MW0202 900mm
ASSEMBLY TIP
Generic view of Top Bar only.
Actual Top Bar will vary
depending on product purchased.
5mm
TP821 Brecon 824P In0821-A 20.04.18.indd 18
x1
70mm FA8439
x2
M8 x25mm
FA8440
x2
ASSEMBLY TIP
Make sure that the fixing points
are centred on the legs.
