TOYOTA
Preparation

Table of Contents

I. Preparation................................................................................................................1-2
1. Table Of Contents ..................................................................................................2
II. Procedure ...............................................................................................................3-23
1. Vehicle Preparation ..............................................................................................3
2. Radio Removal ................................................................. ................................3-4
3. Quick-Sync Wiring Harness Installation.............................................................4-7
4. Subwoofer Umbilical Installation.........................................................................7-9
5. Rear Speaker Bypass Cable Installation.........................................................10-12
6. Power wire Installation.....................................................................................12-14
7. Installation of the Fuse Holder..............................................................................15
8. Amplifier Installation..........................................................................................15-17
9. Dash Speaker installation ................................................................................17-18
10. Front Door Speaker Installation ........................................................................19-21
11. Subwoofer Installation.......................................................................................21-23
12. Fuse Installation....................................................................................................23
13. Set Clock to correct time.......................................................................................23
14. Verify Radio Settings............................................................................................
15. Checklist / Troubleshooting...................................................................................
Accessory Installation Practice (read before installation)
Care must be taken when installing this accessory to ensure damage does not occur to the vehicle. The
installation of this accessory should follow approved guidelines to ensure a quality installation.
These guidelines can be found in the "Accessory Installation Practices" document.
This document covers such items as:
Vehicle Protection (use of covers and blankets, cleaning chemicals, etc.)
Safety (eye protection, checking torque procedure, etc.)
Vehicle Disassembly/Reassembly (panel removal, part storage, etc.)
Electrical Component Disassembly/Reassembly (battery disconnection, connector removal, etc.)
Please see your Toyota/Scion/Lexus dealer for a copy of this document.
Revisions and other installation assets
OEM Audio Plus is committed to providing components and instructions designed for seamless integration.
Please visit oemaudioplus.com for the most up to date installation related documents and media,
Important Warranty Information Failure to completely and properly fill out online Warranty
Registration may result in possible reduction or complete denial of future warranty claims. Complete
yours today at: oemaudioplus.com/registration or call: 855 OEM-ODIO for more details and alternative
methods of system registration.
Issue A 8/14/14
Reference 400CF
Page | 1

Advertisement

Table of Contents
loading

Summary of Contents for OEM Audio Reference 400CF

  • Page 1: Table Of Contents

    Please see your Toyota/Scion/Lexus dealer for a copy of this document. Revisions and other installation assets OEM Audio Plus is committed to providing components and instructions designed for seamless integration. Please visit oemaudioplus.com for the most up to date installation related documents and media, Important Warranty Information Failure to completely and properly fill out online Warranty Registration may result in possible reduction or complete denial of future warranty claims.
  • Page 2: Procedure

    Reference 400CF TOYOTA Procedure 1. Vehicle Preparation Fig. 2-1 a. Apply parking brake. b. Open the trunk and hood of the vehicle. c. Disconnect the negative (-) battery cable. Prepare a protective surface to place all vehicle components on. 2. Radio removal #2 Phillips a.
  • Page 3: Quick-Sync Wiring Harness Installation

    (Fig. 3-1) b. You will want to run these wires full length to the point where the OEM Audio + 10-pin and 6-pin Fig. 3-2 male and female connectors rest in the radio cavity.
  • Page 4 (Fig 3-3) Fig. 3-4 d. In the radio cavity connect the factory 10-pin male connector to the OEM Audio Plus Quick sync wiring harness female 10-pin connector. (Fig 3-4) e. Using a pick tool or a precision flat head Fig.
  • Page 5 (Fig. 3-8) g. Plug the rear bypass umbilical cable into your Fig. 3-9 OEM Audio Plus Quick-Sync Wiring Harness 6- pin connector. Run the other side of the rear speaker bypass cable through the radio cavity to the driver-side kick panel area.
  • Page 6: Subwoofer Umbilical Installation

    Run the cable over the air filter avoiding any binding along the way. Wire tie as necessary. (Fig. 3-12) k. Plug your OEM Audio Plus quick-sync wiring harness connectors into the back of your radio. Fig. 3-13 Plug in the remainder of your radio connectors and reinstalled radio, bezel and trim.
  • Page 7 Reference 400CF TOYOTA Procedure b. Remove the passenger side kick panel by Fig. 4-2 unscrewing the black locking tab. Pull kick panel away from position to remove. (Fig. 4-2) Run the umbilical cable alongside the factory Fig. 4-3 wiring. Remove white plastic wire clips using the pick tool by pushing away and lifting.
  • Page 8 Reference 400CF TOYOTA Procedure g. Remove the weather-stripping on the rear Fig. 4-6 passenger side door to access the side panel. (Fig 4-6) h. Apply pressure to the panel pushing towards the Fig. 4-7 driver side to disengage the locking clips. The bottom-locking clip of the panel may require a panel tool to disengage.
  • Page 9: Rear Speaker Bypass Cable Installation

