- Page 1 Installation, Mounting and Maintenance DISA-360 Ferdinand Schad KG Steigstraße 25-27 D-78600 Kolbingen Telephone +49 (0) 74 63 - 980 - 0 Fax +49 (0) 74 63 - 980 - 200 info@schako.de www.schako.de...
-
Page 2: Table Of Contents
Installation, Mounting and Maintenance DISA-360 Contents Safety instructions ..........................3 General information ................................... 3 Warranty ............................3 Recycling ............................3 General information ..........................4 Identification of the delivered model ............................4 Function ..................................... 4 Installation and commissioning ........................ 5 Operating conditions .................................. 5 Material reception .................................. -
Page 3: Safety Instructions
- Do not change any control or safety elements without prior approval by the manufacturer or the local sales office. SCHAKO shall not give any warranty for damage resulting from: - Improper use caused by ignoring the instructions given in this manual - Non-observance of the operating conditions of the device. -
Page 4: General Information
Identification of the delivered model ondary air in the room (2), which is cooled or heated via the reg- The ceiling induction diffuser type DISA-360 is available in four ister (4). different nozzle configurations: B, C, D and E. The entire series... -
Page 5: Installation And Commissioning
The weight must not Model / Modelo / Modell rest on the water connections. DISA-360-H-OL-SR-B-592-592-WS1-H-AS1-123 SCHAKO cannot be held liable for damage to the Order nr. / Nº Pedido / Auftragsnr: 2198/09 unit caused by improper handling or handling not... -
Page 6: Installation
Installation, Mounting and Maintenance DISA-360 Installation The ceiling induction diffuser type DISA-360 is particularly suit- able for horizontal installation in low false ceiling heights. The devices must not be installed in places with extreme moisture (e.g. laundries or swimming pools), aggressive media, with high dust formation, outdoors or in places subject to explosion hazards. -
Page 7: Connecting The Air Ducts
In order to achieve a uniform cooling capacity, the - Do not mount the temperature control close to or above a ceiling induction diffusers type DISA-360 should be heat source (direct sunlight, lamps, television sets, radia- connected to the cold water distribution system in tors, etc.), in places with draught air or directly opposite... -
Page 8: Checks
Folding down of the secondary air grille The entire DISA-360 is equipped with a series of safety locks, which allow the grille to be folded down via a rotating mecha- nism on one of the profiles for safe execution of maintenance. -
Page 9: Air Ducts And Plenum Box
While the register is hanging on the housing, it - Please do not use any scouring agents for cleaning since must not be subjected to any vigorous movements these materials may impair or damage the DISA-360 (gal- or additional stresses. vanised steel, aluminium and copper) and the surface coatings (paints and anodised surfaces). -
Page 10: Checking The Primary Volumetric Flow
Installation, Mounting and Maintenance DISA-360 Checking the primary volumetric flow The supplied primary volumetric flow can be simply checked by checking the static pressure with a Pa meter and the measuring tube available from us as accessory. To this end, one end of the measuring tube fitted with a rubber... -
Page 11: Troubleshooting
Installation, Mounting and Maintenance DISA-360 Troubleshooting Problem Possible cause Solution Primary air volume not present or too low Check primary air volume Air inlet and outlet of the inner unit clogged Remove foreign material and clean the unit Ventilation of the hydraulic system...
