These names are editable, allowing you a convenient way to identify the output of specific units to
downstream NDI-enabled devices and systems.
Hint: The default name includes the unit serial number, which is also provided on a sticker on the chassis to
help you identify a specific device.
FIGURE 13
Just below, you will see the Audio Source menu (Figure 13). It offers two options, labeled Line In and HDMI.
These determine whether device supplies TriCaster with the embedded audio source (digital audio included
with an HDMI video source) or analog audio supplied to its 1/8" line level stereo input connector. The nearby
volume control governs the audio output level. The device's nominal audio level is +4dBu.
FIGURE 14
The control group below Audio settings lists Hardware, Firmware, and NDI Version details, which can be
helpful if you need support or wish to confirm you have the latest firmware update installed.
Hint: The firmware update process is detailed in Section 1, Quickstart.
FIGURE 15
Completing our discussion of the Basic Settings control group, we find Reset, Reboot and Restore buttons at
the bottom of this pane.
•
Reconnect – breaks and re-establishes the connection between the source and TriCaster.
•
Reboot – restarts the device (a 'warm' reboot)
•
Reset Factory Settings – has the same effect as pressing the recessed Reset pin near the RJ-45 NDI
connector on the back of the device for a few seconds. This resets all settings to their as-shipped
default states. (On selection, the tally LEDs on the front of the unit progressively cycle to off, then on
again a short while later after defaults have been restored and the unit has rebooted.)

AUDIO

2.4.3

VERSION AND UPDATE

2.4.4

UTILITIES

2.4.5
