PILOT'S CHECKLIST
SR20
WITH CIRRUS PERSPECTIVE + AVIONICS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR20 and is the answer not in the manual?

Questions and answers

Related Manuals for Cirrus SR20

Summary of Contents for Cirrus SR20

  • Page 1 PILOT’S CHECKLIST SR20 WITH CIRRUS PERSPECTIVE + AVIONICS...
  • Page 2 FAA Approved Airplane Flight Manual and Pilot’s Operating Handbook (POH) P/N 11934-005, Original Issue. These procedures do not supersede the procedures in the POH. In the event of conflict, the POH shall take precedence. COPYRIGHT © 2017 CIRRUS DESIGN CORPORATION DULUTH, MINNESOTA, USA ISSUED: March 2017 P/N 11935-006...

  • Page 3: Table Of Contents

    NORMAL PERFORMANCE ABNORMAL EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Normal Procedures Table of Contents Primary Flight Display ..............N-1 Airspeeds for Normal Operation ............N-2 Preflight Inspection ................N-3...

  • Page 4: Primary Flight Display

    NORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Primary Flight Display 125° LEGEND 1. True Airspeed TERM 2.

  • Page 5: Airspeeds For Normal Operation

    NORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Airspeeds for Normal Operation Takeoff: • Normal, Flaps 50%............ 71-75 KIAS •...
  • Page 6 NORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 SR22_FM04_1454 Preflight Inspection 1. Cabin a. Required Documents ..........ON BOARD b.
  • Page 7 NORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 o. Stall Warning..............TEST p. Pitot Heat ................ON (1) Verify probe is hot.
  • Page 8 NORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 5. Right Wing Trailing Edge a. Flap and Rub Strips (if installed) ....CONDITION AND SECURITY b.

  • Page 9: Preflight Inspection

    NORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 10. Nose, Left Side a. Cowling .......... ATTACHMENTS SECURE b.

  • Page 10: Starting Engine

    NORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Starting Engine 1. External Power (If applicable) ........CONNECT 2.

  • Page 11: Before Takeoff

    NORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Before Takeoff 1. Doors ................LATCHED 2. CAPS Handle ......... VERIFY PIN REMOVED 3.

  • Page 12: Normal Takeoff

    NORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Normal Takeoff 1. Brakes......RELEASE (STEER WITH RUDDER ONLY) 2.

  • Page 13: Cruise Leaning

    NORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Cruise Leaning Mixture Description Exhaust Gas Temperature Best Power 100 °F Rich Of Peak EGT Best Economy Peak EGT...

  • Page 14: Short Field Landing

    NORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Short Field Landing 1. Flaps..................100% 2. Airspeed ................78 KIAS 3.
  • Page 15 NORMAL PERFORMANCE ABNORMAL EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Performance Table of Contents Takeoff Distance: 3150 LB...............P-1 Takeoff Distance: 2600 LB...............P-2 Cruise Performance .................P-3 Cruise Performance .................P-4...

  • Page 16: Takeoff Distance: 3150 Lb

    PERFORMANCE C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Takeoff Distance: 3150 LB WEIGHT = 3150 LB Headwind: Subtract 10% for each 12 knots Approx.

  • Page 17: Takeoff Distance: 2600 Lb

    PERFORMANCE C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Takeoff Distance: 2600 LB WEIGHT = 2600 LB Headwind: Subtract 10% for each 12 knots Approx.

  • Page 18: Cruise Performance

    PERFORMANCE C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Cruise Performance Conditions: • Mixture ..................Target Fuel Flow* •...
  • Page 19 PERFORMANCE C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Cruise Performance ISA - 30°C ISA + 30°C Press RPM MAP PWR KTAS GPH PWR KTAS GPH PWR KTAS GPH 6000...
  • Page 20 PERFORMANCE C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Landing Distance Table - Flaps 100% WEIGHT: 3150 LB Headwind: Subtract 10% per each 13 Speed over 50 Ft Obstacle: 78 KIAS knots headwind.

  • Page 21: Landing Distance Table - Flaps 100

    PERFORMANCE C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Landing Distance Table - Flaps 50% WEIGHT: 3150 LB Headwind: Subtract 10% per each 13 Speed over 50 Ft Obstacle: 82 KIAS knots headwind.

  • Page 22: Landing Distance Table - Flaps 50

    PERFORMANCE C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Landing Distance Table - Flaps 0% WEIGHT: 3150 LB Headwind: Subtract 10% per each 13 Speed over 50 Ft Obstacle: 87 KIAS knots headwind.

  • Page 23: Wind Components

    PERFORMANCE C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Wind Components  Conditions: Example: (See Chart Wind/Flight Path Angle ....50° •...

  • Page 24: Weight And Balance

    PERFORMANCE C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Weight and Balance Loading Calculations For Moment/1000, refer to Loading Data table on following page. Description Weight Moment/1000...

