TABLE OF CONTENTS
1 Safety Precautions----------------------------------------------- 3
2 Specifications ----------------------------------------------------- 5
3 Features ------------------------------------------------------------- 7
4 Location of Controls and Components ------------------- 8
4.1. Product Overview------------------------------------------ 8
5 Dimensions--------------------------------------------------------- 9
5.1. Indoor Unit & Remote Control -------------------------- 9
5.2. Outdoor Unit -----------------------------------------------10
6 Refrigeration Cycle Diagram --------------------------------11
7 Block Diagram----------------------------------------------------12
8 Wiring Connection Diagram ---------------------------------13
8.1. CS-C18JKV CU-C18JKV ------------------------------13
8.2. CS-C24JKV CU-C24JKV ------------------------------14
9 Electronic Circuit Diagram -----------------------------------15
10 Printed Circuit Board-------------------------------------------16
10.1. Main Printed Circuit Board -----------------------------16
10.2. Power Printed Circuit Board ---------------------------17
10.3. Indicator Printed Circuit Board ------------------------18
10.4. Receiver Printed Circuit Board ------------------------18
Indoor Unit Outdoor Unit
CS-C18JKV CU-C18JKV
CS-C24JKV CU-C24JKV
PAGE
Board-------------------------------------------------------- 18
11 Installation Instruction ---------------------------------------- 19
11.1. Select the Best Location ------------------------------- 19
11.2. Indoor Unit ------------------------------------------------- 20
11.3. Outdoor Unit----------------------------------------------- 24
12 Operation Control----------------------------------------------- 28
12.1. Cooling Operation---------------------------------------- 28
12.2. Soft Dry Operation --------------------------------------- 29
12.3. Automatic Operation ------------------------------------ 30
12.4. Indoor Fan Speed Control ----------------------------- 31
12.5. Outdoor Fan Speed Control --------------------------- 32
12.6. Vertical Airflow Direction Control --------------------- 33
12.7. Horizontal Airflow Direction Control ----------------- 33
12.8. Powerful Operation -------------------------------------- 34
12.9. Quiet Operation------------------------------------------- 34
12.10. Timer Control---------------------------------------------- 35
12.11. Random Auto Restart Control ------------------------ 35
12.12. Remote Control Signal Receiving Sound ---------- 35
12.13. Patrol Operation ------------------------------------------ 36
© Panasonic HA Air-Conditioning (M) Sdn. Bhd. 2008.
Unauthorized copying and distribution is a violation of
law.
Order No. PHAAM0810027C2
Air Conditioner
PAGE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Panasonic CS-C18JKV
Summary of Contents for Panasonic CS-C18JKV
-
Page 1: Table Of Contents
12.11. Random Auto Restart Control ------------------------ 35 10.4. Receiver Printed Circuit Board ------------------------18 12.12. Remote Control Signal Receiving Sound ---------- 35 12.13. Patrol Operation ------------------------------------------ 36 © Panasonic HA Air-Conditioning (M) Sdn. Bhd. 2008. Unauthorized copying and distribution is a violation of law. - Page 2 12.14. e-ion Operation ------------------------------------------- 39 13 Protection Control ---------------------------------------------- 41 13.1. Restart Control (Time Delay Safety Control) ------ 41 13.2. 7 Minutes Time Save Control ------------------------- 41 13.3. 60 Seconds Forced Operation ------------------------ 41 13.4. Starting Current Control -------------------------------- 41 13.5.
-
Page 3: Safety Precautions
1 Safety Precautions • Read the following “SAFETY PRECAUTIONS” carefully before perform any servicing. • Electrical work must be installed or serviced by a licensed electrician. Be sure to use the correct rating of the power plug and main circuit for the model installed. •... - Page 4 18. During pump down operation, stop the compressor before remove the refrigeration piping. (Removal of compressor while compressor is operating and valves are opened will cause suck-in of air, abnormal high pressure in refrigeration cycle and result in explosion, injury etc.) 19.
