Polytree TV70M3X05D01 Assembly Instructions

TREE ASSEMBLY INSTRUCTIONS

Congratulations on purchasing your new tree from
on how to quickly and easily set up your new tree.
1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.
2. Assemble the tree stand and place on a level surface. (See Fig. A)
Fig. A - Tree Stand Assembly
Fig. B - Tree and Light Assembly
Section 2
Section 1
3. Each tree section is numbered with a tag. Please identify all sections before assembling.
4. Assemble the tree from the bottom to the top. Start with the bottom section and remove protective
cap before inserting into the assembled stand. Make sure the pole is firmly inserted and secured into
the stand.
5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.
6. Allow branches to fall into place or gently pull up and out.When adjusting branches, be sure that all
wires are free of branch hinges.
7. (For pre-lit trees only) Connect the light strings as per the color labels indicated in Fig. B and insert
green label plug into the wall outlet. Your entire tree should now be lit. If some bulbs do not light or
flickers, search for any loose plugs and/or broken, loose or missing bulbs. Replace bulbs promptly in
order to maintain the performance and life expectancy of your pre-lit tree.
8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from
the pole and fan out one to the right, one to the left and one at the center of the main stem. (See Fig. C)
Fig. C
Top view
MODEL #: TV70M3X05D01
Polytree®!
Click
Section 3
Control box
Side view
Carefully follow the instructions below
Pull apart the legs of the stand so that they
are snapped into an x-shape, place the tree
stand on a level surface.
To close the stand, press the metal button
and fold the legs together.
*Electrical Rating For The Tree
(For Indoor Use Only)
Input:120VAC, 60Hz, 0.16A
Output: 29V DC 0.28A
Insert Red Label
Plugs Into Red
Labeled Extension Cord
Insert Green
Label Extension
Cord into Adaptor
To Be Plugged
Adaptor
Into Wall
Outlet
