  • Page 1 585-350-213 Issue 1 October, 1993 Table of Contents Upgrade Kit for Map/40 Graphics ©...
  • Page 2 Blank Page...

  • Page 3: Table Of Contents

    Heeding Warnings Avoiding Electrostatic Discharge Damage Unpacking the Upgrade Kit Inventory of Upgrade Kit Items Gathering Tools and Test Equipment Locating Key Components in the MAP/40 The Front of the Chassis Locating the Peripheral Drive Devices 1-11 Chassis Cooling System...
  • Page 4 Upgrading Circuit Cards What’s in This Chapter General Steps for Circuit Card Installation Installing a Circuit Card in the MAP/40 The 486 CPU Circuit Card – 50MHz or 25MHz Verifying Jumpers on the 486 50MHz CPU Verify the Jumpers on the 486 25MHz CPU...
  • Page 5 Contents Installing the SCSI Host Adapter Circuit Card 4-12 Installing the Floppy Disk Drive 4-12 Finishing Up 4-12 Index IN-1...
  • Page 6 Contents...

  • Page 7: About This Book

    About This Book Purpose This book, Upgrade Kit for MAP/40 , 585-350-213, describes the procedures for upgrading both a MAP/40 from a 386 CPU to a 486 CPU, and from IDE to SCSI disk drive system. Intended Audiences This book is intended primarily for the technician. Secondary audiences include the following: customer, field support, customer support, and factory assemble, load, and test (ALT) personnel.

  • Page 8: How This Book Is Organized

    Chapter 2, ‘‘Getting Inside the Platform’’ This chapter describes how to open the MAP/40 by removing the dress cover of the chassis, as well as how to access the peripheral bay and card cage.

  • Page 9: Related Resources

    About This Book Related Resources The following books are expected to be used in conjunction with this book: MAP/40 Voice Processing Hardware Installation , 585-350-109 CONVERSANT Voice Information System Version 4.0 Maintenance , 585- 350-112 How to Make Comments About This Book A reader comment card is behind the title page of this book.
  • Page 10 About This Book...

  • Page 11: Getting Started

    Getting Started What’s in This Chapter This chapter describes warnings about the MAP/40, how to avoid electrostatic damage to hardware items, how to unpack the kit, the importance of saving pack- ing materials, items in the kit, and tools you need.
  • Page 12 The manufacturer(s) does not accept liability for a damaged unit if the unit is not returned in the original packing materials and carton. The carton has been designed to ensure product warranty and to prevent damage. WARNING: Do not use the dress cover of the MAP/40 as a way to lift it.

  • Page 13: Avoiding Electrostatic Discharge Damage

    Getting Started Avoiding Electrostatic Discharge Damage The human body can collect thousands of volts of destructive static electricity from ordinary activities, for example, walking on a rug, handling synthetic materi- als, or wearing synthetic clothes. When this static electricity discharges onto another surface at a different voltage potential, it is called electrostatic discharge or ESD .
  • Page 14 Getting Started Figure 1-1. How to Hold a Short Circuit Card...
  • Page 15 Getting Started Figure 1-2. How to Hold a Long Circuit Card...

  • Page 16: Unpacking The Upgrade Kit

    Getting Started ESD sensitive area (bottom surface) Recommended holding points Figure 1-3. Electronic Component ESD Sensitive Area Unpacking the Upgrade Kit Save the shipping carton and all packing materials to use in the event the unit needs to be returned to the manufacturer. Packing materials include anti-static bags and bubble wrap as well as cardboard and foam inlays.

  • Page 17: Inventory Of Upgrade Kit Items

    3. Remove and lay out each item in the container. 4. Use the list below to ensure that you received all the items in the kit. Inventory of Upgrade Kit Items The MAP/40 486 CPU/SCSI upgrade kit contains the following items: One D486SX/25-00-ATT CPU One 16 Mbyte SIMM...

