INCLUDED.
DO NOT ATTEMPT TO ALTER OR MODIFY ANY PART OF THE WALL MOUNT OR IT'S ATTACHMENTS.
DO NOT USE IF ANY PARTS ARE BROKEN OR APPEAR TO BE DAMAGED.
TIGHTEN ALL BOLTS AND FIXINGS SECURELY. ONLY USE FIXINGS PROVIDED WITH THIS BRACKET.
DO NOT MOUNT YOUR TV NEAR TO SOURCES OF HEAT OR MOISTURE.
ALWAYS HAVE A MINIMUM OF TWO PERSONS TO INSTALL THE WALL BRACKET AND TV.
NOTE FOR USING BRACKET:
For instructions on assembling and fitting bracket please refer to instruction sheet included in bracket package.
2

Attach shelf hangers

Dx4
