C I R R U S
A I R P L A N E M A I N T E N A N C E M A N U A L
1. DESCRIPTION
The wing is constructed in a conventional spar, rib, and shear section arrangement. The upper and lower
skins are bonded to the spar, ribs, and aft shear web forming a torsion box that carries all of the wing bend-
ing and torsion loads. The rear shear webs are similar in construction but do not carry through the fuse-
lage.
The wing spar is manufactured in one piece and is continuous from wing tip to wing tip. The wing spar
passes under the fuselage below the two front seats and is attached to the fuselage in two locations. Lift
and landing loads are carried by the single carry-through spar, plus a pair of rear shear webs (one on each
wing) attached to the fuselage. The wing spar is laminated epoxy/glass fiber (Serials 1005 thru 1885) or
laminated epoxy/carbon fiber (Serials 1886 & subs) in a C-section.
The wing's belly closeout panel is bonded (Serials 1005 thru 1422) or bolted (Serials 1423 & subs) to the
fuselage structure after wing attachment and provides a continuous load path along the bottom of the fuse-
lage.
EFFECTIVITY:
All
WING STRUCTURE
M O D E L S R 2 0
57-10
Page 1
15 Jun 2010
