Function Instruction
Front View
1
1.Remote Control Signal Receiving
Window and digital display
*Back View
VOLUME AUX PC
L
2
AUDIO
INPUT
R
+
TO L SPEAKER
AC IN
ON
OFF
L - L+
5 6
Front View of Remote control
MUTE INPUT
2
1
+
3
VOLUME
_
+ +
5 4
TREBLE BASS
_ _
1. MUTE: press the key to make the system in
muting
2. INPUT SELECT: press the key to select AUX or
PC audio input
3. VOLUME +/- key: adjust the speaker system's
volume, p ress the key to your demanding level
4 . BASS +/-key: a djust the bass volume, p
key to your demanding level
5 . TREBLE+/-key: a djust the treble volume, p
the key to your demanding level
1. HEAT SINK
2.VOLUME CONTROL
Adjust the speaker system's volume to
your demanding level
3.AUDIO INUPUT
2.0 channel audio input jacks
4.OUTPUT
To L speaker
1
5. POWER
Press the switch ON or OFF
6.POWER CORD
3
4
3
System Connection
ress the
ress
VOLUME
ON
OFF
*Please note the correct placement of speaker is shown in the above picture.
1.Connect one end of the translucent speaker cable to the audio input screw terminal on the back of
the sub speaker. the golden wire connect to red screw terminal. the silvery wire connect to black
screw terminal, the other end to the L-speaker audio output screw terminal on the back of the main
speaker.
2.Connect the RCA plug of the audio cable (one end with RCA plug, the other end with 3.5mm stereo
plug) to the audio input jacks of the main speaker, the 3.5mm stereo plug to the audio output jack
of PC or other audio equipment.
3. While connecting to such as CD player, MP3 or PC, etc., please connect the audio cable to PC
INPUT; while connecting to such as VCD or DVD player, etc., please connect the audio cable to

AUX INPUT.

4. Make sure all the cable are connected correctly, then connect the power cord to AC outlet.
* Statement indicating that the socket-outlet shall be installed near the equipment and shall be
easily accessible.
* The highest environmental temperature suitable for this product is 40
To sound card CD MP3,etc
R
AUX PC
L
AUDIO
INPUT
R
+
TO L SPEAKER
AC IN
L - L+
4
L