-
Page 5: Specifications
2 Specifications MODEL INDOOR CS-C18JKV CS-C24JKV OUTDOOR CU-C18JKV CU-C24JKV Performance Test Condition NEW JIS NEW JIS Phase, Hz Single, 60 Single, 60 Power Supply 5.30 7.03 Capacity BTU/h 18100 24000 kJ/h 19100 25300 Running Current 12.0 Input Power 1.72k 2.55k 3.08... - Page 6 MODEL INDOOR CS-C18JKV CS-C24JKV OUTDOOR CU-C18JKV CU-C24JKV Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 12.70 (1/2) 6.35 (1/4) / 15.88 (5/8) Standard Length m (ft) 5.0 (16.4) 5.0 (16.4) Length Range (min - max) m (ft) 3 (9.8) ~ 25 (82.0) 3 (9.8) ~ 25 (82.0)
-
Page 7: Features
3 Features • E-ion Air Purifying System with Patrol Sensor - Active e-ions are released to catch dust particles and bring them back the large positively charged filter - Patrol Sensor color changes to indicate the dirt level in the air •... -
Page 8: Location Of Controls And Components
4 Location of Controls and Components 4.1. Product Overview 4.1.1. Indoor Unit 4.1.2. Outdoor Unit 4.1.3. Remote Control... -
Page 9: Dimensions
5 Dimensions 5.1. Indoor Unit & Remote Control 5.1.1. CS-C18JKV CS-C24JKV... -
Page 10: Outdoor Unit
5.2. Outdoor Unit 5.2.1. CU-C18JKV CU-C24JKV... -
Page 11: Refrigeration Cycle Diagram
6 Refrigeration Cycle Diagram... -
Page 12: Block Diagram
7 Block Diagram... -
Page 13: Wiring Connection Diagram
8 Wiring Connection Diagram 8.1. CS-C18JKV CU-C18JKV Resistance of Outdoor Fan Motor Windings Resistance of Compressor Windings MODEL CU-C18JKV MODEL CU-C18JKV CONNECTION CWA951401J CONNECTION 2K25S236F6A 59.47 Ω 1.505 Ω BLUE-YELLOW C - R 60.95 Ω 1.809 Ω YELLOW-RED C - S Note: Resistance at 20°C of ambient temperature. -
Page 14: Cs-C24Jkv Cu-C24Jkv
8.2. CS-C24JKV CU-C24JKV Resistance of Outdoor Fan Motor Windings Resistance of Compressor Windings MODEL CU-C24JKV MODEL CU-C24JKV CONNECTION CWA951399J CONNECTION 2J39S236A1A 59.47 Ω 0.933 Ω BLUE-YELLOW C - R 60.95 Ω 1.584 Ω YELLOW-RED C - S 80.58 Ω YELLOW-ORANGE Note: Resistance at 20°C of ambient temperature. -
Page 15: Electronic Circuit Diagram
9 Electronic Circuit Diagram... -
Page 16: Printed Circuit Board
10 Printed Circuit Board 10.1. Main Printed Circuit Board... -
Page 17: Power Printed Circuit Board
10.2. Power Printed Circuit Board... -
Page 18: Indicator Printed Circuit Board
10.3. Indicator Printed Circuit Board 10.4. Receiver Printed Circuit Board 10.5. High Voltage Power Supply Printed Circuit Board... -
Page 19: Installation Instruction
11 Installation Instruction 11.1. Select the Best Location 11.1.3. Indoor/Outdoor Unit Installation Diagram 11.1.1. Indoor Unit • Do not install the unit in excessive oil fume area such as kitchen, workshop and etc. • There should not be any heat source or steam near the unit. •... -
Page 20: Indoor Unit
11.2. Indoor Unit 11.2.1. How to Fix Installation Plate 11.2.2. To Drill a Hole in the Wall and Install a Sleeve of Piping The mounting wall shall be strong and solid enough to prevent it from the vibration. 1. Insert the piping sleeve to the hole. 2. - Page 21 1. For the right rear piping 2. For the right and right bottom piping 3. For the embedded piping...
- Page 22 (This can be used for left rear piping and bottom piping also.) 11.2.4. Connect the Cable to the Indoor Unit 1. The inside and outside connecting cable can be connected without removing the front grille. 2. a) INDOOR POWER SUPPLY MODEL (3/4 ~ 2.5HP) Connecting cable between indoor unit and outdoor unit shall be approved polychloroprene sheathed 3 x 1.5 mm...
- Page 23 b) OUTDOOR POWER SUPPLY MODEL (3.0HP) Connecting cable between indoor unit and outdoor unit shall be approved polychloroprene sheathed 4 x 1.5 mm (3/4 ~ 3.0HP) flexible cord, type designation 245 IEC 57 or heavier cord. • Secure the connecting cable onto the control board with the holder.
-
Page 24: Outdoor Unit
11.3. Outdoor Unit 11.3.1. Install the Outdoor Unit • After selecting the best location, start installation according to Indoor/Outdoor Unit Installation Diagram. 1. Fix the unit on concrete or rigid frame firmly and horizontally by bolt nut (ø10 mm). 2. When installing at roof, please consider strong wind and earthquake. Please fasten the installation stand firmly with bolt or nails. - Page 25 4(A). Checking gas leakage for left piping 1) a. Connect the manifold gauge to the service port of 3-way valve. b. Measure the pressure. 2) a. Keep it for 5-10 minutes. b. Ensure that the pressure indicated on the gauge is the same as that of measured during the first time. Evacuation (vacuum method) is recommended, for model 2.0 HP ~ 3.0 HP with the piping length more than 5 meter.