  • Page 18: Gathering Tools And Test Equipment

    Flashlight or auxiliary lighting if in dimly lit area Locating Key Components in the MAP/ Use the following sections and diagrams to locate key components on the unit. For additional information describing the MAP/40 hardware, see the system description for your application. The Front of the Chassis See the table below for descriptions and functions of components on the front of the chassis that are important for this kit.
  • Page 19 Description Function bezel cover upper covers peripheral bay – disk drives power/reset center con- rocker switch turns MAP/40 on and off switch trol panel Power-On center con- lights green when power is on indicator trol panel INT Drive center con-...
  • Page 20 Position 1 Position 2 Peripheral device location Position 3 Position 4 Disk INT activity hidden area indicator (GRN) Control panel Power-On indicator (GRN) Internally mounted Chassis fan Lower bezel cover Figure 1-4. Front View of the MAP/40 1-10...

  • Page 21: Locating The Peripheral Drive Devices

    Getting Started Locating the Peripheral Drive Devices Locate the various drives in the peripheral bay behind the upper bezel cover. Table 1-2. Peripheral Bay Drives Peripheral Drive Description Function Bay Location WANGTEK 125MB Backup & restore Cartridge tape After upgrade: After upgrade: 2 load system WANGTEK 525MB...

  • Page 22: The Back Of The Chassis

    Getting Started The Back of the Chassis Figure 1-5 shows the back view of the MAP/40. See the table below for the loca- tion and description of components on the back of the MAP/40 chassis that are important for this kit.
  • Page 23 Video card MAP/40 faceplate AC input receptacle CPU card faceplate COM1 port I/O Parallel port I/O MAP/40 agency approval label Rear keyboard for radiated interface option emissions (FCC/CSA) Chassis rear air exhaust vents Figure 1-5. Back View of the MAP/40 1-13...
  • Page 24 Getting Started 1-14...

  • Page 25: Getting Inside The Platform

    Getting Inside the Platform What’s in This Chapter This chapter describes how to open the MAP/40 by removing the dress cover over the chassis and by removing the access panel to the circuit card cage. This chap- ter also describes how to replace both the dress cover and the access panel.

  • Page 26: Removing Power From The Platform

    Use a Phillips #2 screwdriver to remove the dress cover from the chassis as fol- lows (see Figure 2-1): 1. In a tower configuration, keep the MAP/40 in an upright, vertical position on the support base. 2. Locate two screws on the bottom, left side and right side corners of the chassis cover.
  • Page 27 Getting Inside the Platform 6. Be aware that, as more of the dress cover is removed, it may begin to col- lapse inward from the pressure of your hands. Move your hands down- ward on the dress panel to reduce the pressure as you lift. 7.

  • Page 28: Removing The Card Cage Access Panel

    Use a Phillips #2 screwdriver to remove the left access panel in order to reach the circuit card cage as follows (see Figure 2-2): 1. Place the MAP/40 on its side using one of the two methods below if you intend to work inside the computer.
  • Page 29 Getting Inside the Platform Access cover Tower configuration - place unit on its side with support base extended over edge Retainer, circuit card Figure 2-2. Removing the Card Cage Access Cover...

  • Page 30: Removing The Card Cage Retaining Bracket

    Removing the Card Cage Retaining Bracket The manufacturer equips the MAP/40 card cage area with a retainer to reduce shipping and environmental vibrations that could damage the circuit cards. Use a Phillips #2 screwdriver to remove the two hold-down screws in the retaining...
  • Page 31 Getting Inside the Platform Retaining bracket Remove 2 screws Figure 2-4. Removing Screws in the Retaining Bracket...

  • Page 32: Replacing The Card Cage Access Panel And Dress Cover

    Getting Inside the Platform Replacing the Card Cage Access Panel and Dress Cover Replace the circuit card cage access panel and dress cover as follows: 1. Remount the circuit card cage retaining bracket, leaving the two Phillips screws only partially mounted to provide adequate access cover clearance. 2.

