  • Page 1 User and maintenance manual Anchorage tripod Model Eagle Nest 3 Read this manual Rel.18092019English carefully and keep it for future reference...

  • Page 2: Ferno Technical Support

    Ferno s.r.l.'s Customer Service. Intellectual property declaration The information in this manual is the property of Ferno s.r.l. - Via Benedetto Zallone 26, 40066 Pieve di Cento (Bologna) Italy. © Copyright Ferno s.r.l. All rights reserved.

  • Page 3: Table Of Contents

    5.1 Initial setup ____________________________ 12 5.2 Leg positioning and assembly ______________ 12 5.3 Head assembly _________________________ 14 5.4 Third leg assembly on the Eagle Nest 3 ______ 15 5.5 Positioning procedure for the upper head anchorage system _______________________ 17 5.6 Installation procedure for the base rope ______ 18 6 - MAINTENANCE___________________________ 19 6.1 Routine and preventive maintenance ________ 19...

  • Page 4: Warning

    Do Not Lubricate Unauthorised overhauls and repairs carried out by people not body in charge of approved by Ferno s.r.l., will render all warranties null and void and Lubricate monitoring the product may compromise the safety of the device. Non-original spare parts and inadequate repairs may cause damage and/or injury.

  • Page 5: Definitions

    CE2008 - Notified body in charge of monitoring the product. • EN 795:2012 - The product is certified according to standards EN795:2012, type B and CEN/TS 16415:2013 (Eagle Nest 3) and type A (Eagle Nest 2) for use by three people.
  • Page 6 Eagle Nest 3 Manufacturer: Ferno Washington Italia srl Product: Model/code: Tripod Anchor Device Eagle Nest 3 Read and fully understand operator’s manual before MM/YY: using the product Standard(s) : Serial Number: EN 795:2012 type B CEN/TS 16415:2013 type B info@ferno.it Legal headquarters and Commercial offices Via B.

  • Page 7: Operator Training And Skills

    EN 795:2012 regulation. The EAGLE NEST 3 device has been tested for three users maximum, according to EN 795:2012 type B and CEN/TS 16415:2013, type B. Its operators need adequate information and training before use.

  • Page 8: Ec Conformity

    YRC). • User's manual. 3.2 EC Conformity The EC conformity of Eagle Nest 3 was established as per Regulation (EU) 2016/425. The conformity assessment procedure described in Module B of the EU Regulation 2016/425 was carried out by Dolomiticert Scarl, Z.I. Villanova 7/a, 32013 Longarone (BL) –...

  • Page 9: Components (Eagle Nest 3)

    Eagle Nest 3 4 - COMPONENTS (EAGLE NEST 3) EAGLE NEST 3 FRONT VIEW Anchorage EN 795 Head Leg - fixed element Locking pin Single leg for Eagle Nest 3 extractable element 5-point adjustment Foot Textile fibre base rope TRANSPORT BAG Fabbricante: Ferno S.r.l.

  • Page 10: General Specifications

    Eagle Nest 3 Eagle Nest Tripod Maximum height The leg inclination is different 4.1 General specifications General use: • As PPE against falls from a height. • No ground anchorage. • Protection against slipping (surface). • The stability of the anchorage device must be guaranteed.
  • Page 11 Eagle Nest 3 Minimum height Single leg for Eagle Nest 3 © Ferno s.r.l.. Rel.18092019...

  • Page 12: Eagle Nest 3 Configuration

    Eagle Nest 3 5 - EAGLE NEST 3 CONFIGURATION 5.1 Initial setup WARNING Before using the Eagle Nest device: Mainly used on flat structures (approx. + / - 1 °). Wear suitable PPE against foreseeable risks. ● Check the good conditions of each element composing ●...
  • Page 13 Eagle Nest 3 Position the leg on the desired hole and insert the locking pin. Insert the leg - fixed element. Lock the two elements with the specially provided pin. ●Note: insert instructions for the maximum differential adjustment of the device feet in case of irregular...

  • Page 14: Head Assembly

    Eagle Nest 3 Insert the ball-jointed foot at the end of the leg. The ball joint allows to adapt the Eagle Nest 3 to any inclination of the legs. Lock the two elements with the specially provided pin. 5.3 Head assembly Insert the head on the terminal end of the leg - fixed element and secure the elements with the specific pin.

