ERECTION INSTRUCTIONS
FOR OREGON DELUXE
BEFORE USE
PLEASE TAKE TIME TO READ AND UNDERSTAND THE ERECTION INSTRUCTIONS.
FAILURE TO ERECT THE TENT IN ACCORDANCE WITH THE INSTRUCTIONS MAY
RESULT IN DAMAGE TO BOTH FABRIC AND POLE SYSTEMS. SUCH DAMAGE
CANNOT BE COVERED BY THE WARRANTY.
WARNING!!
DO NOT PUSH TENT PEGS IN BY HAND, ALL TENT PEGS SHOULD BE DRIVEN HOME
USING A WOODEN OR RUBBER FACED MALLET OR SIMILAR TOOL.
TO ENSURE MAXIMUM POSSIBLE WATERPROOFING THE MAIN FLY SHEET SEAMS
HAVE BEEN TAPED. SHOULD THE TAPE BE DAMAGED AND PEEL AWAY YOU CAN
EFFECT A REPAIR BY USING SEAM SEALER AROUND THE PROBLEM AREA.
WE ALSO RECOMMEND THAT SEEM SEALER IS APPLIED TO UNTAPED SEEMS TO
PREVENT LEAKAGE.
IT IS IMPORTANT THAT YOU DO NOT ALLOW SEAM SEALER TO CONTAMINATE THE
TEETH OF ANY ZIPS AS THIS WILL PREVENT THE ZIP FROM FUNCTIONING CORRECTLY.
IF YOU DO USE SEAM SEALER IT IS BEST APPLIED WHEN THE TENT IS DRY. PICK A DRY
WARM DAY TO CARRY OUT ANY SEALING AND PLEASE ALLOW 48 HOURS FOR THE
SEALANT TO CURE PRIOR TO RE-PACKAGING THE TENT.
FAILURE TO ALLOW THE SEALANT TO DRY FULLY PRIOR TO PACKING THE TENT UP
WILL STICK THE FABRIC TOGETHER POSSIBLY CAUSING IRREPARABLE DAMAGE.
DURING USE
TENTS CONTAINING A HIGH PROPORTION OF SYNTHETIC MATERIALS ARE SOMETIMES
AFFECTED BY CONDENSATION, THIS SHOULD NOT BE CONFUSED WITH LEAKAGE AND
CAN USUALLY BE CURED BY ENSURING THAT ADEQUATE VENTILATION IS
AVAILABLE BY LEAVING DOORWAYS SLIGHTLY UNZIPPED WHEREVER POSSIBLE.
DO NOT PITCH UNDER TREES, MAKE USE OF NATURAL WIND BREAKS LIKE HEDGES
OR WALLS, FACE THE TENT DOOR AWAY FROM THE PREVAILING WIND. USE TWO
HANDS WHEN OPENING AND CLOSING ZIPS, THIS WILL HELP PREVENT PREMATURE
ZIP FAILURE.
READ AND UNDERSTAND THE FIRE PRECAUTIONS INFORMATION ATTACHED TO THE
INSIDE OF THE TENT.
CARE OF YOUR TENT WARNING!!
TENT FABRICS CAN BE WEAKENED BY PROLONGED EXPOSURE TO SUNLIGHT, UNDER
NORMAL HOLIDAY USE YOUR TENT WILL GIVE YOU LONG SERVICE BUT ERECTION
FOR EXTENDED PERIODS IN STRONG SUNLIGHT WILL CAUSE DETERIORATION.
IF YOU ARE LIKELY TO USE YOUR TENT FOR PROLONGED PERIODS IT WOULD BE WISE
TO USE A SITE WHICH IS AS SHADED AS POSSIBLE.
TENTS ARE BEST STORED OPENED OUT, IF THIS IS NOT POSSIBLE AIR FULLY AND
ENSURE IT IS TOTALLY DRY BEFORE PACKING IT AWAY AT THE END OF YOUR
HOLIDAY.
STORE YOUR TENT IN A WELL VENTILATED DRY PLACE. LOOK AFTER YOUR TENT
AND IT WILL LOOK AFTER YOU.
HAVE ANY DAMAGE TO YOUR TENT REPAIRED AT FIRST OPPORTUNITY.
1
Advertisement
Table of Contents
Related Manuals for Khyam Oregon Deluxe
Summary of Contents for Khyam Oregon Deluxe
- Page 1 ERECTION INSTRUCTIONS FOR OREGON DELUXE BEFORE USE PLEASE TAKE TIME TO READ AND UNDERSTAND THE ERECTION INSTRUCTIONS. FAILURE TO ERECT THE TENT IN ACCORDANCE WITH THE INSTRUCTIONS MAY RESULT IN DAMAGE TO BOTH FABRIC AND POLE SYSTEMS. SUCH DAMAGE CANNOT BE COVERED BY THE WARRANTY.
- Page 2 FAILURES IN FIBERGLASS POLES NORMALLY OCCUR THROUGH INCORRECT USE, MAKE SURE THE POLE SECTIONS ARE FULLY INSERTED INTO THEIR ADJOINING FERULES AND DO NOT OVER STRESS THE POLE BEYOND IT’S DESIGNED CURVE. ZIPS SHOULD BE TREATED WITH CARE TO PREVENT PREMATURE FAILURE AND THE TENT SHOULD BE KEPT CLEAN AND DRY AFTER USE.
- Page 3 STARTING AT ONE END OF THE TENT THREAD THIS POLE THROUGH THE SLEEVE SECTION RUNNING ACROSS THE ROOF OF YOUR TENT. THE METAL ANGLE BRACKETS SHOULD BE CLEAR OF THE SLEEVES AT BOTH ENDS. REPEAT THIS FOR THE REMAINING 3 FIBERGLASS ROOF POLES. ENSURE CARE IS TAKEN DURING THIS PROCEDURE, NOT TO ALLOW THE ENDS OF THE SHOCKCORDED POLES TO DAMAGE SLEEVES OR FLYSHEET MATERIAL.
- Page 4 7. THE INTERNAL ROOF RIDGE POLE SHOULD BE LOCATED INTO POSITION. THIS IS LOCATED FROM THE INSIDE OF THE TENT BETWEEN THE TWO MAIN POLES BETWEEN THE BEDROOM AREAS. LOCATE THE POLE INTO THE TWO POCKETS AND ADJUST TO FIT – THERE IS NO NEED TO OVER TENSION THE POLE – IT IS DESIGNED TO ASSIST WATER RUNNING OFF THE ROOF AREA.
- Page 5 THE ELASTIC LOOPS AND TOGGLES SHOULD SIMPLY BE FED THROUGH THE CORRESPONDING LOOPS AND RINGS ON THE FLYSHEET. OPEN THE DOOR OF THE INNER TENT KNEEL OR CAREFULLY STAND ON THE GROUNDSHEET. STARTING AT THE BACK CONNECT ALL THE LOOPS AND RINGS ON THE REAR POLE SECTION WORK FORWARD UNTIL THE INNER IS COMPLETELY SUSPENDED.
- Page 6 4: FOLD THE EDGES OF THE GROUNDSHEET IN SO TO COVER THE FLYSHEET IN THE MIDDLE, MAKE SURE THAT THE OVERALL PACKAGE IS AGAIN ABOUT 10 CMS SHORTER IN WIDTH THAN THE OUTER BAG. 5: ROLL THE PACKAGE UP, ROLLING TOWARDS THE DOOR END OF THE INNER TENT IN ORDER TO ALLOW TRAPPED AIR TO ESCAPE.
