  • Page 2: Manual Update

    New and Updated Parts Added We have added a series of parts to the Model W1812. For increased machine safety, we added a chain guard shown as item 86 in Figure 1. For increased leadscrew stability, we added the col- lar shown as item 95V2.

  • Page 4: Table Of Contents

    Woodstock Technical Support ... 2 Controls and Features ... 3 Machine Specifications ... 4 Standard Machinery Safety ... 6 Additional Safety for Planer/Moulders ... 8 220V Operation ... 9 Extension Cords ... 9 Electrical Specifications ... 9 Unpacking ... 10 Inventory ...
  • Page 5 Woodstock International, Inc. is committed to customer satisfaction. Our intent with this manual is to include the basic information for safety, setup, operation, maintenance, and service of this product.
  • Page 6 . Headstock Scale . Control Panel . Feed Speed Control Dial . Emergency Stop Button Cutterhead ON Button 1. W1812 Front and rear view. Headstock Lock Lever . Chip Deflector Lock Pin . Cabinet Door . Belt Cover . Dust Cover w/Port .
  • Page 7 Phone #: (360) 734-3482 • Online Tech Support: tech-support@shopfox.biz • Web: www.shopfox.biz Weight ... 306 lbs. Length ... 36 Width ... 22" Height ... 34 Foot Print (Length x Width) ... 21" x 19" Total Shipping Weight ... 324 lbs. Box 1 Length x Width x Height ...
  • Page 8 Maximum Planing Width ... 7" Maximum Planing Depth ... Maximum Planing Height ... 7 Maximum Profile Width ... 6 Maximum Profile Depth ... Minimum Stock Thickness ... Minimum Stock Length ... 9" Number of Knives ... 2 Knife Type ... HSS Knife Length ...
  • Page 11 INSTRUCTION MANUAL. This machine presents significant safety hazards to untrained users. Read/ understand this entire manual before starting the planer/moulder. REACHING INSIDE PLANER/MOULDER. Never reach inside planer/moulder or remove covers when the planer/moulder is connected to power. INFEED CLEARANCE SAFETY. The infeed roller is designed to pull material into the cutterhead. Always keep hands, clothing, and long hair away from the infeed roller during operation to pre- vent serious injury.

  • Page 12: Extension Cords

    The Model W1812 is wired for 220V single-phase operation. The power supply circuit used for this machine MUST be grounded and rated for the amperage given below. Never replace a circuit breaker with one of higher amperage without consulting a qualified electrician to ensure compliance with wiring codes.

