Follow drawing below to solder "main" pot to shielded cable.
PARTS
*Recommended Spare Parts
11
DESCRIPTION
Potentiometer 100K w/cable *
PC Board Assembly*
Thyristor Module
Disconnect Switch 30A *
Fuse 2A thru 20A *
Warning Label
Warning Label
PART NUMBER
7200-040-011
7200-039-001
7200-040-006
7200-040-008
FAST ACTING, 600V, TYPE CC
125694
128494
