  • Page 1 Tillage Haulage Landscaping Seeding & Plantation Solutions... Crop Protection Harvest Post Harvest Sub Soiler FIELDKING USA, INC. † Operator Manual † † Part Catalogue Service Manual 960 Holmdel Road Suite 2-02, Holmdel, NJ 07733, USA usa@fieldking.com, www.fieldkingusa.com...
  • Page 2 If your manual is lost or destroyed, “FIELDKING USA” will be glad to provide you a new copy. Visit to nearest dealership & get a copy. Most of our manuals can also be downloaded from our website at www.fieldkingusa.com.

  • Page 3: Customer Information

    4. Return the equipment or parts to the authorized “FIELDKING USA” dealer, from Sometime in the future your sub soiler may need new parts to replace which are where it was purchased, for service or replacement of defective parts that are covered by warranty.
  • Page 4 INDEX INTRODUCTION TECHNICAL INFORMATION General description Warranty Warranty become void USAGE INSTRUCTIONS Overall check -up Attaching sub-soiler to the tractor Safety Instruction TRACTOR PREPARATION AND WORKING Instructions for tractor preparation Width of cut adjustment Leveling the sub-soiler Adjustments for deeper penetration Warning for driver Trouble shooting MAINTENANCE...

  • Page 5: Technical Information

    4. It is an inexpensive implement & it provides a simple and economical way to spare parts of the “FIELDKING USA” Sub-Soiler. obtain boosting crop yields and profits. FIELDKING USA sub-soiler is used to break-up compacted soil layers and FEATURES open the ground up, so that roots and moisture can penetrate more deeply into the soil.
  • Page 6 3.2. ATTACHING THE SUB-SOILER TO THE TRACTOR In order to protect yourself always wear adequate clothes and shoes during the operations. 1. Place the sub-soiler duly levelled on the flat piece of land. 2. Reverse the tractor to the sub-soiler ( Do not drag the sub-soiler) 3.

  • Page 7: Maintenance

    4.6 TROUBLING SHOOTING of un-used oil/grease for rust prevention. The “FIELDKING USA” Sub-Soiler Uses a vertical Shank to break- up Hardpan, These steps will enhance the life of your sub-soiler trench or aerate the soil. it is a simple and reliable system that requires minimal maintenance.
  • Page 8 STANP PIPE ASSEMBLY 75210001 SIDE LINK SUPPORT 75180006 SR.NO. PART NAME PART NO. QTY. HITCH PIN 20MM 10020013 SUB SOILER TYNE 75200001 SPRING WASHER 25MM 10270007 SUB SOILER SHOWEL 75200002 PLAIN NUT M25 10280041 SUB SOILER SHOE 75200003 HEX HEAD BOLT M16x80x2P 10260080 HEX.
  • Page 9 3POINT LINKAGE ASSEMBLY 75380001 TYNE ASSEMBLY 75300001 SR.NO. PART NAME PART NO. QTY. STAND ASSEMBLY 75290001 SUB SOILER TYNE 75300002 HEX HEAD BOLT M16X80X2P 10260080 SUB SOILER SHOWEL 75200002 NYLOCK NUT M16X2P 10280005 SUB SOILER SHOE 75200003 CSK BOLT (M12x40x1.75P)
  • Page 10 SUB-SOILER (3-ARM) SUB-SOILER (5-ARM) COMPLETE 5ARM SUBSOILER PART DETAILS SR.NO. PART NAME PART NO. QTY. FRAME ASSEMBLY 75370001 3 PT. LINKAGE 75380001 TYNE ASSEMBLY 75300001 FRONT SUPPORT PIPE 75370002 STAND PIPE ASSEMBLY 75290001 CSK BOLT (M12X50X1.75P) 10260050 CSK BOLT (M12X40X1.75P) 10260049 HEX HEAD BOLT (M16X60X2P) 10260017...

  • Page 11: Delivery Checklist

    SUB-SOILER (5-ARM) DELIVERY CHECKLIST Dealer Pre-Delivery (Please Tick) Please Complete all Dealer information Below 1. Dealer Pre-Delivery Checklist Dealer Information COMPLETE 5ARM SUBSOILER PART DETAILS 1. The customer or person responsible has SL NO. PART NAME PART NO QTY. Dealer’s Name................been given the operator’s manual.

  • Page 12: Warranty Card

    ADDRESS MOBILE NO. Email NAME OF IMPLEMENT MODEL NO. YEAR OF Mfg. SERIAL NO. REGISTRATION NO. DATE OF PURCHASING NAME OF DEALER Customer`s Signature Dealer`s Signature FIELDKING USA, INC. 960 Holmdel Road Suite 2-02, Holmdel, NJ 07733, USA usa@fieldking.com, www.fieldkingusa.com...
  • Page 13 ADDRESS MOBILE NO. Email NAME OF IMPLEMENT MODEL NO. YEAR OF Mfg. SERIAL NO. REGISTRATION NO. DATE OF PURCHASING NAME OF DEALER Customer`s Signature Dealer`s Signature FIELDKING USA, INC. 960 Holmdel Road Suite 2-02, Holmdel, NJ 07733, USA usa@fieldking.com, www.fieldkingusa.com...
  • Page 14 ADDRESS MOBILE NO. Email NAME OF IMPLEMENT MODEL NO. YEAR OF Mfg. SERIAL NO. REGISTRATION NO. DATE OF PURCHASING NAME OF DEALER Customer`s Signature Dealer`s Signature FIELDKING USA, INC. 960 Holmdel Road Suite 2-02, Holmdel, NJ 07733, USA usa@fieldking.com, www.fieldkingusa.com...
