- Page 1 User manual NeoRé TG TX Heat pump air-water NeoRé TG TX NeoRé 8TG TX NeoRé TG TX NeoRé TG TX NeoRé 8TG TX HP NeoRé TG TX HP NeoRé TG TX HP NeoRé 6TG TX HP All rights and changes reserved. Last update - .
- Page 2 Quick start The quick start guide can only be used if the heat pump installation has been completed, properly started and tested by the installation company. Division and description of the basic control screen . Object section - Displays heating / cooling mode, building temperature, circulating pump operation and building states. To turn the heating and cooling on and off, use the H/C button.
- Page 3 Winter operation On the Overview screen, switch on the H/C icon (the rectangle on the button is orange). You can set the equithermal curve in a simplified mode after pressing the house icon in the first column. It is the SIMPLE NEO function.
- Page 4 For experts: More accurate but complex setting of the equithermal curve according to Table on page can be made in the Object settings. Then use automatic equithermal curve correction to adjust the heating water temperature according to your needs. Equithermal setting Heating water temperature for: Outdoor temperature Floor or ceiling heating...
-
Page 5: Table Of Contents
Contents Safety instructions Safety warning ............Safety precautions . - Page 6 8. . Magnesium anode rod ..........8.
-
Page 7: Safety Instructions
. Safety instructions Safety warning Read the manual carefully before installing, putting into operation or maintaining the device. Adherence to the described procedures for the installation and operation of the device is important for long-term and trouble-free operation. Faults and defects caused by non-compliance with the safety instructions, installation procedures and operating rules will not be taken into account, not even damage or destruction of other related equipment. -
Page 8: Legal Conditions
In case of fire, disconnect the device from the mains and extinguish with a snow or powder fire extinguisher. In the event of a heating water leak, turn off all circuit breakers located on the indoor unit and contact your service organization. -
Page 9: Storage And Transport Conditions
Storage and transport conditions Indoor unit NeoRé IUTX 6- Environment dust-free, non-aggressive Temperature range to 45°C Relative humidity Outdoor unit OU GMx or OU GPx Environment dust-free, non-aggressive Temperature range to 45°C Relative humidity The outdoor unit must be stored and transported in a vertical position in the original packaging and properly se- cured. -
Page 10: Product Specification
. Product specification Product designation The NeoRé series heat pump is designed for heating family houses or smaller industrial buildings. The product is intended for connection to a low-temperature heating system. The ideal heating system is mainly floor, wall and ceiling heating. Connection of conventional wall-mounted radiators is possible, but it is limited by the maximum heating water outlet temperature 55°C. -
Page 11: Outdoor Unit Description
Its heart is a high-quality refrigerant / water exchanger that transfers heat to the heating system. An essential part is the sophisticated Teco controller and its software, which not only controls the operation of the heat pump itself, but also takes care of the thermal comfort inside your building. -
Page 12: Table Of Technical Parameters
.6 Table of technical parameters Figure . : Table of technical parameters... -
Page 13: Principle Of Operation And Correct Use
. Principle of operation and correct use Principle of heat pump operation The basic prerequisite for the operation of a heat pump is a heat transfer medium with suitable properties for changing the state at a given pressure and temperature. All these basic components are indicated in the figure below – Schematic diagram of the heat pump operation. -
Page 14: Low-Temperature Heating System
Low-temperature heating system Examples of a low-temperature heating system: • floor heating • ceiling heating/cooling • wall heating Large-area radiant systems are best suited for use with a heat pump. The heat pump is maximally efficient with these systems and its service life is longer. They are also the most comfortable type of heating for habitable rooms. With these systems, it is possible to induce natural thermal comfort and avoid heat build-up and large thermal differences upwards, as is the case with traditional convective heating systems. -
Page 15: Description Of The User Interface
. Description of the user interface Before making changes to the device settings, carefully read what each function means and what the settings affect. Improper adjustment can result in uncomfortable and uneconomical operation, which is associated with unnecessarily higher equipment wear and higher operating costs. Default screen For the control, activation, deactivation and setting of the heat pump, use the touch screen on the front of the product cover. -
Page 16: Overview
Elements on the display that can be used to change values, turn functions on and off or link to another page have an orange background. Pressing the element displays the linked page or the panel for editing the variable, which dynamically changes according to its type. - Page 17 Figure . : Overview section More.. Reset Energy button, e.g. before the start of the heating season. The right side of the screen is again identical to the previous window. Figure . : Overview section More.. Energy If the current power value is negative, heat is being removed from the building. This is common, for example, when the outdoor unit is defrosting and an ice layer forms on the evaporator, which needs to be removed to maintain good heat transfer.
- Page 18 The left part of the status and error screen (Fig. . page 8) shows a history of the last ten recorded problems. You can clear the error history table using the Reset history button. This deletes data from the screen, but the complete record of the operating data remains saved and is accessible from a web browser in the device settings.