  • Page 13: Inventory

    Shop Fox dealer immediately. The following is a description of the main components shipped with the Model W1812. Lay the components out to inventory them. A. Dust Port ...1 B. Planer/Moulder Head ...1 C.
  • Page 14 This machine distributes a heavy load in a small footprint. Some residential floors may require additional bracing to support both machine and operator. Consider existing and anticipated needs, size of material to be processed through the machine, and space for auxiliary stands, work tables or other machinery when establishing a location for your planer/moulder.
  • Page 15 The Model W1812 can be moved for short distances if two people lift the ends of the cast iron extension wings and walk the machine to the new location. For ease of mobility, the machine can be placed on a Shop Fox Model D2057 Heavy Duty Mobile Base.
  • Page 16 With the help of an assistant, lay the stand on its side, then insert the ⁄ " x 16 x 1 through the rubber feet, then thread on a hex nut onto each bolt. . Next, thread each bolt into the reinforced holes shown in 7, and then thread the four remaining...
  • Page 17 Place the belt onto the cutterhead pulley with the belt direction arrow pointing the direction of pulley rotation. When installed correctly, the internal belt tangs must be facing against the pulley rotation arrow shown in . Next, while keeping your fingers clear, lift the motor and roll the belt onto the motor pulley as shown in Attach the belt guard to the stand ( ⁄...
  • Page 18 . Feed the switch pedestal wiring harnesses into the cabinet through the hole in the cabinet and secure the switch pedestal to the cabinet ( three ⁄ "-18 x ⁄ " hex bolts and . Plug the harnesses into their respective sockets just below the pedestal mounting.
  • Page 19 . Install the dust hood ( ⁄ " flange screws. . Install a 4" flexible dust collector suction hose to the dust port, as shown in Do not confuse this CFM recommendation with the rating of the dust collector. To determine the CFM at the dust port, you must take into account many variables, including the CFM rating of the dust collector, the length of hose between the dust collector and the machine, the...
  • Page 20 If, during the test run, you encounter an unusual noise or vibration, stop using the machine immediately, then review still cannot remedy a problem, contact our Tech Support at (360) 734-3482 for assistance. . Make sure you understand the safety instructions at the beginning of the manual, and verify that the machine is setup properly.
  • Page 21 This machine will perform many types of operations Headstock that are beyond the scope of this manual. Many of these Lock Lever operations can be dangerous or deadly if performed incorrectly. Speed Headstock Cutting Control Height Depth The instructions in this section are written with the Dial Handwheel Scales...
  • Page 22 DISCONNECT THE PLANER/MOULDER FROM POWER! . Pull the pin shown in deflector. Put on heavy leather gloves, and use a 14mm wrench to remove the knife bolts, washers, and any knives (if installed). . Remove any dust, wood chips, or pitch from the cutterhead where the planing knife will seat.
  • Page 23 REMEMBER, moulding knives have many different pro- files, before starting the machine, always verify that the moulding knives do not contact any part of the workpiece guide rails, feed roller swing arm, or the table surface. DISCONNECT THE PLANER/MOULDER FROM POWER! .
  • Page 24 After switching between planing and molding operations, you must re-adjust the feed roller height and spring ten- sion. Feed roller height and spring tension keeps the workpiece feeding into the planer/moulder without chat- ter or slipping. Rollers that are too high, or spring tension that is too light, can cause the workpiece to chatter and slip.
  • Page 25 —If a certain moulding knife profile does not allow you to adjust the outfeed roller down far enough for proper roller traction, the eccentric stop must be repositioned to the lower hole. To do this, remove the jam nut (Figure 28), reposition the eccentric stop (Figure 29) in the lower hole, and finger tighten the jam nut.
  • Page 26 Before using this planer/moulder, inspect each and every workpiece for the following problems, and be familiar with the hardness of the wood workpiece. Each workpiece must have at least one flat surface to slide along the planer/moulder table. To create a flat surface, pass the workpiece over a jointer ( 31).
  • Page 27 There are some common planing mistakes that must be avoided when planing. CORRECT Only plane one board at a time (Figure 33). Whether you use guide rails or not, never attempt to plane more than one board at a time side-by-side. If one board is slightly lower that the other, the feed roller will only hold the highest board, while the lower board will be free to slip when the knife contacts it.

  • Page 28: Avoiding Kickback

    The maximum cutting depth for soft wood at full cutterhead width is no more than the wood, the shallower the cutting depth and the slow- er the feed rate should be. A series of light passes typi- cally results in a smoother finish with less snipe. The basic steps of operating the machine as a planer are as follows: DISCONNECT THE PLANER/MOULDER FROM POWER!
  • Page 29 The Model W1812 will accommodate most moulding knife profiles. However, you still must pay special attention to workpiece support and knife-to-table clearance. Refer to the following examples to avoid common workpiece setup mistakes. REMEMBER, moulding knives have many different pro-...
  • Page 30 When cutting crown moulding (Figure 37), make a wood- en V-track that can be clamped to the table. The V-track must support at least 50% of the workpiece height on both sides. Do not use the guide rails that came with your machine for crown moulding support.
  • Page 31 Make sure to cut your workpiece to the correct width for the knife being used (Figure 39). To improve knife life CORRECT and workpiece results when cutting in very hard woods, use a table saw to rabbet out some of the profile before running the workpiece into the planer/moulder.
  • Page 32 When cutting edge profiles on workpieces that are taller than they are wide, you must clamp wooden extension rails to the table so they support at least 75% of the workpiece height on both sides (Figure 41). Never attempt to use the low profile metal guide rails that came with this machine if they do not adequately support the workpiece, such as with tall workpieces.
  • Page 33 The maximum depth for a moulding cut in soft wood is ⁄ " deep. However, the harder the wood or the more knots it has, the shallower the cut, and the slower the feed rate must be. The basic steps of operating the machine as a moulder are as follows: DISCONNECT THE PLANER/MOULDER FROM POWER! 2.

