This notice must be translated (possibly by the retailer) into the language of the country of use.
For your safety, comply strictly with the instructions for use, verification, maintenance and storage.
ABS SAFETY GmbH cannot be held liable for any direct or indirect accident occurring as a result of use other than provided for in this notice; do not use this
equipment beyond its capabilities!
USE AND PRECAUTIONS:
A retractable fall arrester is a piece of personal protection equipment; it should be allocated to a single user (it can only be used by one person at a time). When
the user moves (up or down), the cable winds onto and unwinds from a pulley. The cable/webbing is kept taut by means of a return spring. In the event of a fall,
a system locks the cable and prevents it unwinding, thus stopping the fall instantly.
User safety relies on the effectiveness of the equipment and full understanding of the safety instructions contained in this leaflet.
Product markings should be checked periodically for legibility.
The upper swivel is linked to an anchor point by a connector (EN362) and the other end (cable or strap) is attached onto a safety point on a harness.
Sharp edges, small diameter structures and corrosion should be avoided as they may affect the performance of the cable or strap; or they should be adequately
protected.
The device's anchoring point must be positioned above the user) and must comply with standard EN795 (R>12kN - EN795:2012 or R>10kN - EN795:1996).
Ensure that the general arrangement limits swinging in the event of a fall, and that the work is done in such a way as to limit the risk and the height of a fall.
For safety reasons and before each use, make sure that in the event of a fall there is no obstacle obstructing the normal deployment of the cable or strap.
The minimum free space should be: 3 m under the user's feet.
* It is essential for safety reason to verify the clearance at the work place before each use and during use in order to be sure there will be no collision with the
ground or obstacle in case of fall. Take particular attention to obstacle in movement (for example truck, mobile work platform, ...).

HORIZONTAL USE:

ABS SAFETY GmbH retractable fall arresters (PS-BL-B-2, PS-BL-B-12) have passed the tests for horizontal use for edges with a radius of
r>=0.5mm / Type A (according to European specification sheet 11.060). To be used in horizontal condition, the anchorage point must be
located at the same level as the edge, where the risk of fall exists. In order to avoid pendulum effects, the working area must not exceed a 30°
angle limit, from each side of the vertical of the anchorage point.
Use the product between: -30°C / 50°C.
We also recommend that you do not suddenly let go of the cable when it is rolled out; it is better to keep a hand on it as it reels into the retractable fall arrester.
Before and during use, we recommend that you take all the necessary precautions for a safe rescue should it be needed.
This equipment is for the sole use of people trained, skilled and in good health, or under the supervision of a trained and skilled person. Warning! Certain
medical conditions may affect user safety; if in doubt, consult your doctor.
Be aware of the hazards that could reduce the performance of your equipment, and therefore the user's safety, if exposed to extreme temperatures (< -30°C or
> 50°C), prolonged exposure to the elements (UV rays, humidity), chemical agents, electrical constraints, twisting of the fall arrest system during use, sharp
edges, friction or cutting, etc.
Before using, always check that the locking system is in working order and that the fall indicator is not triggered (if there is one on the connector). Check that
the cable/webbing is not cut, frayed or burnt. Check that the metal parts are not deformed or oxidized, and check that the connectors are working properly
(locking/opening). The protective casings must be in place and undamaged. Product markings must remain legible. If there is any doubt as to the condition of
the device, or after a fall, it must not be reused (marking it with the words "DO NOT USE" is recommended) and must be returned to the manufacturer or to a
qualified person appointed by the manufacturer.
Do not remove, add or replace any component of the product.
Chemical products: put the system out of use if it is exposed to chemical products, solvents or fuels which could affect its working.

TECHNICAL DATA:

Cable diameter: 4,5 mm - Material: galvanized steel – breaking point > 12 kN
Webbing: 25 mm – Material: polyester – breaking point > 15 kN.

SUITABILITY FOR USE:

The equipment should be used with a fall arrest system as specified in the data sheet (see standard EN363) to guarantee that the dynamic force exerted on the
user during the arrest of a fall is maxi 6 kN. A fall arrest harness (EN361) is the only body-gripping device that may be used. It may be dangerous to create
one's own fall arrest system where each safety function can interfere with another safety function. Therefore, it is important to read the recommendations on
using each component in the system before use.
VERIFICATION:
The recommended service life of the equipment is 10 years (in accordance with the annual examination by a competent person authorized by ABS SAFETY
GmbH) for devices with a cable lanyard or webbing lanyard, but it may be increased or reduced according to use and/or the results of the annual inspections.
The equipment should be inspected if there is any doubt, or following a fall and at least annually, by the manufacturer or a competent person authorized by the
manufacturer to check its strength and hence the user's safety. The product's factsheet must be completed (in writing) after each check, the inspection date and
the date of the next inspection must be indicated on the factsheet, it is also advisable to specify the date of the next inspection on the product.
SERVICING AND STORAGE: (Comply strictly with these instructions)
During transport, keep the product in its packaging, well away from any cutting surface; clean it with water, wipe it with a rag and hang it up in a well-
ventilated location, to let it dry naturally and away from a naked flame or heat source; follow the same procedure for components that have become damp
during use. The system must be stored in its packaging in a dry, well aired place protected from extremes of temperature.
