  • Page 1 AC2990 Treadmill Owner's Manual CAUTION! Read all precautions and instructions in this manual before using this equipment.

  • Page 2: Table Of Contents

    ! CAUTION Read all precautions and instructions in this manual before using this equipment. Table Of Contents Important Safety Instructions-------------------------------------------------------------- 3 Before You Start------------------------------------------------------------------------------ 7 Main Parts List-------------------------------------------------------------------------------- 8 Warning---------------------------------------------------------------------------------------- 9 Using Method-------------------------------------------------------------------------------- 10 Warm Up Exercises------------------------------------------------------------------------- 11 Power Requirements---------------------------------------------------------------------- 12 Console Information----------------------------------------------------------------------- 13 Moving Instructions------------------------------------------------------------------------ 14 Parts List and Exploded View------------------------------------------------------------ 15...

  • Page 3: Important Safety Instructions

    Impor tant Safety Instructions IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: Read all instructions before using this Treadmill: DANGER - To reduce the risk of electric shock: 1. Always unplug this appliance from the electrical outlet immediately after using and before cleaning.
  • Page 4 Impor tant Safety Instructions WARNING - To reduce the risk of burns, fire, electric shock, or injury to persons: 1. An appliance should never be left unattended when plugged in. Unplug from outlet when not in use, and before putting on or taking off parts. 2.
  • Page 5 Impor tant Safety Instructions GROUNDING INSTRUCTION This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment- grounding conductor and a grounding plug.
  • Page 6 Impor tant Safety Instructions WARNING! Heart rate monitoring systems may be inaccurate. Over exercising may result in serious injury or death. If you feel faint stop exercising immediately. Please make sure that there must be a safety area of 2000 mm × 1000 mm behind the treadmill while exercising.

  • Page 7: Before You Start

    Before You Star t Remember to take the time to review owner's manuals before you start. 1. Before using this treadmill or starting any exercise program, consult your physician and accompanied by specialized person. Adjust the speed not over 8KMH. 2.

  • Page 8: Main Parts List

    Main parts list ─ 8 ─...

  • Page 9: Warning

    War ning CAUTION! Before using this treadmill or starting any exercise program, It is important to review this manual and the following precautions. Power switch Power Receptacle Precautions 1. Always unplug the treadmill after using to keep the life of treadmill and avoid any risk of injuries.

  • Page 10: Using Method

    Using Method Please read carefully and using follow the functions: 1. put the plug in the socket, turn on the switch. 2. grasp the handle firmly, stand on the treadmill. 3. Push red safety switch into the casing, tie the safety clip to your cloth, then start the treadmill for exercise.

  • Page 11: Warm Up Exercises

    War m Up Exercises EXERCISE GUIDELINES WARNING! Before beginning this or any exercise program, you should consult your physician. This is especially important for individuals over the age of 35 or individuals with pre-existing health problems. Warming up prepares the body for the exercise by increasing circulation, supplying more oxygen to the muscles and raising body temperature.

  • Page 12: Power Requirements

    Power Requirements IMPROPER CONNECTION OF THE EQUIPMENT GROUNDING CONNECTOR CAN RESULT IN A RISK OF AN ELECTRIC SHOCK. CHECK WITH A QUALIFIED ELECTRICIAN OR SERVICE MAN IF YOU ARE IN DOUBT AS TO WHETHER THE PRODUCT IS PROPERLY GROUNDED. DO NOT MODIFY THE PLUG PROVIDED WITH THE PRODUCT.

  • Page 13: Console Information

    Console Information Before beginning your workout, check your normal resting heart rate. Place your fingers lightly against your neck, or against your wrist over the main artery. After finding your pulse, count the number of beats in 10 seconds. Multiply the number of beats by six to determine your pulse rate per minute.

  • Page 14: Moving Instructions

    Moving Instructions Caution! In order to protecting your treadmill, spattering water on the machine must be forbidden. To avoid the risk of injury, never attempt to move the treadmill while it is operating. To reduce the possibility of injury while lifting, bend your legs and keep your back straight.

