Rapid Spray Marshal Pro Operators Handbook CONTENTS Introduction & Models Warnings Product Risk Assessment Troubleshooting Operation Mixing & Filling Calibration Guides Spraying Buddy Smart Reel Operation Boom Regulator Kit Honda GX200 Engine Cleaning & Maintenance Marshal Tank Parts Breakdown Maruyama 33L/min Pump Breakdown... - Page 3 *WARNING: Always obey vehicle and UTV/ATV manufacturer instructions regarding loading and operation. Please check weight restrictions. Serious death or injury can occur from improper usage. Rapid Spray accepts no liability for the unsafe operation of this unit. REV JUNE 2020...
-
Page 4: Warnings
Rapid Spray Marshal Pro Operators Handbook WARNINGS Read all warnings below and obey any instruction stickers or warnings on the spray unit. Failure to do so may result in serious bodily harm or death. When mounting to any vehicle, ensure that you have read the Vehicle Owner’s Manual and that you comply with all the weight restrictions as specified by the vehicle manufacturer, as overloading can cause injury or death. -
Page 5: Product Risk Assessment
Rapid Spray Marshal Pro Operators Handbook PRODUCT RISK ASSESSMENT TASK HAZARDS RISK CONTROL MEASURES Partially fill the tank Manual handling; Medium Concentrate on tasks, follow safe manual with water, start the slips, trips or falls; handling techniques: don’t lift on your motor and test the petrol fumes;... -
Page 6: Troubleshooting
Always obey vehicle and UTV/ATV manufacturer instructions regarding loading and operation. Please check weight restrictions. Serious death or injury can occur from improper usage. Rapid Spray accepts no liability for the unsafe operation of this unit. Compact Field Sprayers by Rapid Spray... -
Page 7: Operation
Rapid Spray Marshal Pro Operators Handbook OPERATION PRE-START UP Familarise yourself with the unit. Inspect the unit for any broken or damaged components - replace damaged/broken components as necessary. Familiarise yourself with the HONDA motor instructions as per pages 12 - 17, and ensure you follow all warnings and instructions . -
Page 8: Mixing & Filling
Rapid Spray Marshal Pro Operators Handbook MIXING & FILLING The following steps are given as a guide to mixing and filling your Marshal Pro sprayer. Read the product label and follow the instructions carefully, taking special note with regard to the order in which the products are added to the tank. -
Page 9: Calibration Guides
Rapid Spray Marshal Pro Operators Handbook CALIBRATION GUIDE Accurate calibration is an essential element of any spraying function as it ensure that the pesticide is applied at the rate as recommended by the product manufacturer. Application in excess of the recommended rate is prohibited, can damage crops and is uneconomical. -
Page 10: Spraying
Rapid Spray Marshal Pro Operators Handbook SPRAYING For effective spraying, ensure you have taken the following factors into account. Before commencing spraying, plan the work effectively to reduce potential contamination. Do not spray if the operator, bystanders, watercourses or any non-target vegetation appears to be in danger from spray drift contamination. - Page 11 Rapid Spray Marshal Pro Operators Handbook SPRAYING cont. Diagram 1.0 Field Work Spraying Pattern REV JUNE 2020...
-
Page 12: Buddy Smart Reel Operation
Rapid Spray Marshal Pro Operators Handbook BUDDY SMART REEL® (WHERE FITTED) Please read the Buddy Smart Reel® Operators Handbook for full instructions, parts and maintenance instructions. Please note your Marshal Pro sprayer may not require the following instructions. Only applicable to Buddy® Marshal Pro sprayer units. - Page 13 Rapid Spray Marshal Pro Operators Handbook PAIRING MYPACE REMOTE TO BUDDY SMART REEL® The MyPace handheld remote should be delivered already paired to the Buddy Hose Reel. If several reels have been purchased and it is not clear as to which remote is paired to which reel or if the remote has been replaced, the remote can be re-paired to the reel at any time.
-
Page 14: Boom Regulator Kit
Rapid Spray Marshal Pro Operators Handbook BOOM REGULATOR KIT | ATRVS10B400P If your Marshal Pro sprayer has been fitted with a low pressure boom regulation kit and solenoid, you can use this to accurately regulator the output pressure for boom or boomless nozzle spraying. -
Page 15: Honda Gx200 Engine
Rapid Spray Marshal Pro Operators Handbook HONDA GX200 ENGINE Please read the Honda® Owners Manual for full safety, operation, parts and maintenance instructions. Always follow manufacturers directions. SAFETY INFORMATION • Understand the operation of all controls and learn how to stop the engine quickly in case of emergency. - Page 16 Rapid Spray Marshal Pro Operators Handbook COMPONENT & CONTROL LOCATIONS FUEL FILLER CAP AIR CLEANER RECOIL STARTER FUEL TANK MUFFLER SPARK PLUG OIL FILLER CAP/DIPSTICK OIL DRAIN PLUG STARTER GRIP FUEL VALVE LEVER ENGINE SWITCH CHOKE LEVER THROTTLE LEVER FEATURES Oil Alert®...