  • Page 33: Upgrading Circuit Cards

    Upgrading Circuit Cards What’s in This Chapter This chapter serves as an introduction to the circuit cards that you will be upgrad- ing as part of this upgrade kit. This chapter also includes ‘‘General Steps for Cir- cuit Card Installation’’ which applies to the installation of all circuit cards, though additional steps may be required for some.

  • Page 34: Installing A Circuit Card In The Map/40

    Remove the configuration floppy diskette, if you have had the MAP/40 only operating in order to run the configuration program. 5. Turn off the MAP/40 front panel main power switch and remove the incom- ing AC power cord. Also disconnect keyboard and video cords from the MAP/40.
  • Page 35 Do not lose the bracket screws, place them where you can relocate them. See Chapter 2, ‘‘Getting Inside the Platform’’, for more information. 9. Place the MAP/40 on its side to more easily work within the circuit card cage. Use one of the following two methods: a.

  • Page 36: The 486 Cpu Circuit Card - 50Mhz Or 25Mhz

    Wear a ground wrist strap against your bare skin and connect to an earth ground. Either a 486 50MHz or 486 25MHz CPU circuit can be used in the MAP/40 plat- form. You must use a 486 50MHz if you are using the Graphical Speech Editor feature package.
  • Page 37 Upgrading Circuit Cards Figure 3-1. 486 CPU Circuit Card and Jumper Locations...

  • Page 38: Verifying Jumpers On The 486 50Mhz Cpu

    Upgrading Circuit Cards Verifying Jumpers on the 486 50MHz CPU Jumpers on the 486 50MHz should be set as indicated in the figure below. Figure 3-2. Jumper Settings for the 486 50MHz CPU Card...

  • Page 39: Verify The Jumpers On The 486 25Mhz Cpu

    Upgrading Circuit Cards Verify the Jumpers on the 486 25MHz CPU Jumpers on the 486 25MHz should be set as indicated in the figure below. Figure 3-3. Jumpers Settings for the 486 MHz CPU Card...

  • Page 40: Verifying Switch Settings On The 486 Cpu

    Upgrading Circuit Cards Verifying Switch Settings on the 486 CPU Switches are set by the manufacturer. Use the figure below to verify correct switch settings on the 486. These switch settings are correct for either the 486 50MHz or 25MHz. Figure 3-4.
  • Page 41 Upgrading Circuit Cards The header connector numbers are written on the circuit card on the right side of the pin connectors. The header connectors are numbered as follows: COM1 – J4 keyed for connection COM2 – J3 user red tracer for connection Keyboard –...

  • Page 42: The Scsi Host Adapter Circuit Card

    Upgrading Circuit Cards The SCSI Host Adapter Circuit Card The Small Computer System Interface (SCSI) Host Adapter controller card con- trols the hard disk drives, the floppy disk drive, the cartridge tape drive, as well as the SCSI Bus LED front chassis panel indicators for these drives. In this upgrade procedure, you will be replacing your system’s existing hard disk controller card (and possibly a cartridge tape controller card) with the SCSI host adapter control- ler card.
  • Page 43 Upgrading Circuit Cards Figure 3-5. SCSI Host Adapter Controller Circuit Card 3-11...

  • Page 44: Verify The Jumpers On The Scsi Circuit Card

    Upgrading Circuit Cards Verify the Jumpers on the SCSI Circuit Card Jumpers on the SCSI circuit card should be set as indicated in the figure below. Figure 3-6. Jumpers Settings for the SCSI Circuit Card 3-12...

  • Page 45: Verifying Switch Settings On The Scsi Circuit Card

    Upgrading Circuit Cards Verifying Switch Settings on the SCSI Circuit Card Switches are set by the manufacturer. Use the figure below to verify correct switch settings. Figure 3-7. Switch Settings for the SCSI Circuit Card 3-13...

  • Page 46: The Remote Maintenance Card

    Upgrading Circuit Cards The Remote Maintenance Card The Remote Maintenance (RMB) card is PC-AT based. It draws its power from the PC host bus. An optional external AC power adapter is available that plugs into the faceplate of the RMB card. This adapter provides power to operate the RMB card in situations where the power supply in the system fails.

