- Page 1 CEBORA S.p.A. TIG SOUND DC – AC/DC CONTROL PANELS art. 213 – 216 – 218 – 220 REMOTE CONTROL MODULE art. 222 SERVICE MANUAL 3.302.041 25/10/00...
-
Page 2: Table Of Contents
- External panel board code 5.600.853/B......................10 4.3.1 - Topographical drawing............................10 4.3.2 - Connector table..............................10 - Optic interface board power source side code 5.600.763 (art. 222)............11 4.4.1 - Topographical drawing............................11 4.4.2 - Connector table..............................11 - Optic interface board control panel side code 5.600.768 (art. 222)............11 4.5.1... -
Page 3: General Information
This manual has been prepared for the purpose of training personnel assigned to carry out maintenance on Control panels art. 213, 216, 218, 220 and the remote control module art. 222. These articles must be used in TIG SOUND DC and TIG SOUND AC/DC welding systems combined with power sources art. -
Page 4: System Description
Control panels art. 213, 216, 218 and 220 are the control panels of the power sources for TIG SOUND DC 2640/T and TIG SOUND AC/DC 2540/T welding systems. The remote control module art. 222 allows you to connect the aforementioned control panels at a distance from the power sources. -
Page 5: Maintenance
CEBORA S.p.A. 3 - MAINTENANCE WARNINGS ANY INTERNAL INSPECTIONS OR REPAIRS MUST BE CARRIED OUT BY QUALIFIED PERSONNEL. UNPLUG THE UNIT FROM THE POWER MAINS AND WAIT FOR THE INTERNAL CAPACITORS TO DISCHARGE (2 MINUTES) BEFORE PERFORMING MAINTENANCE. 3.1 - Periodic inspection, cleaning. -
Page 6: Remote Control Module (Art. 222)
REGULAR OPERATION. 3.2.1 - Remote control module (art. 222). To check the operation of the remote control module art. 222, carry out the sequence described above, with the control panel connected remotely. The same results should also be obtained in this case. -
Page 7: Troubleshooting
CEBORA S.p.A. 3.3 - Troubleshooting. Given the particular type of equipment represented by the control panels, troubleshooting must also be carried out considering the part relating to the power source to which the panel is connected (see power source Service Manual). -
Page 8: Control Panel Lit, Power Source Running, Some Functions Are Not Possible
CEBORA S.p.A. ♦ Check the wiring between connector J1 micro board on control panel and J3 satellite board on power source. ♦ Make sure the satellite board is correctly mounted on the power source control board. ♦ Replace satellite board on power source. -
Page 9: Electrical Diagrams
CEBORA S.p.A. 4 - ELECTRICAL DIAGRAMS 4.1 - Micro board code 5.602.005/A. 4.1.1 - Topographical drawing. 4.1.2 - Connector tables. Connector Terminals Function 1-2-3-4 RS485 communication line signals. 5 – 6 5 Vdc power supply for RS485 communication line. connector for microprocessor programming. -
Page 10: Display Board Code 5.600.748/A (Art. 220)
CEBORA S.p.A. 4.2 - Display board code 5.600.748/A (art. 220). 4.2.1 - Topographical drawing. 4.2.2 - Connector table. Connector Terminals Function digital signal bus to/from micro boards and external panel. digital signal bus to/from micro boards. 4.3 - External panel board code 5.600.853/B. -
Page 11: Optic Interface Board Power Source Side Code 5.600.763 (Art. 222)
CEBORA S.p.A. 4.4 - Optic interface board power source side code 5.600.763 (art. 222). 4.4.1 - Topographical drawing. 4.4.2 - Connector table. Connector Terminals Function 1-2-3-4 RS485 communication line signals (from satellite board). 5 - 6 5 Vdc power supply input for RS485 communication line.
