  • Page 1 Tillage Haulage Landscaping Seeding & Plantation Solutions... Crop Protection No Till Multi Crop Drill Harvest Post Harvest FIELDKING USA, INC. Operator Manual Part Catalogue † † Service Manual † 960 Holmdel Road Suite 2-02, Holmdel, NJ 07733, USA exports@fieldking.com, www.fieldking.com...
  • Page 2 If your manual is lost or destroyed, “FIELDKING USA” will be glad to provide you a new copy. Visit to nearest dealership & get a copy. Most of our manuals can also be downloaded from our website at www.fieldking.com.

  • Page 3: Customer Information

    4. Return the equipment or parts to the authorized “FIELDKING USA” dealer, from Sometime in the future your No Till Multi Crop Drill may need new parts to replace where it was purchased, for service or replacement of defective parts that are covered by warranty.
  • Page 4 INDEX 1. TECHANICAL DATA 1.1. Introduction 1.2. Warranty 1.3. When the warranty becomes void 1.4. Usage and instruction 1.5. Maintenance 1.6. Re-assembly parts 2. Major Components and their Description 2.1. Frame 2.2. Disc openers 2.3. Seed boxes 2.4. Seed metering device 2.5.

  • Page 5: Technical Data

    It is important that the No Till Multi Crop Drill should be parked in covered area and 1. When the implement has been used beyond the specified power limit like (Tractor Horse away from sunlight.
  • Page 6 3.4. No Till Multi Crop Drill Raise the seed drill so that drive wheel becomes free to be turned. Put a chalk mark on the rim of the wheel. Fill the seed box, set the seed rate adjusting lever and rotate the wheel for ‘N’...
  • Page 7 This ground wheel or drive wheel is 1. Sowing of wheat with No Till Multi Crop Drill is best accomplished when soils have 3-4% more moisture than under conventional method. Germination of wheat and corn crops is attached to the frame in front.
  • Page 8 6. When weed pressure is not a factor, tilling of soil is not needed and reduced tillage (1–2 3. Seed boxes, fluted rollers, seed metering shaft and controlling bottom plate (having ploughings) and cross-sowing methods do not provide any additional advantage over triangular holes) should be thoroughly cleaned.

  • Page 9: Troubleshooting

    2. Drive wheel should be round, if it is bent then repair it. 4. Excessive bend in the tubes should be avoided otherwise the bend will cause obstruction in free flow of seed and results in non-uniform application of seed in the field. 3.
  • Page 10 No Till Multi Crop Drill Main Assembly ITEMCODE QTY. SR. NO. DESCRIPTION 9-TYNE 11-TYNE 13-TYNE 9-TYNE 11-TYNE 13-TYNE HEX. HEAD BOLT M8X1.25X25 10260090 SPRING WASHER 8MM 10270001 CHAIN COVER ASSEMBLY (DISC SEED DRILL) 78550063 CHAIN 10B (45 LINKS) 10140052 UCFL BEARING 205 COMPLETE ASSEMBLY 10050353 PLAIN HEX NUT M16X2 (5.6 GRADE ) AUTO BLACK...
  • Page 13 3-PONT LINKAGE ASSEMBLY CHAIN TIGHTENER ASSEMBLY WITH SPROCKET 16T CHAIN TIGHTNER ASSEMBLY WITH SPROCKET 16T (DISC SEED DRILL) (10170073) 3-PONT LINKAGE ASSEMBLY (DISC SEED DRILL) (78550053) SR. NO. DESCRIPTION ITEM CODE QTY. SR NO. DESCRIPTION ITEM CODE QTY. SPROCKET 16-T FOR CHAIN ADJUSTER (DISC SEED DRILL) 10170072 LEVER PLATE DISC SEED DRILL (RHS) 78550054...
  • Page 14 FRONT DISC ASSEMBLY REAR DISC ASSEMBLY FRONT DISC ASSEMBLY (DISC SEED DRILL) (78550086) REAR DISC ASSEMBLY (DISC SEED DRILL) (78550083) SR. NO. DESCRIPTION ITEM CODE QTY. SR. NO. DESCRIPTION ITEM CODE QTY. TYNE ASSEMBLY (FRONT) (DISC SEED DRILL) 78550076 TYNE ASSEMBLY (REAR) (DISC SEED DRILL) 78550077 DISC SUB ASSEMBLY (DISC SEED DRILL) 78550075...
  • Page 15 Other Information About Seed Gun Setting DISC SUB ASSEMBLY Seed Gun Settings Each seed gun is equipped with a four-position gate. The highest handle position shown is for small seeds, the second and third positions are for larger seeds. The forth position (Handle rotated fully down below the bottom tab) sets the wide open to allow complete clean-out of seed gun.

  • Page 16: Delivery Checklist

    4. All greasing and oil points, stickers, guarding and ID plate have been identified Signature..................and physically pointed out. Delivery Date................FIELDKING USA, INC. 5. The customer agrees that it is his responsibility to read and carry out the Comments..................safety, maintenance and operation as per 960 Holmdel Road Suite 2-02, Holmdel, NJ 07733, USA .......................
  • Page 17 ADDRESS MOBILE NO. Email NAME OF IMPLEMENT MODEL NO. YEAR OF Mfg. SERIAL NO. REGISTRATION NO. DATE OF PURCHASING NAME OF DEALER Customer`s Signature Dealer`s Signature FIELDKING USA, INC. 960 Holmdel Road Suite 2-02, Holmdel, NJ 07733, USA exports@fieldking.com, www.fieldking.com...
  • Page 18 ADDRESS MOBILE NO. Email NAME OF IMPLEMENT MODEL NO. YEAR OF Mfg. SERIAL NO. REGISTRATION NO. DATE OF PURCHASING NAME OF DEALER Customer`s Signature Dealer`s Signature FIELDKING USA, INC. 960 Holmdel Road Suite 2-02, Holmdel, NJ 07733, USA exports@fieldking.com, www.fieldking.com...
