What distinguishes the two units

The connection panel on each unit identifies it by name: TRANSMITTER or RECEIVER. Two
Bose
For compatibility, the two units have a matching Setup Code, set at the factory with both
switches in the "down" position (Figure 2). A Status LED lights when each unit is plugged in
and the two units are communicating.
Figure 2
Connection
panels on the two
units
Bose
Note: For information on the meaning of the different Status LED lights, refer to
"Check the indicators and settings" on page 9.

Choosing a place for each unit

Place the transmitter in the same room with the LIFESTYLE
receiver in the same room with your Bose
Note: Use of the audio link with products that are not Bose link-compatible requires an adapter
cable. For further information, refer to "Instructions for non-Bose or older Bose products" on
page 8.
Considerations for positioning:
• Place each unit upright with all feet flat on a level surface, such as a floor, table, or shelf.
• Do not tip either unit on its side.
• Place each unit within 2 meters (7 feet) of the product to which it is connected (using the
supplied Bose link A cable).
• Keep the two units within 23 meters (75 feet) of each other.
• Be aware that the strongest signal direction is above and around, not below,
the transmitter.
Deutsch Español
® link jacks and a Channel button further distinguish the transmitter.
Transmitter
® link jacks
Français
Channel switch
Bose link jack
Status LED
® link expansion product.
Italiano Nederlands
I
Receiver
® system media center. Place the
Svenska
NTRODUCTION