  • Page 15: Third Leg Assembly On The Eagle Nest 3

    Eagle Nest 3 5.4 - Third leg assembly on the Eagle Nest 3 Place the grey head close to the head assembly. WARNING the anchorage device should only be installed by qualified personnel or organisations. Insert the pin in the hole of the grey head.
  • Page 16 Eagle Nest 3 Lock the third leg with the pin. Insert the third leg - extractable element. Lock the two elements with the specially provided pin. At the end of installation, use the leg adjustment system - extendible leg to adapt the height and the anchorage point centring.

  • Page 17: Positioning Procedure For The Upper Head Anchorage System

    Eagle Nest 3 5.5 Positioning procedure for the upper head anchorage system 1 - Arrange the anchorage system for fall protection paying attention to surround all three head elements. 2 - The textile ring must comply with applicable regulations; only use the sling supplied with the device.

  • Page 18: Installation Procedure For The Base Rope

    (extractable element) of the Eagle Nest. Repeat the operation for all three legs of the device. Ferno strongly recommends to use the base rope supplied with the Eagle Nest 3. © Ferno s.r.l.18092019...

  • Page 19: Maintenance

    ● Do all the locking devices work properly? ● Check-list of extraordinary inspection Ferno base rope: is it in full working order and ● If one of the following problems occurs the EAGLE NET compliant with inspection requirements? must be temporarily dismissed: Non-Ferno base rope: is it in full working order and ●...

  • Page 20: Cleaning The Device

    You are thus invited When not in use, store the device in an indoor to be wary of those who present themselves as Ferno's environment that is dry and protected from direct authorised technician. We suggest you to directly contact sunlight.

  • Page 21: Technical Support

    8 - WARRANTY Warranty Terms and Conditions Ferno's products are guaranteed against manufacturing defects for a period of 24 months from the date on the Ferno s.r.l. shipping document. Ferno s.r.l. guarantees its spare parts for a period of 12 months.
  • Page 22 (to be borne by Ferno), while the right to call and the sending of the technician are EXCLUDED by the If a product is found to be defective, Ferno s.r.l. will repair maintenance at the customer's site. or replace it.

  • Page 23: Main Rules For Usage Of The Eagle Nest And Of Fall-Arresting Ppe

    Eagle Nest 3 MAIN RULES FOR USAGE OF THE EAGLE NEST AND OF FALL-ARRESTING PPE • PPE must be used by duly trained and informed personnel. • PPE cannot be used by personnel judged unfit further to a technical evaluation or by inadequately trained personnel.
  • Page 24 Eagle Nest 3 The device must be equipped with adequate instructions for use made by the Manufacturer, to be written in the language of the country where it has been sold. In case, the translation of the instructions for use in a language different from that of the Manufacturer will be at the reseller’s charge.
  • Page 25 Eagle Nest 3 The Eagle Nest has been submitted to a dynamic resistance and integrity test. This table shows the peak displacement values. These data allow the user to calculate the minimum air draught under their feet so that any impact is avoided on the way down.

  • Page 26: Periodical Inspection Log

    Eagle Nest 3 PERIODICAL INSPECTION LOG Date Periodical (P) or Defects noted, repairs carried out and any other relevant Signature of Date of next extraordinary information the person in inspection inspection (S) charge © Ferno s.r.l.18092019...

  • Page 27: Training Record

    Eagle Nest 3 TRAINING RECORD Date Instructor Name Training Type TRAINING RECORD Date Instructor Name Training Type © Ferno s.r.l.. Rel.18092019...
  • Page 28 Eagle Nest 3 TRAINING RECORD Date Instructor Name Training Type TRAINING RECORD Date Instructor Name Training Type © Ferno s.r.l.18092019...
  • Page 29 Eagle Nest 3 Product User and Maintenance Manual, required to operate the product safely, maintain its efficiency and reliability, and comply with the terms of the warranty. Rel.18092019 English Ferno s.r.l. Via Benedetto Zallone 26 40066 - Pieve di Cento (BO) - ITALY Telephone (toll-free for Italy) 800.501.711...