-
Page 19: Meaning Of Graphic Symbols And Text Abbreviations
Meaning of graphic symbols and text abbreviations Heat pump operation – the heat pump is used for heating / cooling / DHW heating. Secondary source operation – the secondary source is used for heating, the heat pump is used for DHW heating Defrosting –... - Page 20 Outdoor temperature – outdoor air temperature Comp. – current compressor speed Vent. – current fan speed Hours in use – number of operating hours of the device Water flow – current water flow in the indoor unit Current power – current heat output supplied by the heat pump Suppl.
-
Page 21: Simplified Setting Of The Weather Compensation Curve - Simple Neo
Simplified setting of the weather compensation curve – SIMPLE NEO Pressing the house icon on the Overview screen (Fig. . page 6) displays simplified setting of the weather compen- sation curve – SIMPLE NEO (Fig. .6 page ). In simplified setting of the weather compensation curve (SIMPLE NEO), you can find: H/C is used to switch heating/cooling on or off like on the previous screen. -
Page 22: Object
Object ) is reserved for navigation. You can use the up arrow , down arrow and The right part of the screen (Fig. .8 Fig. Menu buttons to scroll through the section windows. Next to the arrows is a slide that indicates which screen of the section is currently displayed. - Page 23 I.e. if the building temperature is 22.8°C, the required building temperature is 22°C, the IQ correction gain is and the output water temperature calculated according to the weather compensation curve is 23°C, the actual temperature of the output water after an IQ correction change will be: - (( .8 - = - ( .8 x = - .6 +...
- Page 24 Weather compensation curve setting Heating water temperature for: Outdoor temperature Floor heating Radiators 19°C 22°C 25°C 6°C 28°C 40°C 7°C 33°C 45°C 20°C 38°C 50°C Table . : Weather compensation curve setting The weather compensation curve must then be adjusted to match the nature of the heated building. For this tuning, use Automatic correction +/- 3➦C .
- Page 25 Attenuation time schedule allows you to set a decrease of the heating water output temperature. In the settings (Fig. page ), there are two time slots available for each day of the week. Click on the orange rectangles to set the desired times.
-
Page 26: Dhw
Figure . : Building section – screen Dew point sensors The first item in the DHW section (Fig. . page 6) is Required DHW temperature °C, which shows and allows the ad- justment of the desired temperature of the hot water in the tank. Figure . - Page 27 If Follow en. tariff for DHW is active, hot water heating is only possible at times of low electricity tariff. On the second screen of the DHW section (Fig. . 6 page ), you can activate DHW circulation. This activates hot water circulation in the piping, which is controlled by the time schedule.
-
Page 28: Graphs
Graphs The Graphs section (Fig. . page 8) consists of screens, between which you can switch using the navigation keys. Individual screens show clear records from the last ten hours of heat pump operation. Individual graphs plot the courses of output water temperature , required power , outdoor air temperature , DHW temperature and building indoor tempe All operating data is then stored in memory and accessible via a web browser. -
Page 29: Settings
.6 Settings The Settings section (Fig. . 8 page ) is used for general setting of heat pump parameters or special settings in the Service Access section. “Current limit st phase” is intended primarily for devices with a single-phase outdoor unit (information about the outdoor unit is given in Chapter .6 –... - Page 30 Silent mode allows you to activate/deactivate the silent mode. Only during attenuation enables the silent mode only during the attenuation time. At the bottom of the screen, Service access can be used to log into the service settings section. The last page of the Settings section contains Logout , which can be used to log out of the service section.
- Page 31 When changing Neota Route settings, these changes must be registered by activating Use new settings NR . Figure . : Settings section – screen Network settings ) contains E-mail settings , which can be used to set the parameters for sending The third screen (Fig.
-
Page 32: More
Figure . : Settings section – screen Network settings E-mail settings The second screen of e-mail settings shows statistics about the sent error e-mails. The first item Send test email can be used to send a test e-mail. (Fig. . page Figure . - Page 33 Figure . : Settings section – screen Language settings Figure . 6: Settings section – screen Silent mode Second. source tank temp ➦C displays the current temperature in the secondary source storage tank. Second. source hyster. ➦C sets the limit temperature for using the secondary source. If the temperature in the stor- age tank is higher than the set limit, the secondary source is used for heating.