  • Page 34: Moulding Knives

    Inc. dealer. If you do not have a dealer in your area, these products are also available through online dealers. Please call or e-mail Woodstock International Inc. Customer Service to get a current listing of dealers at: 1-800-840-8420 or at sales@woodstockint.com.
  • Page 35 A perfect dedicated dust collector for a planer/moulder on a job site or in a shop. The motor is ⁄ HP, 110V, sin- gle-phase; and the flow specifications are 650 CFM with a static pressure of 3.4" H O. The bag capacity is 2.8 cubic feet with a filtration level down to 30-micron.
  • Page 36 Regular maintenance on your machine will ensure its optimum performance. Make a habit of inspecting your machine each time you use it. Loose mounting bolts. Worn switch, damaged cords, and plugs. Damaged V-belt. Any other unsafe condition. Frequently vacuum sawdust away from the internal working parts of the machine and motor fan cover.

  • Page 37: Assembly

    Since all bearings are sealed and permanently lubricated, simply leave them alone until they need to be replaced. However, this machine does need lubrication in other places, such as those shown in Figures 49—51. At a minimum, lubricate these areas every six months, but under heavy use or adverse working conditions, increase lubrication intervals accordingly.

  • Page 38: Test Run

    If you require additional machine service information not included in this section, please contact Woodstock International Technical Support at (360) 734-3482 or send an e-mail to:...

  • Page 39: Feed Roller Height And Spring Tension

    The feed rollers must be aligned correctly with the table to maintain a smooth and straight feed. DISCONNECT THE PLANER/MOULDER FROM POWER! . Remove the chip deflector lock pin, and set the chip deflector aside. Refer to 54, and make a wooden gauge block as outlined.
  • Page 40 If the drive chain tensioner rubber foot (Figure 57) wears and the drive chain becomes slack after long-term machine use, the chain will have to be readjusted. The chain should not be tight like a V-belt where there is preload on a pulley and shaft. The sprocket shafts on this machine must be free float- ing with no chain tension against them.
  • Page 41 Due to normal wear and break in, the column ways and the headstock gib will eventually have to be readjusted. To adjust the headstock gib, do these steps: 1. DISCONNECT THE PLANER/MOULDER FROM POWER! 2. Clean and lubricate the column leadscrew, gib, and ways.

  • Page 42: Wiring Diagram

    These pages are current at the time of printing. However, in the spirit of improvement, we may make changes to the electrical systems of future machines. Study this diagram carefully. If you notice differences between your machine and these wiring diagrams, call Woodstock International Technical Support at (360) 734-3482.
  • Page 43 Wiring Diagram WARNING Read Page 39 ACCIDENTAL INJURY HAZARD! Disconnect power supply before Before adjustments, setup, Wiring or maintenance! -40-...

  • Page 44: Electrical Component Locations

    Feed Speed Emergency ON Switch Dial Stop Switch Feed Motor Feed Motor Control Read Circuit Board Page 39 Panel Before Wiring Magnetic Contactor Start Capacitor Motor Junction Thermal Relay 61. Electrical component locations. -41-...
  • Page 45 This section covers the most common problems and corrections with this type of machine. Motor will not start. 1. Emergency Stop button is applied or at fault. 2. Break or short in wiring; or loose connections. 3. Power supply switched off/has incorrect voltage.