  • Page 15: Parts List And Exploded View

    Parts List and Exploded View Overall ItemNo. Grade No. Part No. Description AC2990-WX01ASSY Console Frame Assembly AC2990-WX02ASSY Console ASSY AC299004ASSY Left Upright Assembly AC299005ASSY Right Upright Assembly AC299004-22WXASSY Mainframe Assembly GB70M6*15DHS4 Socket Head Cap Screw M6*15 5.70 AC29901600 Motor Cover 5.61...
  • Page 16 Parts List and Exploded View Overall ─ 16 ─...
  • Page 17 Parts List and Exploded View Console Frame Assembly Grade No. Part No. Description ItemNo. AC29900100 Console Frame ECT74600 Plastic Clip Block Coun tersu nk head hexagon riveted n uts M 5 GB17880.3M5*13DS17 AC299008ASSY Emergency Switch ASSY AC29904000 Console Frame Upper Casing GB846ST2.9*13DS Phillip Screw ST2.9*13 GB845ST4.2*13DS...
  • Page 18 Parts List and Exploded View Console Frame Assembly ─ 18 ─...
  • Page 19 Parts List and Exploded View Console ASSY Grade No. Part No. Description ItemNo. AC29905000 Front Cover of Console ECT74800 Buffer Pad For Key B242 Main PCB GB845ST2.9*9.5DS Phillip Screw ST2.9*9.5 AC29900200 Bracket for Console GB845ST4.2*13DS Phillip Screw ST4.2*13 GB6560M4*8DSG Phillip Screw M4*8 GB862.24DS12 Serrated lock washers Φ4 AC29905100...
  • Page 20 Parts List and Exploded View Console ASSY ─ 20 ─...
  • Page 21 Parts List and Exploded View Mainframe Assembly Grade No. Part No. Description ItemNo. 5.1.1 AC29900600 Deck Frame 5.1.2 DC1600A9200 Ground bumper 5.1.3 AC299007ASSY Inverter Frame ASSY 5.1.4 FLPSR-5500 Teflon washer 5.1.5 R15-22M-RDS Actuator 5.1.6 GB5780M10*45DS20 Hex Head Bolt M10*45 5.1.7 DQ10DS2A Washer Washer Φ11*Φ23*2 5.1.8...
  • Page 22 Parts List and Exploded View Left Upright Assembly Right Upright Assembly ItemNo. Grade No. Part No. Description AC29900400 Left Upright GB17880.5M10*22.5DS17 Flat head hexagonal rivet nut Grade No. Part No. Description ItemNo. AC29900500 Right Upright GB17880.5M10*22.5DS17 Flat head hexagonal rivet nut ─...
  • Page 23 Parts List and Exploded View Mainframe Assembly Grade No. Part No. Description ItemNo. AC299003-22ASSY Deck Frame and Inverter Frame Assembly AC29900801 Front Bracket for fixing Motor Cover AC32705800 Clip Nut M6 GB70M6*15DHS4 Socket Head Cap Screw M6*15 ECU7P3500 Plastic Clip Block GB845ST4.2*16DS Phillip Screw ST4.2*16 GB9074ST4.2*16DHS...
  • Page 24 Parts List and Exploded View Mainframe Assembly Grade No. Part No. Description ItemNo. 5.38 EVOT31000 Bracket for fixing Switch 5.39 GB819M4*12DS2 Cross countersunk head cap head screw M4*12 5.40 GB41M4DS2 Nut M4 5.41 Power Outlet 5.42 L100AMP175022-1-L-14 Connect Wire 5.43 L100AMP175022-1-N-14 Connect Wire 5.44...
  • Page 25 Parts List and Exploded View Mainframe Assembly ─ 25 ─...
  • Page 26 Parts List and Exploded View Inverter Frame ASSY Grade No. Part No. Description ItemNo. 5.1.3.1 AC29900700 Inverter Frame 5.1.3.2 DC29002200 Wheel 5.1.3.3 GB894.125FH12 Circlip for shaft 5.1.3.4 DQ8DHS2B Washer Washer Φ9*Φ28*2 5.1.3.5 GB70M8*15DHS4 Socket Head Cap Screw M8*15 ─ 26 ─...
  • Page 27 Parts List and Exploded View Emergency Switch ASSY Grade No. Part No. Description ItemNo. 1.4.1 AC29907700 Bottom Casi ng for Emergency Switch Pull Rope 1.4.2 AC29907500 Upper Casing for Emergency Switch 1.4.3 STDP4012 Safe Key Clamp 1.4.4 AC29907600 Upper Casing for Emergency Switch Pull Rope 1.4.5 GB846ST2.2*6.5DS Phillip Screw ST2.2*6.5...
  • Page 28 Parts List and Exploded View Motor Assembly Grade No. Part No. Description ItemNo. 5.34.1 AC29701300 Bracket for fixing Motor 5.34.2 AC29706700 Insulation Rubber 5.34.3 STDP3600 Insulation Base 5.34.4 STDP6800 Locknut M8 5.34.5 GB70M8*40*40DHS2 Socket Head Cap Screw M8*40 5.34.6 DQ8DHS2A Washer Φ9*Φ22*2 5.34.7 D40-42M3-ZH...