  • Page 47: Performing The Upgrade

    Gather the appropriate tools, the components of the upgrade kit, and a space to place the old components you remove from the MAP/40 (hint: have an empty box to place old components in to avoid mixing them in with the new kit components).

  • Page 48: Removing Old Circuit Cards

    CPU card. If for some reason your cables are NOT identified, you should mark your communication port cable at this time. 3. Remove the 386 CPU card from slot #9 in the MAP/40 following the stan- dard removal procedure found in Chapter 10 of MAP/40 Voice Processing Hardware Installation , 585-350-109.

  • Page 49: Installing The 486 Cpu Card And Remote Maintenance Card

    Performing the Upgrade Installing the 486 CPU Card and Remote Maintenance Card 1. Pick up the CPU/RMB keyboard adapter and plug the new keyboard/reset extension cable connector onto J2 of this adapter. Refer to Figure 4-1 to see the proper orientation. 2.
  • Page 50 Performing the Upgrade 3. Install the CPU/RMB keyboard adapter with assembled cables onto the backplane. The adapter must have the headers facing away; the adapter should form the shape of a “U.” See Figure 4-2. 4. Plug the new keyboard/reset extension cable onto the existing keyboard/ reset cable removed earlier from the 386 CPU.
  • Page 51 Performing the Upgrade Figure 4-2. CPU/RMB Keyboard Adapter Installed in the MAP/40...

  • Page 52: Removing The Old Drive Units

    4. From either side of the peripheral bay, locate the two screws on each side of the drive units. Remove these screws (8 screws total) and save. 5. Slide each unit out through the front of the MAP/40. 6. Because the SCSI cable connects to both the disk and tape units, the floppy drive needs to be removed from position 1.
  • Page 53 Performing the Upgrade 6. Remove the terminating resistors, RN1 and RN2, using needle nose pliers. Discard the resistors. See Figure 4-3. MOTOR START PARITY SCSI ID 0 SCSI ID 1 WITH POWER Power cable receptacle PIN 2 Faceplate Terminating Resistors PIN 50 SCSI cable receptacle...
  • Page 54 Performing the Upgrade 7. Set the disk aside and open the Universal Installation Kit which contains the installation hardware. The kit contains two bags. One bag contains the LED lenses, the LED with the connector cable assembly, and the faceplate. The second bag con- tains the mounting rails, spacer bar, and a bag of screws needed for assembly and mounting.
  • Page 55 MAP/40. 18. Locate on either side of the MAP/40 the bottom fourth set of slots just behind the front of the peripheral bay. Screws provided with the bracket kit will be used through the bottom slot to secure the drive to the MAP/40 peripheral bay area.

  • Page 56: Installing The Scsi Cartridge Tape Drive

    Performing the Upgrade 19. Place the drive in the MAP/40, sliding it through the front entry area. Hold the drive unit from inside the peripheral bay area when aligning the bracket with the holes. 20. Insert two screws on each side of the disk in the first bottom mounting hole.
  • Page 57 Performing the Upgrade terminating resistors Figure 4-5. Jumper Settings for SCSI Cartridge Tape Drive 4-11...
  • Page 58 Reinstall the video card in slot #10 using the step outlined in ‘‘Installing a Circuit Card in the MAP/40’’ in Chapter 3 of this book. Go to Chapter 2 and reverse the process you used to get into the MAP/40. There are also procedures there to replace the dress panel and left cover.
  • Page 59 Card retaining bracket disk drive units Cartridge tape drive 4-10 Header connections on 486 CPU Circuit card 486 CPU general installation how to hold installation in MAP/40 Remote maintenance 3-14 Inside the MAP/40 SCSI host adapter 3-10 COM1 COM2 Cooling system...
  • Page 60 Index 486 CPU SCSI host adapter 3-13 System power-down Key components in MAP/40 Keyboard adapter, see CPU/RMB keyboard adapter Keyboard header connections Tape drive unit 4-10 Test equipment needed Tools needed MAP/40 back 1-12 card cage access panel cooling system...
