Yamaha TSS-10 Owner's Manual

Home theater sound system
Hide thumbs Also See for TSS-10:
Table of Contents

Advertisement

Quick Links

See also: Service Manual
HOME THEATER SOUND SYSTEM
TSS-10
INPUT
DIGITAL 1
DIGITAL 2
ANALOG
MODE
DTS
DIGITAL
PL
MOVIE
PL MUSIC
VOLUME
TRIM
7
+6
6
+4
5
+2
4
0
3
–2
2
–4
1
–6
Active Servo
Technology
STANDBY/ON
SILENT
TSS-10
HOME THEATER SOUND SYSTEM
OWNER'S MANUAL
U B
INPUT
MODE
REAR
S.WOOFER
VOLUME
MUTE
TEST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TSS-10 and is the answer not in the manual?

Questions and answers

Related Manuals for Yamaha TSS-10

Summary of Contents for Yamaha TSS-10

  • Page 1 HOME THEATER SOUND SYSTEM TSS-10 OWNER’S MANUAL INPUT DIGITAL 1 DIGITAL 2 ANALOG MODE DIGITAL MOVIE PL MUSIC VOLUME TRIM INPUT –2 MODE –4 –6 REAR S.WOOFER VOLUME MUTE TEST Active Servo Technology STANDBY/ON SILENT TSS-10 HOME THEATER SOUND SYSTEM...
  • Page 2 YAMAHA will not be held responsible for any damage resulting from use of this system with a voltage other than specified.

  • Page 3: Table Of Contents

    PREPARATION FEATURES G Home Theater Sound This system delivers a realistic and powerful sound experience like that found in a movie theater. G Includes Dolby Digital, Dolby Pro Logic II and DTS Decoders This system can reproduce the sound field of the software with the logo mark, and also reproduce normal 2-channel stereo sources in surround sound.

  • Page 4: Checking The Accessories

    CHECKING THE ACCESSORIES Check your package to make sure it contains the following items. Remote control Batteries (AAA, R03, UM-4) INPUT MODE REAR S.WOOFER VOLUME AC adaptor MUTE TEST (LSE9802B1540) Optical cable Audio pin cable INSTALLING BATTERIES IN THE REMOTE CONTROL Insert the batteries in the correct direction by aligning the + and –...

  • Page 5: Controls And Functions

    CONTROLS AND FUNCTIONS Front panel INPUT DIGITAL 1 DIGITAL 2 ANALOG MODE DIGITAL MOVIE PL MUSIC VOLUME TRIM –2 –4 –6 STANDBY/ON SILENT INPUT and indicators Press this button repeatedly to select an input source between DIGITAL 1, DIGITAL 2 and ANALOG. The current mode is shown by the lighting of the corresponding indicator.

  • Page 6: Using The Remote Control

    CONTROLS AND FUNCTIONS VOLUME (+/–) and indicators Used for adjusting the overall volume level of this system. The current level is shown by the lighting of the indicators on the front panel. VOLUME on the front panel: Turn this control clockwise to increase the level, and counterclockwise to decrease the level.

  • Page 7: Setting Up The System

    SETTING UP THE SYSTEM System configuration This system includes an amplifier unit, five speakers and a subwoofer. Amplifier unit x 1 Speaker x 5 The three speakers with a 3 m cable are used as front speakers and a center speaker. The two speakers with a 10 m cable are used as rear speakers.
  • Page 8 SETTING UP THE SYSTEM Adjusting the front angle of the front/ center/rear speakers The front angle of the speakers can be adjusted as shown below. 1 Loosen the screw on the bottom of the speaker stand. * Attach the supplied non-skid pads at the four corners on the bottom of the stand for improved stability.

  • Page 9: Connections

    * This system cannot be connected to video signal input/ VOLUME TRIM output terminals of a TV, VCR, DVD player, etc. –2 –4 –6 Active Servo Technology STANDBY/ON SILENT TSS-10 HOME THEATER SOUND SYSTEM Right rear speaker Center Right front speaker speaker DVD player Subwoofer...

