KWC ONO highflex 10.151.413.000 Installation And Service Instructions Manual
Kitchen faucet
Hide thumbs
Also See for ONO highflex 10.151.413.000:
- Installation and service instructions manual (16 pages) ,
- Installation and service instructions manual (146 pages)
Advertisement
Table of Contents
- 1 Operating Data
- 2 Environmental Conditions
- 3 Periodic Checks
- 4 Corrosion
- 5 Mechanical Damage
- 6 Examples of Assembly
- 7 Installation
- 8 Rinse
- 9 Functions
- 10 Disassembling Diverter
- 11 Spare Parts
- 12 Maintenance
- 13 Cleaning Instructions
- 14 Installation and Service Instructions
- 15 Subject to Technical Alteration
- Download this manual
802353
10.151.413.000
10.151.413.700
10.151.423.000
10.151.423.700
Franke Water Systems AG
KWC | Hauptstrasse 57 | P.O. Box 179 | CH-5726 Unterkulm | Phone +41 62 768 68 68 | www.kwc.com
Montage- und Serviceanleitung
Instructions de montage et d'entretien
Istruzioni di montaggio e di assistenza
Instrucciones de montaje y servicio
KWC ONO
®
10.152.423.000
10.152.413.000
10.153.423.000
Advertisement
Table of Contents
Related Manuals for KWC ONO highflex 10.151.413.000
Summary of Contents for KWC ONO highflex 10.151.413.000
- Page 1 Instrucciones de montaje y servicio 802353 Installation and service instructions KWC ONO ® 10.151.413.000 10.152.413.000 10.151.413.700 10.151.423.000 10.152.423.000 10.153.423.000 10.151.423.700 Franke Water Systems AG KWC | Hauptstrasse 57 | P.O. Box 179 | CH-5726 Unterkulm | Phone +41 62 768 68 68 | www.kwc.com...
- Page 2 Pour informations supplémentaires voir nos För ytteligare information se produktblad. documentations de vente détaillées. KWC VG Franke WS/KS Franke WS/KS KWC Deutschland GmbH Franke Consumer Products Franke S.p.A. Junghansring 70 Via Pignolini 2 Luxury Products Group DE-72108 Rottenburg 800 Aviation Parkway IT –...
- Page 3 Umgebungsbedingungen Conditions d‘environnement Ambiente circostante In unmittelbarer Nähe von Aucun produit de nettoyage ni Non conservare detergenti o so- Armaturen und Anschlussschläu- détergent chimique ne doit être stanze chimiche nelle immediate chen dürfen keine Reinigungs- stocké à proximité immédiate des vicinanze della rubinetteria e dei mittel und Chemikalien gelagert robinetteries et des raccordements...
- Page 6 Z.536.051.000 Z.536.051.700 ø35mm / 1 3/8" EU/AUS Beim Anschliessen zwingend gemäss Abbildung oberhalb der Mutter gegenhalten! ø35mm / Pour le raccordement, il est impératif 1 3/8" d'appliquer une force contraire au-dessus de l'écrou (voir illustration)! Radius min. Eseguire il collegamento sopra il = 50mm / 2"...
- Page 7 Kalt- und Warmwasser öffnen. Ouvrir eau froide et chaude. Aprire acqua fredda e calda. Abrir la salida de agua fría y caliente. Open cold and hot water. D spülen F rincer sciacquate Sp enjuagar E flush R max. = 320mm / 12 5/8“...
- Page 8 10.151.423.000 10.151.423.700 Inbus / Allen Neu/New Z.536.936 Inbus / Allen...
- Page 9 Inbus / Allen Inbus / Allen...
- Page 10 10.151.413.000 10.151.413.700 Z.535.965 Z.535.966 Z.635.322.700 Z.534.836 Z.635.276.700 Z.634.912 Z.535.991.000 Z.536.051.000 Z.535.995.700 9 Nm +/- 1 Nm SW 32 Z.536.051.700 Z.535.664.000 Z.536.288 Z.535.664.700 Z.634.938.700 Z.532.241 Z.532.241 Z.535.967 ø 10 mm M24x1 Z.635.231 Z.535.651 L 550 mm Adapter 3/8” x 1/2” Z.635.392 Z.535.739 3/8”...
