3. device description

LabModul 240 are electronic test devices to
be operated via a PC for the testing of brea-
thing masks according to DIN EN 136, self-
contained breathing apparatus (SCBA) ac-
cording to DIN EN 137 and chemical protecti-
ve suits (CPS) according to DIN EN 943-1.
The tests are performed in the low (-50 to 50
mbar) and medium pressure measuring range
(0 to 20 bar).
For testing other breathing apparatus or che-
mical protective suits, contact Labtec. Only
breathing air according to DIN EN 12021 may
be used.
Module T Control panel with LCD display and
membrane keyboard for manual operation of
the device.
Module COM Freely positionable touchscreen
PC, connected to test device via swivel arm
mounting, incl. pre-installed LabNet Profi test
software
The device is also available as model MT. The
model LabModul 240 MT has no interface to
the LabNet Profi operating software but is de-
signed for purely manual operation without PC
support. The LabModul 240 MT has the stand-
ard operating panel of option T. The interface
can be retrofitted at the factory.
Connection requirements
A 230-240 V / 50-60 Hz power supply is requi-
red to operate the test stand.
As medium pressure connection Euro-coupling
and nipple are available as standard. If units
with other coupling connections are tested, ap-
propriate intermediate adapters must be used.
Please contact the manufacturer of the units
for this.
Scope of delivery and accessories
The scope of delivery of the device includes a
power supply cable and a USB cable.
Adapters for the connection of CPS, regulators
and sealing caps for respirators must be or-
dered separately depending on the connection
used (e.g. ESA, PE45, RD40, manufacturer-
specific connections).
User Manual LabModul 240
Labtec offers a wide range of accessories for
test devices.
The range includes test adapters for adapting
all respiratory protection devices on the mar-
ket, quick release devices for quick device
adaptation as well as holders for holding hel-
met-mask combinations

4. technical data

Medium pres- EURO coupling and nipple 0...20 bar
sure connec-
tion:
Medium pres- Measuring range
sure sensor: precision
Low pressure Measuring range
sensor: precision
Dead space approx. 480 ml - w. o. Adapter
Power Input:
Transformer Output:
Dimensions ~ B 460 x H 490 x D 430 mm
Weight: approx. 21 kg
Page 3
0...25 bar
± 0,5 %
-50.0.+50 mbar
± 0,05 %
230 V AC
24 V DC
