PS Engineering IntelliPAX 11606 Installation And Operation Manual page 13

PMA8000E Dual Audio Panel Expansion
Pilot Audio Panel
J2
35
37
Expansion Unit #2
11636
See PMA8000D Installation Manual, Document 200-890-0304 for complete information
200-250-0005
PS Engineering, Inc.
IntelliPAX Expansion Unit
3
Expansion Audio Input
14
Expansion Lo
1
Expansion Power
Expansion Unit #1
11636
15
Expansion Audio Output (L)
2
Expansion Audio Output (R)
15
Expansion Audio Output (L)
2
Expansion Audio Output (R)
3
Expansion Audio Input
Expansion Lo
14
1
Expansion Power
Page E
35
Copilot Audio
36 Panel
39
Copilot Panel
10
J1
11
40
41
37
38
41
Rev. 14, Jan. 2012
J2
Ground Lug
