- Page 1 HEAT PRESS MODEL PTM-80 Instruction Manual and Operation PTM-80 – Code 13232 / 19550 - Review.01...
-
Page 2: Table Of Contents
8.1.1 Parts list ........................14 8.1.2 Top platen assembly....................18 8.1.3 Lower platen assembly ....................19 8.2 PTM-80 With Lower Platen Heating ................20 8.2.1 Top platen assembly....................20 8.2.2 Lower plate assembly ....................21 9 CERTIFICATE OF WARRANTY....................23 10 APPENDIX .......................... -
Page 3: Security Instructions
1 SECURITY INSTRUCTIONS This manual provides the necessary information for the proper use and handling of the equipment. Read carefully before installing and powering it up. 1.1 Safety Warnings in the Manual Contents This manual presents safety warnings like this: REGULATION Take a look on the operating instructions. -
Page 4: Introduction
2.2 Mogk Customers You have just purchased your Heat Press PTM-80, one more product with the quality and technology Mogk. Which incorporates modern concepts of design and architecture. To make the most of all available resources and a better performance of your equipment, please! Read this technical manual before using the equipment. -
Page 5: About Manual
There are confidential content in this manual, drawings and technical instructions. Therefore, Mogk reserves the copyright, dissemination and use of it, should not such acts be carried out without our prior written permission. -
Page 6: Installation
4 INSTALLATION Install the PTM-80 on a level surface, without the presence of aggressive agents. See technical specifications for installation on page 11. 4.1 Operation of machine The following procedures should be performed with the top platen in the open position: Put the machine plug into a (110V or 220V) socket, as page 11 indication;... -
Page 7: Pressure Control
4.2 Pressure Control The PTM-80 has a manual system of pressure regulation, developed exclusively by Mogk engineering for the purpose of convenience and flexibility in operation, this system is located at the top of the machine. (Fig.1) The following procedures should be performed with the top platen in the open position: Set the desired pressure by turning the knob a half turn at a time;... - Page 8 Turn on the equipment: Press the button for three seconds to access the temperature parameter, press the keys to adjust the desired value, after selection, press key to save and exit. Press the button for three seconds to access the pressing time parameter, press the keys to adjust the desired value, after selection, press...
-
Page 9: Maintenance
5 MAINTENANCE ATTENTION! Maintenance should be performed by a qualified professional. DANGER! Always disconnect the power cord to the power source before any maintenance. GROUND We suggest always having the equipment grounded. HOT SURFACE Before any maintenance make sure that the machine is cold. 5.1 Cleaning DANGER! Always disconnect the power cord to the power source before any... -
Page 10: Technical Assistance
5.3 Technical assistance The Mogk Industry and Trade Machines Ltda. Provides technical assistance services to its customers even if the equipment warranty period has expired. To request the service contact through our communication channels. Costs will be reduced if the service is requested in advance. -
Page 11: Technical Data And Information
6 TECHNICAL DATA AND INFORMATION ELECTRIC CIRCUIT CONDUCTOR VOLTAGE CURRENT BREAKER PHASE / NEUTRAL 220V MONOPHASE 20 A 25 A 2,5 mm² FREQUENCY 60 Hz ELECTRIC POWER 4400 W TEMPERATURE CONTROL RANGE 0° A 255°C WITH NO WORKBENCH WORKBENCH WEIGHT 118 Kg 104 Kg HEIGHT... -
Page 12: Electrical Schematic
7 ELECTRICAL SCHEMATIC... -
Page 13: Assembly Drawings And Spare Parts
8 ASSEMBLY DRAWINGS AND SPARE PARTS 8.1 PTM -80 With Top Platen Heating Optional Teflon Protector Optional workbench... -
Page 14: Parts List
8.1.1 Parts list... -
Page 18: Top Platen Assembly
8.1.2 Top platen assembly... -
Page 19: Lower Platen Assembly
Lower platen assembly 8.1.3... -
Page 20: Ptm-80 With Lower Platen Heating
8.2 PTM-80 With Lower Platen Heating 8.2.1 Top platen assembly... -
Page 21: Lower Plate Assembly
8.2.2 Lower plate assembly... -
Page 23: Certificate Of Warranty
Inform immediately Mogk any irregularity with the normal operation of the equipment, identifying, as far as possible, their origin. b) Arrange for Mogk technicians have free access to the equipment, so that the service work to be started soon after his arrival at the customer location performed without hindrance;... -
Page 24: Appendix
10 APPENDIX... -
Page 26: Mogk Products
PTP - 1450 THERMAL PRESS SEMIAUTOMATIC PTP - 660 THERMAL PRESS FOR Mogk Industry and Trade Machines Ltda. LABEL - SR4 Rua 2 de Setembro, 2877 - Itoupava Norte Zip Code: 89052-505 - Blumenau – SC - Brazil Phone: +55 47 3323-5844 Fax: +55 47 3323-3172 mogk@mogk.com.br...