- Page 17 Rapid Spray Marshal Pro Operators Handbook BEFORE OPERATION CHECKS Is your engine ready to go? For your safety, and to maximise the service life of your equipment, it is very important to take a few moments before you operate the engine to check its condition. Be sure to take care of any problem you find, or have your servicing dealer correct it before you operate the engine.
- Page 18 Rapid Spray Marshal Pro Operators Handbook SAFE OPERATING PRECAUTIONS Before operating the engine for the first time, please review the SAFETY INFORMATION section and the BEFORE OPERATIONS CHECKS on previous cards. For your safety, do not operate the engine in an enclosed area such as a garage. Your engine’s exhaust contains poisonous carbon monoxide gas that can collect rapidly in an...
- Page 19 Rapid Spray Marshal Pro Operators Handbook STARTING THE ENGINE cont. Move the throttle lever away from the MIN. position, about 1/ 3 of the way toward the MAX. position. MIN. MAX. MIN. 1/ 3 POSITION THROTTLE LEVER Some engine applications use a remote-mounted throttle control rather than the engine mounted throttle level shown here.
- Page 20 Rapid Spray Marshal Pro Operators Handbook STOPPING THE ENGINE To stop the engine in an emergency, simply turn the engine switch to the OFF position. Under normal conditions, use the following procedure. Move the throttle level to the MIN. position.
-
Page 21: Cleaning & Maintenance
Rapid Spray Marshal Pro Operators Handbook CLEANING & MAINTENANCE After use, the sprayer must be thoroughly decontaminated, inside and outside. Decontaminating the tank, including pumps, hoses and hand lance, avoids damage to crops from harmful spray residues and prevents sprayer corrosion and abrasion. As a guide, follow the decontamination procedure below: After spraying, rinse all liquid out of the tank. - Page 22 Rapid Spray Marshal Pro Operators Handbook CLEANING & MAINTENANCE cont. Maintenance to pump and engine should be carried out regularly. Refer to pump and engine handbooks for Maintenance Schedule. PUMP MAINTENANCE Check pump Operators Handbook for maintenance schedule and further instructions.
-
Page 23: Marshal Tank Parts Breakdown
Rapid Spray Marshal Pro Operators Handbook MARSHAL TANK PARTS BREAKDOWN 250L MARSHAL TANK 910 (L) x 730 (W) x 620 (H) Part No. Qty Description AMPTC00200ATT / 400BTT 200 / 400L Marshal Tank 2, 3, 4 ARLP250VSR 255mm Screw Lid... -
Page 24: Maruyama 33L/Min Pump Breakdown
Rapid Spray Marshal Pro Operators Handbook MARUYAMA 33L/MIN PUMP REGULATOR PARTS Compact Field Sprayers by Rapid Spray... - Page 25 Rapid Spray Marshal Pro Operators Handbook Description CPUXK330S - Oil Filter Cap incl. #2 O-Ring P20 CPUXL330V - Valve Repair Kit Plug O-Ring P20 #6204 Bearing #6006 Bearing D30428 Oil Seal S100 O-Ring Snap Ring Oil Gauge incl. #10-2 Packing 17x24xT1.2 Washer...
- Page 26 Rapid Spray Marshal Pro Operators Handbook TURBO 400 SPRAY GUN | AHG103 Marshal Pro Range Part No. Description CRP2360236 O-Ring 121 CRP1626095 1/ 2 ″ BSP Ring Nut CRP239024 Metal Trigger (only suits Turbo 400 guns) CRP26150614 O-Ring (orange lever)
- Page 27 Rapid Spray Marshal Pro Operators Handbook PISTOL GRIP SPRAY GUN | AHG104 Buddy® Marshal Pro Range Part no. Description O Ring - Rubber Valve Shaft - Brass with Chrome Plated CPLD104Z05 Stainless Steel Spring Gasket - Rubber Pressure Axle - Brass...
-
Page 28: Warranty
RAPID SPRAY in addition or inconsistent with these provisions. Purchasers to whom these provisions apply agree to hold RAPID SPRAY not liable for claims by their customers in excess of the obligations of RAPID SPRAY expressly set forth herein. - Page 29 RAPID SPRAY, only after inspection of the failed component. In no event shall RAPID SPRAY be liable to any person for indirect or consequential damages or for injury or Inability | Unsuitability commercial loss resulting from any use or inability to use any RAPID SPRAY product.
- Page 30 This page has been left blank intentionally. Rapid Spray 35 Enterprise Cres, Singleton NSW 2330 PO BOX 3119 Singleton NSW 2330 Call us on 1800 011 000 or visit www.rapidspray.net...
-