-
Page 34: Web Server Operation
• The default IP address of the heat pump is 192.168.134.176 • The user name is “neore” and the password is “neore” This address and other settings can be changed in the Settings section in the heat pump controller. -
Page 35: Neota Route (Cloud)
Figure . : NeoRé heat pump connection options Neota Route (cloud) Neota Route is a service for NeoRé heat pumps, which provides user access to a web server over the internet without the need for a public IP address and accurate router mapping (as is the case for operating a web server over the internet). It is enough if the heat pump has access to the internet, just like any other computer in the household. -
Page 36: Commissioning
. Commissioning Commissioning of the heating system Before starting the circulating pump, the circuit must be filled with water. Water should be filled to a basic pressure of – . bar. From a water column height of m, the basic pressure increases by . bar per metre of height. The maximum water column height is 8 m. -
Page 37: Shutdown
6. Shutdown Attention! When shutting down the system completely, the heating system and the heat pump can be damaged or completely destroyed in winter due to freezing. Short-term shutdown If you need to turn off the heat pump briefly, press H/C and/or DHW so that the orange indicator in the upper right corner of the button turns grey. -
Page 38: Faults And Status Messages
. Faults and status messages Error code structure A fault code consists of four digits. The first two digits indicate critical errors. These are faults that cause the heat pump to stop running. The other two digits indicate the status of the connected temperature sensors. Faults of temperature sensors do not affect the operation of the heat pump. -
Page 39: Faults And Troubleshooting
rd digit - No fault - Faulty outdoor temperature sensor – the sensor is disconnected - Faulty outdoor temperature sensor – the sensor is short-circuited - Faulty building temperature sensor – the sensor is disconnected - Faulty building temperature sensor – the sensor is short-circuited - Faulty DHW temperature sensor –... - Page 40 The heat pump user interface in the States and faults lists the last ten fault states (codes) of the heat pump. Complete operating data is accessible via the heat pump’s web interface. The controller has the Fault autoreset function. Thanks to this function, the heat pump can resume operation after a critical fault has been removed, e.g.
-
Page 41: Status Messages
Fault xxx Low water pressure. If the heating system pressure is lower than .8 bar, the device stops operating in order to avoid damage to the circulating pump. The usual cause is leaking heating water. There may also be damage to the expansion vessel or air leak from its bag. To remove the fault, increase the water pressure in the heating system to . -
Page 42: Protective Functions
is heated continuously to the temperature set by the weather compensation curve for an outdoor temperature of + °C. To correct this, contact a service organization. Status xx x and xx x This status means that the indoor temperature sensor is disconnected or faulty. The indoor temperature sensor is not a standard part of the heat pump installation and it is therefore possible that this status will be displayed permanently. - Page 43 These are protective mechanisms that take care of the safety of the heat pump and protect it from damage or destruction. The following overview lists and explains these safety functions. This list primarily aims to explain the behaviour of the heat pump to the end user or to aid a service organization. In no case it encourages making changes to the product itself or in the service offer.
- Page 44 Water pressure monitoring – heating/cooling water pressure The loss of pressure in the heating system is a serious problem, so when the pressure in the heating system drops below the set value, the entire system stops. The critical pressure value can be set in the service settings under Minimum water pressure . This protection is linked to the autoreset function.
-
Page 45: Service Organization
Both parameters can be set in the service settings as Restart and Restart Threshold. Cooling water temperature deficit Protection against low water temperature during cooling, when the cooling water temperature drops below the set limit. The limit temperature for shutting down the outdoor unit and cooling is set as the cooling water temperature minus the cooling water temperature deficit. -
Page 46: Maintenance Of The Device And Components
8. Maintenance of the device and components Thanks to its design, the heat pump is easy to maintain. Basic maintenance is to be performed by a service organization during regular annual inspection. During this inspection, the service organization shall check all important parts of the heat pump, especially the operation of the refrigerant circuit. -
Page 47: Maintenance Of The Indoor Unit
Maintenance of the indoor unit The indoor unit requires only minimum maintenance. The device does not contain components that require maintenance by the user. Use only a damp cloth to clean its surface. Take extra care when the device is in operation and powered. We recommend performing maintenance on the indoor unit outside the heating/cooling season in the non-powered state. - Page 48 8. . Magnesium anode rod The service life of magnesium anode protection cannot be precisely determined, because it depends on the quality of the water entering the vessel. Therefore, the protection must be visually checked every six months after commissioning. If a large part of the magnesium anode rod is depleted, replace it with a new one.
- Page 49 Maintenance plan Check of operation, errors and statuses Clean up heating water filter and check water flow Check expansion tank pressure Check safety valve operation Check, desludge DHW tank Check, replacement of DHW tank anode rod - enamel tank Check, replacement of DHW tank anode rod - stainless steel tank Check, DHW tank ACES - stainless steel tank Check of circulator function Check the outdoor unit exchanger...
- Page 50 . Disposal of the device Disposal of the packaging The EKO-KOM system is based on the cooperation of industrial enterprises (clients), cities and municipalities. This non- profit system ensures that waste from packaging is sorted by the consumer, collected by collection vehicles, resorted and finally used as a secondary raw material.
- Page 51 . Manufacturer contact MANUFACTURER NEOTA CZ s.r.o. Štefánikova Brno, Czech Republic Company ID No. VAT ID No. CZ ESTABLISHMENT NEOTA CZ s.r.o. Jankovice Holešov, Czech Republic Phone: + E-mail: support@neota.cz facebook.com/tepelnacerpadlaneore Documents for download All product documentation is also available online at www.neota.cz/en/downloads in PDF format. Online manuals For quick access to manuals from you cellphone you can use QR codes.
