- Page 1 SUNCONTROL2 User manual Valid for the following models SC320M SC350M...
- Page 2 INSTRUCTIONS FOR THE PROPER DISPOSAL This electronic product is subject to the European Directive 2012/19 / EU. Comply with local waste disposal regulations, do not dispose of old products with normal household waste. The proper disposal of products that can no longer be used prevents potential negative consequences for the environment and for the population.
-
Page 3: Table Of Contents
INDEX 1. Safety instructions 2. Package contents 3. DESCRIPTION 4. operations 5. installation 6. charging curve selection 7. Led indicators 8. Fuse replacement 9. Technical features 10.F.A.Q. 11. warranty... -
Page 4: Safety Instructions
• The information contained in this manual may be changed without notice. NDS Energy s.r.l. reserves the right to make changes and improvements to the product at any time without notice and without obligation to apply these changes to the devices previously distributed. -
Page 5: Package Contents
N° 1 Replacement fuse • Wall mounting screws 3. DESCRIPTION SUNCONTROL2, the automatic solar regulator with MPPT technology to push the efficiency of photovoltaic modules to the maximum: more energy, less space. The MPPT algorithm always uses the "maximum power peak"... - Page 6 The touch screen display DT002 (optional) with new management software, allows you to view the charge information and set the various settings with the new communication protocol NDS. MAIN FEATURES • MPPT technology (+25% performances) • Charging curve selection: Wet, GEL, AGM e LiFePO •...
-
Page 7: Operations
4. operations SUNCONTROL2, charges up to two batteries: one service battery (B1) and one starter battery (B2), with priority charging to the service battery. SUNCONTROL2 will start charging the batteries if the following conditions are satisfi ed: 1. The connected Solar Panels deliver a voltage 1V higher than the voltage of the batteries to be recharged. -
Page 8: Installation
5. installation Place the SUNCONTROL2 on the chosen surface and secure the entire device using the fixing holes integrated in the shell with the supplied screws or equivalent (Fig.1). Fig. 1 All electrical and setup connections are on the front, it is not necessary to disassemble the plastic shells, except for the protection fuse replacement. - Page 9 3 4 5 6 7 8 9 10 N° PIN CONNECTION Display Connection Secondary connection (for future connections) Solar Panel Negative poles Batteries Negative poles Solar Panel 1 Positive pole Solar Panel 2 Positive pole Leisure battery Positive pole (B1) Starting battery Positive pole (B2) Dip Switch - Charging curve selection Temperature sensor connection for B1 (optional)
-
Page 10: Charging Curve Selection
6. charging curve selection The Dip Switches, located next to the power connections, allow you to select the proper charging curve for the installed services battery, use the table to set the correct curve for your battery. The Dip Switches affect the B1 charging curve (leisure battery), not B2 (starter battery). - Page 11 CHARGING CURVE B1 - PHASE DISCUSSION With voltage between 8V and 10.5V, a current PULSE CHARGE between 1A and 2A will be delivered, every 5 seconds. Timeout 4 hours. With voltage between 10.5V and 12.0V, an RECONDITIONING approximately 2A costant current will be delivered. Timeout 8 hours.
-
Page 12: Led Indicators
B2 - PHASE DISCUSSION With voltage between 8V and 10.5V, a variable PULSE CHARGE current between 1A and 2A, every 5 seconds. Timeout 4 hours. With voltage between 10.5V and 12.0V, an RECONDITIONING approximately 2A costant current will be delivered. Timeout 8 hours. -
Page 13: Fuse Replacement
8. Fuse replacement If the protective fuse on the SUNCONTROL2 electronic board is damaged, it can be replaced with the original replacement fuse (supplied) or with a common 25A (for SC320M) or 30A (for SC350M) automotive fuse. FUSE: • 25A (SC320M) •... -
Page 14: Technical Features
9. Technical features DESCRIPTION SC320M SC350M INPUTS Maximum input Voltage solar 29,5V 29,5V panels (open circuit voltage) Solar Panel input Connections Solar Panel input Maximum Power 50W - 160W 50W - 180W Suppoerted OUTPUT B1 Battery nominal voltage Charging current maximum output Minumum battery capacity 60Ah 80Ah... - Page 15 OUTPUT B2 Battery nominal voltage Charging current maximum output Minumum battery capacity 15Ah/10Ah 15Ah/10Ah required Lead-acid/LiFePO Minimum/maximum voltage 8V / 12,5V 8V / 12,5V starting charge Maximum charging voltage 14,4V 14,4V Temperature regulated fan speed Maximum charging timeout GENERAL Charging algorithm OPTICHARGE Stand-by self-consumption <2mA <2mA...
-
Page 16: F.a.q
Is it possible to connect one 200W solar panel only, on a single SUNCONTROL2 connection? It’s possible to connect just one bigger solar panel (200W), for example on SUNCONTROL2 Pin N°5, but you must connect Pin N°5 and Pin N°6. Use, at least, a 6 mm cross-size cable. -
Page 17: Warranty
11. warranty... - Page 20 Tutta l’energia che ti serve all the energy you need 0037_MANB_Sc320_Sc350_GB02 NDS ENERGY s.r.l. Via Pascoli, 169 65010 Cappelle sul Tavo (Pe) Italy Tel.:+39 085 4470396 web: www.ndsenergy.it email: customer@ndsenergy.it LIKE US: facebook.com/ndsenergysrl...