- Page 26 • If gauge needle does not move from 0 cmHg (0 MPa) to -76 cmHg (-0.1 MPa), in step above take the following measure: - If the leak stops when the piping connections are tightened further, continue working from step - If the leak does not stop when the connections are retightened, repair the location of leak.
- Page 27 5. Secure the power supply cord and connecting cable onto the control board with the holder. 6. Attach the control board cover back to the original position with screw. 7. For wire stripping and connection requirement, refer to instruction of indoor unit. •...
-
Page 28: Operation Control
12 Operation Control 12.1. Cooling Operation • Cooling operation can be set using remote control. • This operation is applied to cool down the room temperature reaches the setting temperature set on the remote control. • The remote control setting temperature, which takes the reading of intake air temperature sensor, can be adjusted from 16°C to 30°C. -
Page 29: Soft Dry Operation
12.2. Soft Dry Operation • Soft Dry operation can be set using remote control. • Soft Dry operation is applied to dehumidify and to perform a gentle cooling to the room. • This operation starts when the intake air temperature sensor reaches the setting temperature on the remote control. •... -
Page 30: Automatic Operation
12.3. Automatic Operation • Automatic operation can be set using remote control. • This operation starts to operate with indoor fan at SLo speed for 20 seconds to judge the intake air temperature. • After judged the temperature, the operation mode is determined by referring to the below standard. •... -
Page 31: Indoor Fan Speed Control
12.4. Indoor Fan Speed Control • Indoor Fan Speed can be set using remote control. 12.4.1. Fan Speed Rotation Chart Fan Speed (rpm) COOL/DRY CS-C18JKV CS-C24JKV S Hi 1390 1500 1240 1350 1140 1230 H Lo 1130 1190 C Lo... -
Page 32: Outdoor Fan Speed Control
• Auto Fan Speed during Soft Dry operation: 1. Indoor fan will rotate alternately between off and Lo-. 2. At the beginning of each compressor start operation, indoor fan will increase fan speed gradually for deodorizing purpose. 3. When compressor at turn off condition for 6 minutes, indoor fan will start fan speed at Lo- to circulate the air in the room. This is to obtain the actual reading of intake air temperature. -
Page 33: Vertical Airflow Direction Control
12.6. Vertical Airflow Direction Control 12.6.1. Auto Control • When the vertical airflow direction is set to Auto using the remote control, the louver swings up and down as shown in the diagram. • When stopped with remote control, the discharge vent is reset, and stop at the closing position. -
Page 34: Powerful Operation
12.8. Powerful Operation • To achieve the setting temperature quickly. • When Powerful operation is set, the setting temperature will be automatically decreased 3°C internally against the present setting temperature (Lower temperature limit: 16°C). • This operation automatically will be running under SHi Fan Speed (Cooling). •... -
Page 35: Timer Control
12.10. Timer Control 12.10.1. ON Timer • When the ON Timer is set by using the remote control, the unit will start to operate slightly before the set time, so that the room will reach nearly to the set temperature by the set time. •... -
Page 36: Patrol Operation
12.13. Patrol Operation • To monitor air dirtiness level by using Patrol sensor and to maintain air freshness by activates e-ion operation. • Patrol operation start condition - When the unit operation is started with “OFF/ON” button. - When the unit stops, “Patrol” button is pressed, Patrol individual operation will start. - During cooling only operation, “Patrol”... - Page 37 • Dirtiness level sensitivity adjustment. It is possible to change the Patrol sensor sensitivity, where the Threshold value (G1 ~ G4) will be shifted accordingly: 1. Press and release “SET” button. 2. Press “Timer ” / “Timer ” button to select sensitivity. –...
- Page 38 - Remote Control Receiving Sound → Patrol Mode Normal Operation : Beep • → Stop Patrol Mode : Long Beep • → Normal Operation Patrol Mode : Beep • → Patrol Stop : Beep • - Timer Control - When ON timer activates when unit stops, previous operation resumes and restored last saved patrol operation status. - When ON timer activates during any operation, no change and carry on current operation.