    Reference 400CF TOYOTA Procedure 5. Rear Speaker Bypass Cable Installation Fig. 5-1 a. Remove the dead pedal in the driver-side kick panel area. Using the panel tool, wedge this piece out of place and pull directly toward you. (Fig. 5-1) Panel Tool Fig.
  • Page 10 Reference 400CF TOYOTA Procedure e. With the factory speaker module in hand Fig. 5-5 disengage the locking tab on the bottom of the module. Using a precision screwdriver or pick tool, gently lift to unlock. Caution: Locking tab only needs to be lifted slightly to unlock the terminals of the factory speaker module.
  • Page 11: Power Wire Installation

    Reference 400CF TOYOTA Procedure Install the harness ground together with the Fig. 5-9 factory ground and then re-install the 10mm bolt and tighten. (Fig. 5-9) 10mm Socket Reinstall the factory speaker module using a Fig. 5-10 10mm socket wrench. (Fig. 5-10) 10mm Socket 6.
  • Page 12 Reference 400CF TOYOTA Procedure Fig. 6-3 c. Under the dash area on driver-side, lubricate power wire with silicone spray or comparable substitute. Run through the grommet. The wire will only go so far due to the positioning of the factory wiring under the hood.
  • Page 13 Reference 400CF TOYOTA Procedure e. Run power wires to the battery by following Fig. 6-7 the direction of the factory wiring harness towards the battery. Secure using cable ties as necessary. (Fig. 6-7) Fig. 6-8 Use a wire stripper to strip 3/8" off the end of each power wire.
  • Page 14: Installation Of The Fuse Holder

    Reference 400CF TOYOTA Procedure 7. Installation of the Fuse Holder Fig. 7-1 a. Remove the 10mm bolt from the battery’s positive terminal. (Fig. 7-1) 10mm Wrench b. Install the ring terminal of the fuse holder Fig. 7-2 lead then re-install the 10mm bolt and tighten.
  • Page 15 Reference 400CF TOYOTA Procedure c. Remove the outward-facing 10mm bolt used Fig. 8-3 to mount the driver-side lower front dash panel. (Fig. 8-3) 10mm Wrench Fig. 8-4 d. Install the "B" labeled bracket together with the 10mm bolt. Positioning the bracket in the mounting location for the amplifier to mount adjacent to the kick panel.
  • Page 16: Dash Speaker Installation

    Reference 400CF TOYOTA Procedure g. Plug the Black 10-pin connector from the Fig. 8-7 Quick-Sync Harness into its designated receptacle on the Sub Amplifier. (Fig. 8-7) * See Series 2 Connectivity Addendum h. Carefully insert Amplifier Assembly through the bottom opening underneath the diver- Fig.
  • Page 17 OEM Audio Plus 1" Tweeter in position and Re-install dash speaker connector. (Fig. 9-3) Fig. 9-4 d. Mount the OEM Audio Plus dash speaker by using the two 10mm bolts. (Fig. 9-4) 10mm Socket Fig. 9-5 e. Reinstall dash speaker grill and repeat process for other side.
  • Page 18: Front Door Speaker Installation

    Reference 400CF TOYOTA Procedure 10. Front Door Speaker Installation Fig. 10-1 a. Use a pick tool to remove the cover behind the interior door latch. (Fig. 10-1) b. Remove #2 Phillips screw behind the door latch. Pick Tool Fig. 10-2 Fig.
  • Page 19 Reference 400CF TOYOTA Procedure Disengage door locking tab. (Fig. 10-5) Fig. 10-5 Panel Tool Fig. 10-6 g. Use panel tool to disengage the clips behind the door panel one at a time. Start at the bottom, then the sides and finish at the top.
  • Page 20: Subwoofer Installation

    6x9 speaker in place and remove speaker. (Fig. 10-9) 10mm Socket_ Mount the 6x9 OEM Audio Plus speaker by using the four 10mm bolts and re-install 6x9 Fig. 10-10 speaker connector. (Fig. 10-10) m. Reassemble door in reverse order - Taking time to ensure all clips are engaged.
  • Page 21 Reference 400CF TOYOTA Procedure c. Install the bottom subwoofer bracket to the Fig. 11-3 OEM Audio Plus Sub Enclosure using two M6 Screws provided. (Fig. 11-3) 4mm Hex Fig. 11-4 d. With the bottom subwoofer bracket installed. Connect the Subwoofer umbilical cable to the OEM Audio Plus Sub Enclosure.
  • Page 22: Fuse Installation

    (thinner wire) and the 30A fuse for the 12-gage power wire. (Fig. 12-1) Fig. 12-2 b. Connect Battery Ground (-). (Fig. 12-2) 10mm Wrench This concludes the OEM Audio Plus Reference 400CF Installation for the FJ Cruiser Issue A 8/14/14 Page | 22...
  • Page 23 6. Check the wiring – Look out for pinched or damaged wires that may have occurred during installation. 7. If all else fails - Bypass the OEM Audio Plus sound system by restoring the factory connections to the radio and contact the OEM Audio Plus technical support line at 1-855-OEM-ODIO ext.
