19-4315; Rev 0; 10/08
General Description
The MAX9791A evaluation kit (EV kit) demonstrates the
MAX9791A IC, which combines a stereo Class D power
®
amplifier, a DirectDrive
and a 120mA, 4.75V low-dropout regulator (LDO) for
notebook, tablet PC, and portable media player appli-
cations. Maxim's DirectDrive technology eliminates the
need for bulky DC-blocking capacitors at the output of
the headphone amplifier.
The EV kit is configured for a 12dB speaker amplifier
gain and a 0dB headphone amplifier gain. It is designed
to operate from a 4.5V to 5.5V speaker supply and an
optional separate 2.7V to 5.5V headphone supply. The
EV kit is capable of delivering up to 2W into a pair of 4Ω
speakers and 180mW into a 32Ω headphone load.
DESIGNATION
QTY
REQUIRED COMPONENTS
1μF ±10%, 10V X7R ceramic
C1, C2, C5, C6,
8
capacitors (0603)
C25–C28
Murata GRM188R71A105K
1μF ±10%, 50V X7R ceramic
C3, C4, C29
3
capacitors (0805)
Murata GRM21BR71H105K
0.1μF ±10%, 16V X7R ceramic
C7, C8, C9
3
capacitors (0603)
Murata GRM188R71C104K
10μF ±10%, 10V X7R ceramic
C10, C30, C31
3
capacitors (0805)
Murata GRM21BR71A106K
R1, R2
2
20k
R3, R4, R13
3
40.2k
Speaker and headphone amplifier
U1
1
with LDO (28 TQFN-EP*)
Maxim MAX9791AETI+
1
PCB: MAX9791A Evaluation Kit+
DirectDrive is a registered trademark of Maxim Integrated
Products, Inc.
________________________________________________________________ Maxim Integrated Products
For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,
or visit Maxim's website at www.maxim-ic.com.
stereo headphone amplifier,
DESCRIPTION
±1% resistors (0603)
±1% resistors (0603)
MAX9791A Evaluation Kit
♦ No DC-Blocking Output Capacitors Required at
Headphone Output
♦ Speaker and Headphone Operation
Speaker: 2W Stereo Output
Headphone: 180mW DirectDrive Stereo Output
♦ Wake-on-Beep Function
♦ 120mA, 4.75V LDO
♦ Lead-Free and RoHS Compliant
♦ Fully Assembled and Tested
PART
MAX9791AEVKIT+
+ Denotes lead-free and RoHS compliant.
DESIGNATION
QTY
OPTIONAL COMPONENTS
AVDD, HPVDD,
PGND,
SPOUTL+,
SPOUTL-,
SPOUTR+,
SPOUTR-
C11–C24, C32,
C33
HPL, HPR,
PGND, SENSE,
SPOL+, SPOL-,
SPOR+, SPOR-
HPINL, SPINL
HPINR, SPINR
HPOUT
JU1, JU2, JU3
JU4, JU6
JU5
L1–L4
R5–R8
R9–R12,
R14, R15
R16
* EP = Exposed pad.
Features
Ordering Information
TYPE
EV Kit
Component List
DESCRIPTION
7
Binding posts
Not installed, ceramic capacitors
0
(0603)
Not installed, small PCB test
0
points
2
White side-entry phono jacks
2
Red side-entry phono jacks
1
3.5mm stereo headphone jack
3
3-pin headers
2
2-pin headers
0
Not installed, 2-pin header
Not installed, inductors (6.4mm x
0
6mm x 1.5mm)
4
0
±5% resistors (0805)
0
Not installed, resistors (0603)
0
Not installed, resistor (0805)
5
Shunts (JU1–JU5)
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MAX9791A and is the answer not in the manual?

Questions and answers

Summary of Contents for Maxim MAX9791A

  • Page 1 DirectDrive is a registered trademark of Maxim Integrated Not installed, resistor (0805) Products, Inc. — Shunts (JU1–JU5) * EP = Exposed pad. ________________________________________________________________ Maxim Integrated Products For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
  • Page 2 PHONE WEBSITE Murata Electronics North America, Inc. 770-436-1300 www.murata-northamerica.com Note: Indicate that you are using the MAX9791A when contacting this component supplier. Quick Start Detailed Description of Hardware The MAX9791A evaluation kit (EV kit) demonstrates the Recommended Equipment MAX9791A IC in a 28-pin TQFN package. The IC com-...
  • Page 3 ⎠ VSPKR Wake-on-Beep where A is the desired speaker voltage gain. VSPKR Jumper JU6 controls the MAX9791A EV kit’s wake-on- beep feature. See Table 4 for jumper JU6 configuration. ⎛ ⎞ Ω 40.2k Refer to the Wake-on-Beep section of the MAX9791/ Ω...
  • Page 4 MAX9791A Evaluation Kit Figure 1. MAX9791A EV Kit Schematic _______________________________________________________________________________________...
  • Page 5 MAX9791A Evaluation Kit Figure 2. MAX9791A EV Kit Component Placement Guide—Component Side _______________________________________________________________________________________...
  • Page 6 MAX9791A Evaluation Kit Figure 3. MAX9791A EV Kit PCB Layout—Component Side _______________________________________________________________________________________...
  • Page 7 MAX9791A Evaluation Kit Figure 4. MAX9791A EV Kit PCB Layout—Layer 2 _______________________________________________________________________________________...
  • Page 8 MAX9791A Evaluation Kit Figure 5. MAX9791A EV Kit PCB Layout—Layer 3 _______________________________________________________________________________________...
  • Page 9 MAX9791A Evaluation Kit Figure 6. MAX9791A EV Kit PCB Layout—Solder Side _______________________________________________________________________________________...
  • Page 10 Figure 7. MAX9791A EV Kit Component Placement Guide—Solder Side Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.