- Page 11 10.152.413.000 Z.535.965 Z.535.556.000 Z.535.966 Z.635.276.700 Z.635.322.700 Z.634.938 Z.535.557.000 Z.536.288 Z.634.912 SW 32 Z.534.836 9 Nm +/- 1 Nm Z.536.051.000 Z.536.051.000 Z.536.051.700 Z.536.051.700 Z.532.241 Z.532.241 Z.535.967 Z.535.967 M16x1 3/8” 3/8" Z.535.651 L 550 mm Z.635.392 M24x1 Z.635.231 3/8"...
- Page 12 Z.535.850.000 Z.536.193.700 10.151.423.000 10.151.423.700 Z.535.963.000 Z.535.963.700 Z.535.964 Z.535.846 Z.535.966 Z.635.322.700 Z.536.936 Z.534.836 Z.635.276.700 Z.536.051.000 Z.535.991.000 Z.536.051.700 Z.535.995.700 Z.634.912 9 Nm +/- 1 Nm SW 32 Z.535.664.000 Z.536.288 Z.535.664.700 Z.634.938.700 Z.532.241 Z.532.241 Z.535.967 ø 10 mm M24x1 Z.635.231 Z.535.651 L 550 mm Adapter 3/8”...
- Page 13 Z.635.392 10.152.423.000 Z.535.850.000 Z.535.963.000 Z.535.964 Z.535.846 Z.535.965 Z.535.968 Z.535.966 Z.635.322.700 Z.635.322.700 Z.534.836 Z.635.276.700 Z.634.912 Z.536.051.000 Z.536.051.000 Z.535.991.000 9 Nm +/- 1 Nm SW 32 Z.536.051.700 Z.536.051.700 Z.535.664.000 Z.536.288 Z.634.938.700 Z.532.241 Z.532.241 Z.535.967 Z.535.967 3/8" 3/8" 3/8" Z.536.231 Z.535.784 Z.535.783 L 600 mm L 500 mm M24x1 Z.635.231...
- Page 14 10.153.423.000 Z.535.963.000 Z.535.850.000 Z.535.964 Z.535.846 Z.535.556.000 Z.535.965 Z.535.968 Z.535.966 Z.635.276.700 Z.634.938 Z.635.322.700 Z.635.322.700 Z.535.557.000 Z.536.288 Z.634.912 SW 32 Z.534.836 9 Nm +/- 1 Nm Z.536.051.000 Z.536.051.000 Z.536.051.000 Z.536.051.700 Z.536.051.700 Z.536.051.700 Z.532.241 Z.532.241 Z.532.241 Z.535.967 Z.535.967 Z.535.967 3/8" 3/8" 3/8" 3/8" Z.536.231 Z.535.651 L 550 mm...
- Page 15 Grundsätzliche Reinigungshinweise: Avisos básicos de limpieza: - Beim Reinigen muss die Oberfläche der Armatur kalt sein (Wärme - Cuando se procede a limpiar la griferia, su superficie debe estar beschleunigt die Zerstörung der Oberfläche)! fria (el calor acelera la destrucción de la superficie)! - Reinigungshinweise der Reinigungsmittelhersteller beachten! - Respetar los avisos de limpieza del fabricante del detergente! Die Pflege:...
- Page 17 Reciclaje del documento sobre base del papel usado del 100%. Recycling paper on 100% waste paper basis. Franke Water Systems AG KWC | Hauptstrasse 57 | P.O. Box 179 | CH-5726 Unterkulm | Phone +41 62 768 68 68 | www.kwc.com...
- Page 18 R max. = 320mm / 12 5/8“ Z.635.392 KWC VG Franke WS/KS Franke WS/KS KWC Deutschland GmbH Franke S.p.A. Franke Consumer Products Junghansring 70 Via Pignolini 2 Luxury Products Group DE-72108 Rottenburg 800 Aviation Parkway IT – 37019 Peschiera del Garda...