  • Page 10: Connecting Audio Components

    The amplifier unit has no video input terminal. To enjoy watching a source played on the DVD player etc. connected • to the amplifier unit, connect the video output of DVD player to the TV. • The TSS-10 cannot record any audio or video source. Rear panel SPEAKER...

  • Page 11: Connecting The Speakers

    Connecting the speakers Connect the speakers to the amplifier unit. Connect the three speakers with a 3 m cable to the FRONT L, R and CENTER terminals. Connect the two speakers with a 10 m cable to the REAR L and R terminals. Connect the subwoofer to the SUBWOOFER terminal. Note •...

  • Page 12: Connecting The Power Cable

    CONNECTIONS Connecting the power cable Rear panel CENTER S. WOOFER ANALOG INPUTS DC IN 15V AC adaptor (included) Power cable (U.S.A. model) (included) Once all connections have been made, check them one more time. Finally, plug in the amplifier unit to the wall outlet in the following procedure.

  • Page 13: Adjusting Speaker Output Levels

    ADJUSTING SPEAKER OUTPUT LEVELS This section explains how to adjust speaker output levels using the test tone generator. When this adjustment is complete, the output level heard at the listening position should be the same from each speaker. This is important for best performance of the various decoders (Dolby Digital, Dolby Pro Logic II and DTS).

  • Page 14: Playing A Source

    Let’s listen to sources played on the audio and video components connected to this system. Remote control Front panel INPUT INPUT DIGITAL 1 INPUT DIGITAL 2 ANALOG MODE DIGITAL MOVIE PL MUSIC VOLUME TRIM VOLUME +/– MUTE –2 –4 –6 VOLUME STANDBY/ON SILENT...

  • Page 15: Selecting The Surround Mode

    SELECTING THE SURROUND MODE This system provides you with four surround modes for theaterlike surround sound enjoyment. For the best results, choose a mode appropriate for the selected audio source. Remote control Front panel INPUT INPUT DIGITAL 1 DIGITAL 2 ANALOG MODE DIGITAL...

  • Page 16: Troubleshooting

    Refer to the chart below when this system does not function properly. If the problem you are having is not listed below or if the instruction below does not help, set this system to the standby mode, disconnect the power cable, and contact the nearest authorized YAMAHA dealer or service center. Problem...
  • Page 17 Problem Though a Dolby A Dolby Digital 2-channel encoded source is Digital encoded inputted to this system. source is inputted to this system and the DIGITAL mode is selected, no sound is outputted from the center and rear speakers. A DTS or Dolby The DVD player, etc.

  • Page 18: Glossary

    5 channels in a Dolby Digital or DTS 5.1 channel systems. I SILENT CINEMA YAMAHA has developed a natural, realistic sound effect DSP algorithm for headphones. Parameters for headphones have been set for each surround mode so that accurate representations of all the...

  • Page 19: Specifications

    Amplifier unit Output Power per Channel Front/center/rear: 6W (1 kHz, 4 Subwoofer: 18W (100 Hz, 4 ... 200 mV Input Sensitivity Headphone Jack Output Level/Output Impedance ... 450 mV/30 ... 40 Hz–20 kHz Frequency Response Dimensions (W ... 96 mm 281 mm (3-3/4”...
  • Page 20 YAMAHA ELECTRONICS (UK) LTD. YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD1 7JS, ENGLAND YAMAHA SCANDINAVIA A.B. J A WETTERGRENS GATA 1, BOX 30053, 400 43 VÄSTRA FRÖLUNDA, SWEDEN YAMAHA MUSIC AUSTRALIA PTY, LTD. 17-33 MARKET ST., SOUTH MELBOURNE, 3205 VIC., AUSTRALIA Compliance with FCC regulations does not guarantee that interference will not occur in all installations.
