TABLE OF CONTENTS

I USER NOTICE
II PRODUCT SPECIFICATIONS
III PACKING LIST
IV PRODUCT OVERVIEW
V PART NAMES AND FUNCTIONS
VI PREPARATION
6.1 The Case
6.2 Power Supply Preparation
VII MENU OPERATION & FUNCTION
7.1 Button Position
7.2 Button Function
7.3 Overview of Menu Functions
7.4 HDMI Output
VIII BASIC OPERATION
8.1 Turning On/Off
8.2 Inserting the Insertion Tube into the Machinery or
Equipment Being Borescoped
8.3 Recording Images
8.4 Image Playback
IX STORAGE AND MAINTENANCE
9.1 Cleaning
9.2 Repacking
9.3 Storage
X TROUBLESHOOTING
10.1 Troubleshooting Guidelines
10.2 Repair
PRODUCT WARRANTY
EXTERNAL SPECIFICATION

USER NOTICE

I
Please read this user manual carefully before operation.
1
WARNING
4
1. Do not use or store in a place with explosives, a strong magnetic field or
6
combustible gas.
2. Unauthorized dismantling or modification of this borescope
7
voids the warranty.
8
3. Make sure the power is turned off before putting the instrument into
the carrying case.
9
4. Never touch the lens/LED module during or immediately after use.
9
Contact may cause burns.
10
5. If smoke or abnormal noise is detected, stop using and turn off the
12 borescope immediately.
12
6. Do not look directly look at the light from the end of the insertion tube.
13
It is extremely bright and can cause eye damage.
13
7. If any abnormality is noticed during operation, stop using and turn off the
17
borescope immediately.
18
18
ATTENTION
19
1. Only use this borescope within the approved operating
19
temperature range.
21
2. DO NOT over-torque, bend, twist, or fold the insertion tube. Doing so
22
could damage the articulation control wire assemblies and/or electrical
22
wiring.
22
3. Only use the power adapter provided by ViewTech.
22
4. DO NOT yank or attempt to forcefully remove the insertion tube if it
becomes stuck inside the equipment being borescoped. When extracting
23
the insertion tube from the inspection area:
34
a. Be sure that the bending section (distal tip of the insertion tube)
23
is straight. Use the joystick to remove any angle before attempting
removal.
24
b. If the insertion tube becomes stuck during removal, gently rotate
25
the joystick until it becomes loose again.
5. After use, center the joystick in order to straighten the bending section
prior to storage. The borescope should always be stored with the bending
section straight (do not force the bending section with your fingers -
always use the joystick to adjust and straighten the bending angle.)
1