  • Page 25: Loading Data

    PERFORMANCE C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Loading Data Use this table to determine the Moment/1000. Weight Baggage Fuel...

  • Page 26: Temperature Conversion

    PERFORMANCE C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Temperature Conversion To convert from Celsius (°C) to Fahrenheit (°F), find in the shaded columns the number representing the temperature value (°C) to be converted.
  • Page 27 NORMAL PERFORMANCE ABNORMAL EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Abnormal Procedures Table of Contents Perspective Crew Alerting System (CAS) Index CAS Message...
  • Page 28 EMERGENCY ABNORMAL PERFORMANCE NORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Abnormal Procedures Table of Contents PFD FAN FAIL Advisory .............A-7 MFD Cooling Fan Failure ............A-7 MFD FAN FAIL Advisory ............A-7...

  • Page 29: Flight Environment

    ABNORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Flight Environment Inadvertent Icing Encounter 1. Pitot Heat................... ON 2.

  • Page 30: Abnormal Landings

    ABNORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Abnormal Landings Landing With Failed Brakes One brake inoperative 1.

  • Page 31: Engine System

    ABNORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Engine System Low Idle Oil Pressure OIL PRESS Caution OIL PRESS 1.

  • Page 32: Fuel System

    ABNORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Fuel System Low Fuel Quantity FUEL QTY Caution FUEL QTY 1.

  • Page 33: Fuel Imbalance

    ABNORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Fuel Imbalance FUEL IMBALANCE Caution FUEL IMBALANCE 1. Fuel Quantity Gages............CHECK 2.

  • Page 34: Low Alternator 1 Output

    ABNORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Low Alternator 1 Output ALT 1 Caution (Failure) ALT 1 1.

  • Page 35: Integrated Avionics System

    ABNORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Integrated Avionics System Avionics Switch Off AVIONICS OFF Caution AVIONICS OFF 1.

  • Page 36: Pitot Static System

    ABNORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Pitot Static System Pitot Static Malfunction Static Source Blocked 1.

  • Page 37: Flight Control System

    ABNORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Flight Control System Electric Trim/Autopilot Failure 1. Airplane Control.......... MAINTAIN MANUALLY 2.
  • Page 38 ABNORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Landing Gear System Brake Failure During Taxi 1. Engine Power............AS REQUIRED •...
  • Page 39 NORMAL PERFORMANCE ABNORMAL EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Emergency Procedures Table of Contents Perspective Crew Alerting System (CAS) Index CAS Message...
  • Page 40 EMERGENCY ABNORMAL PERFORMANCE NORMAL C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Table of Contents Emergency Procedures FUEL QTY Warning ..............E-9 Fuel Imbalance ................E-9 Electrical System................E-10...

  • Page 41: Airspeeds For Emergency Operations

    EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Airspeeds For Emergency Operations Maneuvering Speed: • 3150 lb................133 KIAS •...

  • Page 42: Engine Failures

    EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Engine Failures Engine Failure On Takeoff (Low Altitude) 1.

  • Page 43: Airstart

    EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Airstart Engine Airstart 1. Bat Master Switches..............ON 2.

  • Page 44: Smoke And Fire

    EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Smoke and Fire Engine Fire In Flight 1. Mixture ................CUTOFF 2.

  • Page 45: Wing Fire In Flight

    EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Wing Fire In Flight 1. Pitot Heat Switch ..............OFF 2.

  • Page 46: Forced Landings

    EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Forced Landings Emergency Landing Without Engine Power 1. Best Glide Speed............ESTABLISH 2.

  • Page 47: Engine System

    EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Engine System Oil Pressure Out of Range OIL PRESS Warning OIL PRESS 1.

  • Page 48: High Cylinder Head Temperature

    EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 High Cylinder Head Temperature CHT Caution and Warning On-Ground 1.

  • Page 49: Fuel System

    EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Fuel System Low Fuel Quantity FUEL QTY Warning FUEL QTY 1.

  • Page 50: Electrical System

    EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Electrical System High Voltage on Main Bus 1 M BUS 1 Warning M BUS 1 1.

  • Page 51: High Or Low Voltage On Essential Bus

    EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 High or Low Voltage on Essential Bus ESS BUS Warning ESS BUS 1.

  • Page 52: Unusual Attitude

    EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Unusual Attitude Inadvertent Spin Entry 1. CAPS ................ACTIVATE Inadvertent Spiral Dive During IMC Flight 1.

  • Page 53: Caps Deployment

    EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 CAPS Deployment • WARNING • The maximum demonstrated deployment speed is 133 KIAS. 1.
  • Page 54 EMERGENCY C I R R U S P I L O T ’ S C H E C K L I S T M O D E L S R 2 0 Circuit Breaker Panel AVIONICS LIGHTS LANDING STDBY ALT2 LIGHTS ATTD B CONV...
