- Page 1 HOT PRESS PTM-110 Version: English - Translation Instruction Manual and Operation PTM-110 – Code 23970 Review 02...
-
Page 2: Table Of Contents
1.1 Safety Warnings in the Manual Contents ............... 3 1.2 Security Warnings on the Equipment ................3 2 INTRODUCTION ........................4 2.1 Mogk Quality Policy ......................4 2.2 Mogk Customers ....................... 4 2.3 About the Equipment ......................4 2.4 About Manual ........................5 3 GENERAL INFORMATIONS ..................... -
Page 3: Security Instructions
1 SECURITY INSTRUCTIONS This manual provides the necessary information for the proper use and handling of the equipment. Read carefully before installing and powering it up. 1.1 Safety Warnings in the Manual Contents This manual presents safety warnings like this: REGULATION Take a look on the operating instructions. -
Page 4: Introduction
2.2 Mogk Customers You have just purchased your Heat Press PTM-110, one more product with the quality and technology Mogk. Which incorporates modern concepts of design and architecture. To make the most of all available resources and a better performance of your equipment, please! Read this technical manual before using the equipment. -
Page 5: About Manual
There are confidential content in this manual, drawings and technical instructions. Therefore, Mogk reserves the copyright, dissemination and use of it, should not such acts be carried out without our prior written permission. -
Page 6: Installation
4 INSTALLATION Install the PTM-110 on a level surface, without the presence of aggressive agents. See technical specifications for installation on page 4.1 Operation of machine The following procedures should be performed with the top platen in the open position:... -
Page 7: Pressure Control
4.2 Pressure Control The PTM-110 has a manual system of pressure regulation, developed exclusively by Mogk engineering for the purpose of convenience and flexibility in operation, this system is located at the top of the machine. (Fig.1) The following procedures should be performed with the top platen in the open position: Set the desired pressure by turning the knob a half turn at a time;... - Page 8 Turn on the equipment: Press the button to access the temperature parameter, press the keys to adjust the desired value, after selection, press key to save and exit. Press the button to access the pressing time parameter, press the keys to adjust the desired value, after selection, press key to save and exit.
-
Page 9: Maintenance
5 MAINTENANCE ATENTION! Maintenance should be performed by a qualified person. DANGER! Always turn off the power supply before any maintenance. EARTH We suggest you to have your machine earthed. HOT SURFACE Prior to any maintenance activities, make sure the machine is cold. 5.1 Cleaning ATENTION! Switch off the machine before cleaning. -
Page 10: Technical Assistance
5.3 Technical Assistance DANGER! Only people with technical qualifications are authorized to install, operate and maintenance services of this equipment. All safety instructions in this manual must be followed. The non-observance of this warning may result in life- threatening and / or serious damage to property. WARNING! For safety reasons, we do not recommend any modifications to the equipment. -
Page 11: Technical Data And Information
6 TECHNICAL DATA AND INFORMATION ELECTRIC CIRCUIT CONDUCTOR VOLTAGE CURRENT BREAKER PHASE / NEUTRAL 220V BIPHASIC 41 A 50 A 10 mm² FREQUENCY 60 Hz ELECTRIC POWER 9 000 W TEMPERATURE CONTROL RANGE 0° A 255°C WEIGHT 405 Kg HEIGHT 1,5 m DEPTH 2,4 m... -
Page 12: Electrical Schematic
7 ELECTRICAL SCHEMATIC IMPRIMIR ESQUEMA ELÉTRICO EM A3... -
Page 13: Assembly Drawings And Spare Parts
8.1 List of Materials 8 ASSEMBLY DRAWINGS AND SPARE PARTS... -
Page 14: General Assembly
8.2 General Assembly... -
Page 19: Top Platen Assembly
8.3 Top platen assembly... -
Page 20: Lower Platen Assembly
8.4 Lower platen assembly... -
Page 21: Warranty Certificate
. transport costs and insurance from the place of installation to Mogk, and vice versa are your obligations. If there is need for intervention, expenses such as accommodation and travelling costs should be paid by the costumer. -
Page 22: Appendix
10 APPENDIX Procedures to unlock: 10.1 Initial procedure – removal of the transport lock With hexagonal key Nº5 remove the lock (A) unlocking the set screws (B); Store the locking componentes; PTM-110 - Locked for transport PTM-110 - Unlocked... - Page 23 10.2 Start the machine Connect the power connector (C) to the circuit breaker (D); After performing the procedure place the Procedures – start the machine: back cover (A). Remove back cover (A) Unlock the set For your safety always keep the machine screws (B) use the phillips key.
-
Page 24: Digital Controller
10.3 Digital controller...
