Yamaha NS-P110 Owner's Manual

Home cinema 5.1ch speaker package & home cinema 6.1ch speaker package.
Hide thumbs
Most useful pages: More

Advertisement

NS-P1 10
NS-P1 16
(NS-P110/NS-P116: NX-E130 + NX-C130 + SW-P130)
HOME CINEMA 5.1CH SPEAKER PACKAGE
HOME CINEMA 6.1CH SPEAKER PACKAGE
OWNER'S MANUAL
U
I

Advertisement

   Also See for Yamaha NS-P110

   Related Manuals for Yamaha NS-P110

   Summary of Contents for Yamaha NS-P110

  • Page 1

    NS-P1 10 NS-P1 16 (NS-P110/NS-P116: NX-E130 + NX-C130 + SW-P130) HOME CINEMA 5.1CH SPEAKER PACKAGE HOME CINEMA 6.1CH SPEAKER PACKAGE OWNER’S MANUAL...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. • Explanation of Graphical Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert you to the...

  • Page 3

    This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly approved by Yamaha may void your authority, granted by the FCC, to use the product. IMPORTANT : When connecting this product to accessories and/or another product use only high quality shielded cables.

  • Page 4: Unpacking

    G Subwoofer SW-P130 SUBWOOFER SYSTEM YST SW005 Please check to make sure all listed items are included. G Speaker cables < > NS-P110 < > NS-P116 G Subwoofer cable G Fasteners (for NX-C130) G Nonskid pads (for NX-E130) G Nonskid pads (for SW-P130)

  • Page 5: Caution

    ● Secure placement or installation is the owner’s responsibility. YAMAHA shall not be liable for any accident caused by improper placement or installation of speakers. ● Any time you note distortion, reduce the volume control on your amplifier to a lower setting.

  • Page 6: Table Of Contents

    COMPONENTS OF THE PACKAGE The speaker package “NS-P110 and NS-P116” is designed for use in a multi-channel audio system such as a home theater system. NS-P110 includes four NX-E130 speaker systems, one NX- C130 speaker system and one SW-P130 subwoofer system.

  • Page 7: Setting Up The Speakers

    Place the speakers depending on your listening position by following the instructions below. Speaker configuration < > NS-P110 This speaker package employs a 6 speaker configuration: 2 front speakers, 2 rear speakers, a center speaker and a subwoofer. The front speakers emit main source sound. The rear speakers emit surround sounds, and the center speaker emits center sounds (dialog etc.).

  • Page 8: Placing The Subwoofer

    Placing the subwoofer Å ı : Subwoofer, Placing the center speaker You can place the speaker on top of the TV if the top is flat, on the floor under the TV, or inside the TV rack . Be sure to place the speaker in a stable position.

  • Page 9: Mounting The Front/rear Speakers (and Rear Center Speaker For Ns-p116)

    70 mm 10 mm Min. 20 mm 70 mm Using the Yamaha Speaker Stand SPS-80 (option) By using the Yamaha Speaker Stand SPS-80, speakers can be placed on the floor. SPS-80 * The SPS-80 is not available in some areas.

  • Page 10: Placing The Front/rear Speakers (and Rear Center Speaker For Ns-p116)

    (and rear center speaker for NS-P116) The following optional accessories are needed for mounting the speakers on commercially available speaker stands. * Inquire at your authorized YAMAHA dealer for the optional accessories. Mounting bracket (AAX34790) 60 mm...

  • Page 11: Connections

    Caution: Plug in the subwoofer and other audio/video components after all connections are completed. An example of basic connections Amplifier WOOFER OUTPUT Subwoofer VOLUME INPUT AUTO STANDBY HIGH INPUT2 /MONO POWER To AC outlet CONNECTIONS Front speakers Right Left FRONT /MONO Center speaker Rear speakers...

  • Page 12: How To Connect Speaker Cables

    ● Connect the subwoofer to the line output (pin jack) terminal(s) of the amplifier. * To connect with a YAMAHA DSP amplifier (or AV receiver), connect the SUBWOOFER (or LOW PASS etc.) terminal on the rear of the DSP amplifier (or AV receiver) to the L/MONO INPUT terminal of the subwoofer.

  • Page 13: Using The Subwoofer (sw-p130)

    USING THE SUBWOOFER (SW-P130) Controls and their functions Front panel Rear panel POWER 110V-120V VOLTAGE SELECTOR 220V-240V 220V-240V 110V-120V Power indicator Lights up GREEN when the POWER switch ( pressed in to the ON position and goes off when set to the OFF position.

  • Page 14: Automatic-power-switching Function

    Automatic power-switching function If the source being played is stopped and the input signal is cut off for 7 to 8 minutes, the subwoofer automatically switches to the standby mode. (When the subwoofer switches to the standby mode by the automatic power- switching function, the power indicator lights up in red.) When you play a source again, the power of the subwoofer turns on automatically by sensing audio signals input to the...

  • Page 15: Frequency Characteristics

    Set the VOLUME control to minimum (0). Turn on the power of all the other components. Press the POWER switch to the ON position. * The power indicator on the front panel lights up in green. Play a source containing low-frequency components and adjust the amplifier’s volume control to the desired listening level.

  • Page 16: Advanced Yamaha Active Servo Technology (for Sw-p130)

    ADVANCED YAMAHA ACTIVE SERVO TECHNOLOGY (for SW-P130) The theory of Yamaha Active Servo Technology has been based upon two major factors, the Helmholtz resonator and negative-impedance drive. Active Servo Processing speakers reproduce the bass frequencies through an “air woofer”, which is a port or opening in the speaker’s cabinet.

  • Page 17: Troubleshooting

    Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not listed below or if the instructions given below do not help, disconnect the power cord and contact your authorized YAMAHA dealer or service center.

  • Page 18: Specifications

    < > NX-C130 ... 1.1 kg (2 lbs. 7 oz.) SW-P130 Type ... Advanced Yamaha Active Servo Technology Magnetic shielding type Driver ... 16 cm (6-1/2”) cone woofer Amplifier Output U.S.A. and Canada models ... 55 W/5Ω Other models ... 50 W/5Ω...

  • Page 19

    YAMAHA ELECTRONIQUE FRANCE S.A. RUE AMBROISE CROIZAT BP70 CROISSY-BEAUBOURG 77312 MARNE-LA-VALLEE CEDEX02, FRANCE YAMAHA ELECTRONICS (UK) LTD. YAMAHA HOUSE, 200 RICKMANSWORTH ROAD WATFORD, HERTS WD1 7JS, ENGLAND YAMAHA SCANDINAVIA A.B. J A WETTERGRENS GATA 1, BOX 30053, 400 43 VÄSTRA FRÖLUNDA, SWEDEN Printed in China WF51940 YAMAHA MUSIC AUSTRALIA PTY, LTD.

This manual also for:

Ns-p116, C0, Sintetizador6, Nx-e130, Nx-c130, Sw-p130