  • Page 46: Headstock

    Machine has excessive 1. Motor fan rubbing on fan cover. vibration or noise. 2. Machine incorrectly mounted on floor or mobile base. 3. Motor mounting loose. 4. V-belt at fault. 5. Headstock gib loose. 6. Knives are dull. 7. Motor brushes worn/at fault (feed motor only).
  • Page 47 Excessive snipe (there is 1. One or both of the feed rollers are a dip in the end of the set too low. board that is uneven with 2. Feed roller springs are applying the rest of the cut). too much roller pressure. 3.
  • Page 48 -45-...
  • Page 49 PART # DESCRIPTION XPS07M PHLP HD SCR M4-.7 X 8 XPN06 HEX NUT 1/2-12 XPN05 HEX NUT 1/4-20 XPB25 HEX BOLT 3/8-16 X 1-3/4 X1812005 KNOB X1812006 HANDWHEEL XPN08 HEX NUT 3/8-16 XPSS11 SET SCREW 1/4-20 X 1/4 XPN08 HEX NUT 3/8-16 XPSS08 SET SCREW 5/16-18 X 1/2 X1812011...
  • Page 50 213-4 213-1 213-2 213-3 217-1 217-3 217-4 217-2 PART # DESCRIPTION XPSS02 SET SCREW 5/16-18 X 3/8 XPN02 HEX NUT 5/16-18 XPB07 HEX BOLT 5/16-18 X 3/4 X1812209 MOTOR PULLEY XPN08 HEX NUT 3/8-16 XPW07 FLAT WASHER 5/16 X1812213 MOTOR 2HP 220V 213-1 XPC400C S CAPACITOR 400M 250V 1-3/4 X 3-3/4 213-2 X1812213-2 FAN...
  • Page 51 302-3 302-2 315-2 315-1 302-1 302-4 -48- 310-1 342-1 Note: For wiring harness locations, refer to wiring diagram on Page 40.
  • Page 52 PART # DESCRIPTION X1812301 FEED ROLL SPROCKET X1812302 FEED MOTOR 1/4 HP 220V 302-1 X1812302-1 FEED MOTOR POWER CORD 302-2 X1812302-2 FEED MOTOR BRUSH SET 302-3 X1812302-3 PLASTIC LOCK SCREW 302-4 X1812302-4 DRIVE GEAR X1812303 STEEL CONDUIT X1812304 PLASTIC CONDUIT X1812305 STAND XPS06...
  • Page 53 PART # DESCRIPTION D3377 LOGO SHOP FOX X1812401 COVER WARNING LABEL X1812402 ID LABEL X1812404 COVER WARNING LABEL XLABEL-12 READ MANUAL LABEL XLABEL-04 ELECTRICITY LABEL PART # X1812407 X1812408 PLABEL-63 DISCONNECT 220V LABEL X1812410 X1812412 X1812413 -50- DESCRIPTION CUTTERHEAD WARNING LABEL MACHINE NAME LABEL MODEL NUMBER LABEL MOTOR DUST LABEL...
  • Page 54 Name ___________________________________________________________________________________ Street __________________________________________________________________________________ City _________________________ State ___________________________Zip ________________________ Phone # ______________________ Email___________________________Invoice # ___________________ Model #_________Serial #______________Dealer Name__________________Purchase Date___________ . How did you learn about us? _____ Advertisement _____ Mail Order Catalog . How long have you been a woodworker/metalworker? _____ 0-2 Years _____ 2-8 Years .
  • Page 55 FOLD ALONG DOTTED LINE Place Stamp Here FOLD ALONG DOTTED LINE TAPE ALONG EDGES--PLEASE DO NOT STAPLE...
  • Page 56 Woodstock International, Inc. will repair or replace, at its expense and at its option, the Shop Fox machine or machine part, which in normal use has proven to be defective, provided that the original owner returns the product prepaid to a Shop Fox factory service center with proof of their purchase of the product within two years, and provides Woodstock International, Inc.
