A M P L I F I E R S Congratulations! 3 Low Level Input/ Speaker/ Power wiring Bridging Two Amplifiers Electrical Wiring Troubleshooting 11 GT1500D GT2500D CONTENTS Specifications Features Installation Precautions 10...
A M P L I F I E R S Congratulations on your purchase of a BOSS Audio Systems car audio amplifier. Class D amplifiers are designed and engineered in the USA to the highest level of quality, and will afford you years of listening enjoyment.
Nickel-plated Speaker and Power Terminals Protection Circuitry Against Thermal, Overload and Short Circuit Faults Variable Subsonic Filter (15Hz-40Hz, 24dB/octave) Variable Low Pass Filter (50Hz-150Hz, 24dB/octave) 0/180 Phase Selector Remote Subwoofer Level Control GT1500D and GT2500D Front GT1500D Rear GT2500D Rear...
The minimum recommended impedance is 2 Ohms. The fuse rating for the GT1500D is 40 amperes (2 x 20A fuses) and the GT2500D carries a fuse rating of 75 amperes (3 x 25A fuses). Although sufficient for normal working conditions, overloading of the amplifier may cause these fuses to blow.
Bridging Two Amplifiers GT1500D and GT2500D (BRIDGED SWITCH : MASTER POSITION) To Inputs of From Outputs of Head Unit Satellite Amplifier (BRIDGED SWITCH : SLAVE POSITION) Electrical Wiring All BOSS series power amplifiers are equipped with easy top access screw terminals.
Precautions Before you drill or cut any holes, investigate your car's layout very carefully. Take care when you work near the gas tank, fuel lines, hydraulic lines and electrical wiring. Do not operate the amplifier when it is not mounted. Attach all audio system components securely within the automobile to prevent damage, especially in case of an accident.
Page 7
Troubleshooting, cont. High squeal noise Check all RCA interconnects. High squealing noises are almost always caused by RCA cables with poor grounding. Always use high-quality RCA interconnects from speakers in your audio system. Distorted sound Check that the Level control(s) is set to match the signal level of the head unit. Always begin at the lowest setting.
