- Page 7 Max. 17°...
-
Page 10: Technical Specifications
TECHNICAL SPECIFICATIONS MODEL: hydrostatic ride on mower. ENGINE: B&S INTEK, 344 cm 13HP @3300 rpm max. 4-stroke OHV petrol, with oil pump, oil filter cast iron cylinder FUEL TANK VOLUME: 7 litres – RESERVE: 1,5 litres HOURLY CONSUMPTION: about 3 litres/h. STARTER: electric, with battery 12 V TRANSMISSION: hydrostatic CLUTCH: for PTO with electromagnetic clutch... - Page 11 STARTING UP THE ENGINE - Sit down on the operator seat. - Put the forward lever into the STOP position (2, fig. 3) - Switch off the PTO switch (4, fig. 1 in the OFF position). - Push the throttle half way in (5, fig. 3). - If the engine is cold, use the choke (6, fig.
-
Page 13: Troubleshooting Guide
CHECKING THE BLADES AND CUTTING DECK A blunt blade tears the grass, therefore the cutting edges of both blades must be sharpened. To remove a blade, take hold of it firmly, wearing work gloves, and unscrew the central screw (3 fig. 9), remembering that the screw has a right –... - Page 16 TECHNICAL DRAWINGS VALID AS FROM FRAME NO. 565895...