-
Page 39: E-Ion Operation
12.14. e-ion Operation • This operation provides clean air by producing negative ions to attract dust captured at the positively charged e-ion filters. • e-ion operation start condition - During unit running at any operation mode, if “e-ion” button is pressed, combination operation (operation mode + e-ion operation) starts. - Page 40 • Power failure - During e-ion individual operation, if power failure occurs, after power resumes, e-ion individual operation resumes immediately. - During combination operation, if power failure occurs, after power resumes, combination operation resume immediately. - e-ion operation status is not memorized after OFF the unit. After OFF, when the operation is ON again, air conditioner operates without e-ion operation.
-
Page 41: Protection Control
13 Protection Control 13.1. Restart Control (Time Delay Safety Control) • When the thermo-off temperature (temperature which compressor stops to operate) is reached during:- - Cooling operation - the compressor stops for 3 minutes (minimum) before resume operation. - Soft Dry operation - the compressor stops for 6 minutes (minimum) before resume operation. •... -
Page 42: Dew Prevention Control
• This is to prevent compressor from rotate reversely when there is an instantaneous power failure. • If this condition happens continuously for 5 times within 50 minutes, unit will turn OFF with TIMER LED blinks. • The 5 times counter can be reset when either one of the following condition happen: - Unit is OFF by remote control or AUTO OFF/ON button. -
Page 43: Servicing Mode
14 Servicing Mode 14.1. Auto OFF/ON Button 1. AUTO OPERATION MODE The Auto operation will be activated immediately once the Auto OFF/ON button is pressed. This operation can be used to operate air conditioner with limited function if remote control is misplaced or malfunction. 2. -
Page 44: Remote Control Button
14.2. Remote Control Button 14.2.1. SET BUTTON • To check current remote control transmission code and store the transmission code to EEPROM. - Press “SET” button for more than 10 seconds. - Press “TIMER SET” button until a “beep” sound is heard as confirmation of transmission code change. •... -
Page 45: Troubleshooting Guide
15 Troubleshooting Guide 15.1. Refrigeration cycle system In order to diagnose malfunctions, make sure that there are no electrical problems before inspecting the refrigeration cycle. Such problems include insufficient insulation, problem with the power source, malfunction of a compressor and a fan. The normal outlet air temperature and pressure of the refrigeration cycle depends on various conditions, the standard values for them are shown in the table to the right. - Page 46 15.1.1. Relationship between the condition of the air conditioner and pressure and electric current Cooling Mode Condition of the air conditioner Low Pressure High Pressure Electric current during operation Insufficient refrigerant (gas leakage) Clogged capillary tube or Strainer Short circuit in the indoor unit Heat radiation deficiency of the outdoor unit Inefficient compression...
-
Page 47: Disassembly And Assembly Instructions
16 Disassembly and Assembly Instructions WARNING High voltages are generated in the electrical parts area by the capacitor. Ensure that the capacitor has discharged sufficiently before proceeding with repair work. Failure to heed this caution may result in electric shocks. 16.1. - Page 48 16.1.3. To remove electronic controller...
- Page 49 16.1.4. To remove discharge grille 16.1.5. To remove control board...
- Page 50 16.1.6. To remove cross flow fan and indoor fan motor...
- Page 51 16.1.7. To align cross flow fan...
-
Page 52: Technical Data
17 Technical Data 17.1. Thermostat Characteristics Cooling Soft Dry... -
Page 53: Operation Characteristics
17.2. Operation Characteristics 17.2.1. CS-C18JKV CU-C18JKV... - Page 55 17.2.2. CS-C24JKV CU-C24JKV...
-
Page 57: Exploded View And Replacement Parts List
18 Exploded View and Replacement Parts List 18.1. Indoor Unit Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts. - Page 58 REF. NO. PART NAME & DESCRIPTION QTY. CS-C18JKV CS-C24JKV ← CHASSY COMPLETE CWD50C1623 FAN MOTOR L6CBYYYL0037 ARW7614AC ← CROSS FLOW FAN COMPLETE CWH02C1077 ← BEARING ASS’Y CWH64K007 ← SCREW - CROSS FLOW FAN CWH551146 ← ION GENERATOR CWH94C0028 EVAPORATOR CO.
-
Page 59: Outdoor Unit
18.2. Outdoor Unit Note: The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts. - Page 60 REF. NO. PART NAME & DESCRIPTION QTY. CU-C18JKV CU-C24JKV CHASSY ASS’Y CWD50K2115 CWD50K2100 COMPRESSOR 2K25S236F6A 2J39S236A1A ← ANTI - VIBRATION BUSHING CWH50055 ← NUT - COMPRESSOR MOUNT CWH561049 ← PACKING CWB81043 CONDENSER CWB32C2691 CWB32C2692 ← SOUND PROOF BOARD CWH151051 ← FAN MOTOR BRACKET CWD541065 ←...
