STATRON 3231.10 Manual

Regulated power supply

Download this manual

Gerätetechnik GmbH

The correct use of this voltage regulator is:

the connection and use of loads with a d.c. voltage between 0 and 32 VDC and current max.6,4A.

Attention!

Do read this manual carefully. This warranty does not apply to fuses, disposable batteries or to any

product that has been misused, altered, neglected or damaged by accident or abnormal conditions of

operation or handling. We will not be liable for any indirect, special, incidental, or consequential

damages.

Table of contents

1. Introduction

2. Safety instructions (connection to line / changing of fuses)

3. Control Elements, Display and Connections

4. Operation and application

5. Specifications

regulated power supply type 3231.10

Need help?

Do you have a question about the 3231.10 and is the answer not in the manual?

Page 1 Gerätetechnik GmbH regulated power supply type 3231.10 The correct use of this voltage regulator is: the connection and use of loads with a d.c. voltage between 0 and 32 VDC and current max.6,4A. Attention! Do read this manual carefully. This warranty does not apply to fuses, disposable batteries or to any product that has been misused, altered, neglected or damaged by accident or abnormal conditions of operation or handling.
Page 2 1. Introduction This d.c. voltage regulator is an infinitely variable voltage source with high stability and low internal resistance. The regulator can operate both as voltage stabilizer and as current stabilizer in dependence on the load resistance. The manifold characteristics of the d.c. voltage regulator secure its application everywhere where constant d.c.
Page 3 2.11 Do not physically abuse the unit. Dropping it off a workbench or bouncing it around the trunk of a car or the back of a truck may cause damage. Protect the unit while transporting it and use it where it cannot be accidentally hit, kicked, or dropped.
Page 4 4. Operation and application a) Connection Make sure that you are using a 230V/50-60Hz line voltage. Then plug in the power plug, turn the control knobs right (0V / 0A position) and switch the unit on. Chose the voltage your need. You can set-up the current by switching the Imax switch.