  • Page 29: Console Panel Functions

    Console Panel Functions KEY BEHALF FUNCTION Key name Function START This button is used to start the current program. STOP This button is used to stop the current program. 1. These buttons are used to adjust the speed of the treadmill during workout.
  • Page 30 Console Panel Functions Key name Function Speed instant: 2,4,6,8,10,12 go to selected speed directly. 2,4,6,8,10,12. Incline Instant: 2,4,6,8,10,12 go to selected incline angle directly. 2,4,6,8,10,12. DISPLAY FUNCTION Window name Function Indicates elapsed time after pressing start in minutes and seconds (0- TIME 99minutes,0-59seconds).
  • Page 31 Console Panel Functions 2. Program mode When console turns on, the LED screen scrolls "PRESS START OR SELECT PROGRAM". If press PROG. Button, will cycle through to the desired preset program1 (P1), preset program2 (P2), preset program3 (P3), preset program4 (P4), preset program5 (P5), user program1 (U1), user program2 (U2), TIME countdown mode, CALORIES countdown mode, DISTANCE countdown mode, HR1, HR2,HR3.
  • Page 32 Console Panel Functions 2.3 COUNTDOWN MODE 2.3.1 TIME COUNTDOWN MODE Press PROG. Button cycle through time countdown mode. (1) Indicates ENTER TIME in dot matrix, Time window will be flash 30:00, Use speed + or – button to adjust value. (2) Press ENTER button, Indicates PRESS START in dot matrix.
  • Page 33 Console Panel Functions 2.4.2 HR2- HR3 Press PROG. Button cycle through HR2 and HR3 mode, The same HR1. HR1: Target Heart Rate at 65% MAX HR HR2: Target Heart Rate at 75% MAX HR HR3: Target Heart Rate at 85% MAX HR 3.
  • Page 34 Console Panel Functions 5. Treadmill Error Messages Malfunction Corrective Action 1. Check console and the main communication cable connection. ER01, 2. Check inverter and the main communication cable connection. Communication Error 3. Replace inverter. 4. Replace console. 1. Elevation auto. Sense mode. ER02, 2.

  • Page 35: Electrical Connection

    Electrical Connection ─ 35 ─...

  • Page 36: Belt Adjustment And Maintenance

    Belt Adjustment and Maintenance 1. Running Belt Adjustment Caution Over-tightening of the roller will severely shorten the life of the running belt and may cause further damage to other components (such as Roller, Motor etc.). Speed of Running Belt don't exceed 4KMH, during adjustment. 1.1 Adjust Running Belt in center of treadmill Running belt is possible off normal while using for period of time or just use a new treadmill, solution of two situations are as following:...
  • Page 37 Belt Adjustment and Maintenance 2. Cleaning Warning! To prevent electrical shock, be sure the power is turn off and disconnect plug from socket before attempting any cleaning or mainteance. Routine maintenance and cleaning for your unit will keep good function and extend the life of your unit.

  • Page 38: Maintenance Check List

    MAINTENANCE CHECK LIST ─ 38 ─...
