- Page 1 Installation, Mounting and Maintenance DISA-H Ferdinand Schad KG Steigstraße 25-27 D-78600 Kolbingen Telefon +49 (0) 74 63 - 980 - 0 Telefax +49 (0) 74 63 - 980 - 200 info@schako.de www.schako.de...
-
Page 2: Table Of Contents
Installation, Mounting and Maintenance DISA-H Contents Safety instructions ..........................3 General information ................................... 3 Warranty ............................3 Recycling ............................3 General information ..........................4 Identification of the delivered model ............................4 Function ..................................... 4 Installation and commissioning ........................ 5 Operating conditions .................................. 5 Material reception .................................. -
Page 3: Safety Instructions
- Do not change any control or safety elements without pri- or approval by the manufacturer or the local sales office. SCHAKO shall not give any warranty for damage resulting from: - Improper use caused by ignoring the instructions given in this manual - Non-observance of the operating conditions of the device. -
Page 4: General Information
Installation, Mounting and Maintenance DISA-H General information Function The primary air (1) supplied from the plenum box induces sec- Identification of the delivered model ondary air in the room (2), which is cooled or heated via the reg- The induction diffuser type DISA-H is available in three different ister (4). -
Page 5: Installation And Commissioning
The weight must not Identification sticker: rest on the condensate pan or the water connec- tions. SCHAKO cannot be held liable for damage to the unit caused by improper handling or handling not mentioned here, loading or unloading. Storage... -
Page 6: Installation
Hydraulic connections DISA-H-HT (4-pipe) Mounting The DISA-H series has been developed for horizontal installation in suspended entry halls or ceiling panellings. The device is sus- pended from a load-bearing ceiling using fastening material ap- proved by the building supervisory authorities, for example M6 threaded bars. -
Page 7: Connecting The Air Ducts
Installation, Mounting and Maintenance DISA-H The connection of the hydraulic connections can be done by sol- Mounting accessories dering, pressing (in connection with supporting sleeves) or by means of flexible hoses resistant to oxygen diffusion and push- Valves and actuators fit systems. -
Page 8: Checks
Installation, Mounting and Maintenance DISA-H Checks To ensure this, the following maintenance activities must be car- ried out: Prior to commissioning, the following items must be checked or guaranteed: - If the register is soiled, clean it by spraying it with water or compressed air or by evacuation. -
Page 9: Checking The Primary Volumetric Flow
Installation, Mounting and Maintenance DISA-H When decommissioning the unit or shutting it down for a longer period in winter, the water must be drained from the unit, in order to avoid damage to the register due to the formation of ice. If you want to use antifreezes, you must first determine the freezing point. -
Page 10: Troubleshooting
Installation, Mounting and Maintenance DISA-H Troubleshooting Problem Possible cause Solution Primary air volume not present or too low Check primary air volume Air inlet and outlet of the inner unit clogged Remove foreign material and clean the unit Ventilation of the hydraulic system Air in the hydraulic system The unit does not cool or heat suffi- Please inform the installer... - Page 11 EC Declaration of Conformity [FOR MARKING] FERDINAND SCHAD KG WITH THE COMPANY HEAD OFFICE IN Steigstraße 25-27 D-78600 Kolbingen (GERMANY) HEREBY DECLARES THAT THE DESIGN AND CONSTRUCTION OF THE air treatment units DISA-H COMPLY WITH THE FOLLOWING REGULATIONS: Machinery Directive 2006/42 EC Directive on General Product Safety: 2001/95/EC APPLICABLE HARMONISED REGULATIONS DIN-EN-ISO 12100 SAFETY OF MACHINERY - Safety of Machinery - Basic terms, general...
